MSC SPI Plug Thread Gage, #6-40, 3B Class, Double End, Go/No Go
Supplier: MSC 55310973
This plug thread gage is designed for #6-40 internal threads with a 3B classification. It features a double-end design with both "Go" and "No Go" functions, and includes a handle for ease of use. Constructed from tool steel, it has a Go Pitch Diameter of 0.1218 in (3.0937 mm) and a No Go Pitch Diameter of 0.12430 in (3.1572 mm).
- Taperlock design
- Inspects internal threads to ensure proper assembly of mating components
- Includes handle
- Go pitch diameter: 0.1218 in (3.0937 mm)
- No Go pitch diameter: 0.12430 in (3.1572 mm)
- Handle size: 00
- Overall length: 2.7399 in (69.5900 mm)
- Right-hand thread direction
- Inspection certificate traceable to NIST standards (ASME B1.2)
- UNF thread standard
