Square or Rectangle Cuvettes and Cells
Fireflysci Type 18FL Fluorescence Micro Cuvette with PTFE Cover (Material: UV Quartz) (Lightpath: 10mm)
Type 18FL Fluorescence Micro Cuvette with PTFE Cover (Material: UV Quartz) (Lightpath: 10mm)• Cuvette has an open top with a PTFE lid which rests on the top• Material is UV Quartz (transmits over 80% between 190-2,500nm)• Four windows and the base optically polished for fluorescence measurements• Lightpath is 10mm• Outside dimensions 12.5x12.5x45mm• Inside Dimensions- 10x2x45mm• Capacity- 0.7mL
Sigma Aldrich Fine Chemicals Biosciences HellmaR absorption cuvette1EA
with PE stopper aperture 2.5mm x 2mm rectangular
Fireflysci Type 701M Sub-Micro Cuvette (Material: Black UV Quartz) (Lightpath: 10mm) (Z-Dimension: 8.5mm) (Capacity: 50ul)
Type 701M Sub-Micro Cuvette (Material: Black UV Quartz) (Lightpath: 10mm) (Z-Dimension: 8.5mm) (Capacity: 50µl)• Cuvette has an open top with a PTFE threaded stopper which pushes into the top• Material is UV Quartz (transmits over 80% between 190-2,500nm)• Black quartz is to block out and absorb any stray light• Two 2x2.5mm windows optically polished• Lightpath is 10mm• Outside dimensions 12.5x12.5x45mm• Inside Dimensions- 10x2x2.5mm• Capacity- 50µl
Fireflysci Type 41FL Macro Flourescence Cuvette with Screw Cap (Material: Optical Glass) (Lightpath: 10mm)
Type 41FL Macro Flourescence Cuvette with Screw Cap (Material: Optical Glass) (Lightpath: 10mm)• Cuvette has an airtight cap, which screws onto the top of the cuvette• Each cell comes standard with one closed screw cap and one open screw cap with a self-healing injection disc (SEPTA)• Material is Optical Glass (transmits over 80% between 340-2,500nm)• Four windows and the base optically polished• Lightpath is 10mm • Outside dimensions 12.5x12.5x55mm• Inside Dimensions- 10x10x45mm• Capacity- 3.5mL
Perkin Elmer US LLC UV Quartz SUPRASIL Rectangular Semi-Micro Cell with Lid - 10 mm, Qty. 2
The UV Quartz SUPRASIL Semi-Micro Cells are widely used in routine UV/Vis analysis. They have the same outside dimensions as Macro cells, but their cell walls have been thickened slightly, limiting the interior sample chamber width to 4 mm with a base thickness of 3.2 mm. Each cell has two clear windows. Semi-Micro cells have either a lid or a stopper. While the outside dimensions of Semi-Micro cells with Stoppers differ slightly from those with Lids, the path length and volume are not affected. UV Quartz SUPRASIL is a quartz of the highest purity and homogeneity. An empty UV Quartz SUPRASIL cell gives a transmission of more that 80% over a spectral range of 200 - 2,500 nm. These cells are identified by a blue PerkinElmer logo.
Sigma Aldrich Fine Chemicals Biosciences HellmaR absorption cuvette1EA
with PTfE stopper black side walls and base
MTC Bio Spectrophotometer Cuvette, PS, 1.5mL semi-micro, round opening, 10mm light path, 340-800nm range, 2 optical sides, 10 trays of 100, 1000/cs
MTC Bio's disposable cuvettes are compatible with most popular spectrophotometers. Manufactured from high quality, optically clear polystyrene. They are intended for deteriminations in the 340 to 800nm (visible) wavelength range. Available in 3 sizes: 1.5mL micro, 2.5mL semi-micro and 4.5mL macro. All sizes are 12.5mm square, 45mm height and are compatible with various spectrophotometer models including: Carolina®, Spectronic®200, Spectronic®20 and 20D, Spectronic®Educator, Genesys™ and Accuris SmartDrop. If a closure is desired, please order cuvette caps separately. • Fits most spectrophotometers and photometers• Polystyrene for use in visible range (340-800nm)• Dust-proof, non-scratch protective packaging• Absorption reproductivity error of ≤1%
Fireflysci Type 1 Macro Cuvette with PTFE Cover (Material: Pyrex Glass) (Lightpath: 10mm)
Type 1 Macro Cuvette with PTFE Cover (Material: Pyrex Glass) (Lightpath: 10mm)• Cuvette has an open top with a PTFE lid which rests on the top• Material is Pyrex Glass (transmits over 80% between 320-2,500nm)• Two windows optically polished• Lightpath is 10mm• Outside dimensions 12.5x12.5x45mm• Inside Dimensions- 10x10x45mm• Capacity- 3.5mL
Hunter Lab 20mm Transmission Cell
Optically clear glass cells with fixed path length of 10 mm, 20 mmor 50 mm. Sample volume 20 ml, 40 ml and 100 ml respectively.For use with Transmission Spill Tray and Cell Holder.
Sigma Aldrich Fine Chemicals Biosciences HellmaR absorption cuvette1EA
flowthrough cells with 2 screw connectors M 6 X 1 and FEP tubes aperture 17.5mm x 3.5mm rectangular
Starna Cells Inc SEMI MICRO CELL
Sub-Micro Fluorometer Cells, Type 16F, Window material: Spectrosil Quartz, Useable Range: 170 to 2700nm, Path Length: 10mm, Aqueous Volume: 65 microliter, Exterior: 12.5L x 12.5W x 45mmH, Window: 2W x 2.5mmH, Z Dimension: 8.5mm, Geometric V
Cole-Parmer Jenway Quartz Cuvette, Ultra-Micro, UV/Visible, 50 uL, 10 mm Path; 1/EA
Quartz cuvettes are available in a wide capacity range from 50 L to 35 mL and path lengths from 10 to 100 mm.
Visible % transmission: maximum from 400 to 750 nm
UV wavelength % transmission: maximum from 200 to 400 nm
