Partition Chromatography
Miles Scientific Plate Holder (Plastic), Holds 25 plates
This TLC plate holder is lightweight and made of polypropylene. It is thus highly resistant to contamination or other ill affects from exposure to typical TLC solvents.The sloping bottom grooves guide TLC plates to the vertical grooves which hold plates in an upright position. Holds up to 25 TLC plates of any size. Dimensions: 10.5" x 8.0" x 4.0" (L x W x H)
Macherey-Nagel TLC/HPTLC aluminum sheets ALUGRAM RP-18W/UV254, 5x10 cm
ALUGRAM sheets RP-18W/UV254 - size: 5x10 cm - pack of 50
Sorbent Technologies Inc Alumina N TLC Plates, w/UV254, polyester backed, 200um, 4x8cm, 50/pk
Alumina Neutral (pH 6-8) with UV254, analytical, polyester backed TLC plates. The coating thickness is 200um and dimensions are 4x8cm. There are 50 plates per pack. Applications include: terpenes, alkaloids, steroids, aliphatic and aromatic compounds. To ensure sufficient adherence an inert organic binder is added to the aqueous suspension for coating. The aluminum oxide layer has a specific surface of about 200 m2/g (BET) and a pore size of about 60A. To activate the aluminum oxide layer, we recommend heating the TLC plates for 10 minutes at 120C.
Miles Scientific Glass Reagent Sprayer
A glass sprayer with a specially designed head to eliminate formation of droplets and spattering. This feature assures delivery of a fine misty spray and ends problems from an uneven discharge. Can be used with an air-line or the rubber bulb supplied. The volume of the reagent flask is 100 ml.
Camag Scientific Twin Trough Chamber For 10X10 Cm Plates, With Stainless Steel Lid
This Is A Classical Developing Tank For Thin-Layer Chromatography. Compared To A Flat Bottom Chamber Less Solvent Is Needed. A Twin-Trough-Chamber Reduces Disposal Problems And Allows Preconditioning Of The Plate With Any Solvent And For Any Duration. For Preconditioning Or Saturation, The Trough Opposite To The Plate Is Filled With Developing Solvent. The Use Of A Saturation Pad Is Recommended For A Fast, Homogeneous And Reproducible Chamber Saturation Process. This Tank Is Suitable For Plates Up To 10 X 10 Cm In Size.
Chemglass Life Sciences 125mL TLC Chromatography Sprayer, Improved
125mL TLC Chromatography Sprayer. Sprayer provides a fine, uniform spray ideally adjusted for the development of chromatographic patterns. Spray pattern is adjustable by varying the coverage of the vent hole with the users thumb. Sprayer is used with low pressure air (5/PSI) or rubber pressure bulb. Sprayer consists of an atomizer top attached to the reservoir with a Rodaviss 24/40 joint. This design provides for a positive, grease-free seal between the atomizer and reservoir and eliminates the glass hooks used on other sprayers. Complete sprayer consists of the atomizer top, Erlenmeyer shaped reservoir, CG-182-03 open-top screw cap and CG-305-212, #212 Viton o-ring.
Chemglass Life Sciences TLC Developing Tank Complete, Latch-Lid
Heavy duty, molded TLC developing tank for use with plates up to 20 x 20 cm ( 8in x 8in). The weight of the tank is approximately 15 pounds and the bottom is ground to insure stability. The unique latching system holds the matching ground surfaces of the lid and tank firmly in place, enhancing the stability of the saturated atmosphere for the developing TLC plates. All of the metal components of the Latch-Lid mechanism are made of stainless steel. Inside dimensions of the tank are 27cm wide x 7cm deep x 26 cm high (10 5/8in x 2 7/8in x 10in). Tank is supplied complete with lid.
Macherey-Nagel TLC polyerster sheets POLYGRAM SIL G, 20x20 cm
POLYGRAM sheets SIL G - size: 20 x 20 cm - pack of 25
Miles Scientific SILICA GEL COATED ON AL FOIL SHEETS 200UM 20X20CM (25 SHEETS)
Analtech’s flexible backed TLC plates offer the same exacting specifications as with the classic glass backed plates assuring batch-to-batch uniformity. Quality is controlled at each step in the manufacturing process — from incoming raw materials to outgoing packaging. Lighter and safer to handle than glass; also unbreakable- Easy to cut with scissors to customize plate size or isolate components - Available with Polyester or Aluminum backing - Attach to reports for permanent record - Minimum storage space required - Inexpensive shipping due to weight
