Accuflow Systems Anderson-Negele Pressure Gauge, 63 mm, 0-60 psig, 3/4 in Tri-Clamp
Supplier: Accuflow Systems EK06901100211
Sanitary 63 mm pressure gauge for hygienic process monitoring, offering a 0-60 psig range, bottom mounting, and a 3/4 in Tri-Clamp process connection. Constructed with AISI 316L wetted parts and an AISI 304 case, it is suitable for CIP/SIP and process temperatures up to 284 °F.
- Range 0-60 psig.
- Dial size 63 mm.
- Process connection 3/4 in Tri-Clamp.
- Mounting bottom.
- Wetted material stainless steel AISI 316L, Ra ≤8 microinches.
- Bourdon tube and socket stainless steel AISI 304, welded.
- Case stainless steel AISI 304.
- Lens polysulphone.
- System fill mineral oil (standard); case fill unfilled (optional glycerin).
- Maximum process temperature 284 °F.
