HPLC Guard Columns and Cartridges
Sepax Technologies Inc Sepax HPLC Column Antibodix WCX, NP1.7, 2 x 10 mm
Antibodix columns are specially designed for high resolution, high efficiency and high recovery separations of antibodies. The packing support is composed of a rigid, spherical, highly cross-linked poly(styrene divinylbenzene) (PS/DVB) non-porous bead. The non-porous resin has particle size of 1.7, 3, 5 and 10 µm. The PS/DVB resin surface is grafted with a highly hydrophilic, neutral polymer thin layer with the thickness in the range of nanometer. On the top of the hydrophilic layer, weak cation-exchange functional groups are attached via a proprietary chemistry, resulting in high capacity ion-exchange layer.
Waters Corp GTxResolve Premier SEC Guard, 1000Å, 3 μm, 4.6 x 30 mm
The GTxResolve Premier SEC 1000Å, 3 μm, 4.6 x 30 mm Guard is manufactured with low adsorption MaxPeak HPS hardware and novel bridged ethylene HO-PEO particles. It is designed to support high recovery analyses of 200 to 800Å diameter GTx drugs, including mRNA, LNPs, and viral vectors. This optimized 4.6 x 30 mm Guard is intended for use with both 4.6 and 7.8 mm ID analytical columns to ensure long column lifetimes.
- Features low adsorption MaxPeak HPS hardware and novel bridged ethylene HO-PEO particles.
- Designed for high recovery analyses of GTx drugs (200 to 800Å), including mRNA, LNPs, and viral vectors.
- Extends analytical column lifetime by trapping particulates; cGMP, ISO 9001 certified manufacturing with rigorous QC.
- Minimizes secondary interactions, offering broad method flexibility across buffers (pH 2.5–8.5, 4°C to 50°C).
Waters Corporation XTerra MS C8 Guard Cartridge, 10 μm, 10 mm x 7.8 mm
XTerra columns offer high efficiency separations, combining silica and polymer particle benefits for a rugged material with high mechanical strength and an expanded pH range. Designed for mass spectrometry, XTerra MS C8 columns deliver sharp peaks, good sensitivity, and large peak capacities. Trifunctional bonding chemistries ensure long lifetimes over a wide pH range, high throughput, excellent resolution, and ultra-low bleed.
- Compatible with mass spectrometry applications
- Sharp peaks, good sensitivity, large peak capacities
- Trifunctional bonding chemistries for long lifetimes over a wide pH range
- High throughput with excellent resolution and ultra-low bleed
- Spherical particle shape
- Pore size: 125 Å
- Temperature limits: 20°C to 60°C
- pH range: 1 to 12
Optimize Technologies EXP Trap Cartridge, 4.6mm x 5mm, 3.0µm EXP, HILIC, 3pk
The Hand-Tight EXP™ Trap Column is rated to 20,000+ psi. This unique design connects directly to any injection valve (with 10-32 threads) or in-line with 1/16” tubing for unparalleled convenience and efficiency. The EXP™ System enables chemists to quickly remove detergents or salts which can affect the ionization process in MS work. This trapping technique can concentrate the sample directly on-line, allowing for increased recovery of precious sample material compared to off-line techniques. Free-Turn™ architecture allows users to change cartridges by hand without breaking fluid connections on the holder inlet/outlet. The EXP™ Trap Column family now offers packed beds available in 2, 5, 10, 15, 20 and 30mm lengths with diameters ranging from 1-4.6mm and bed volumes from 1.6-600µL. Please contact your representative directly if you're interested in a length other than 5mm.
Mac-Mod Avantor ACE HILIC-B, 100 Å, 3 µm, 2.1 x 10 mm Guard Cartridges (5/pk)
Avantor ACE HILIC UHPLC and HPLC columns are manufactured with 100 Å Ultra-Inert Base Deactivated Silica specifically designed for your HILIC method development needs. Avantor ACE HILIC UHPLC and HPLC columns are available in 3 different bonded phases HILIC-A (acidic phase), HILIC-B (basic phase), and HILIC-N (neutral phase). Avantor ACE HILIC UHPLC and HPLC columns are available in 1.7, 3, and 5 um particle sizes in all analytical column sizes. All Avantor ACE HILIC columns are known for their excellent peak shape and batch to batch reproducibility. Columns are packed in 1000 bar UHPLC hardware.
Mac-Mod Avantor ACE C18-AR, 100 Å, 5 µm, 20.0 x 10 mm Guard Cartridges (3/pk)
Avantor ACE Excel UHPLC and HPLC columns are manufactured with 100 Å Ultra-Inert Base Deactivated Silica specifically designed for your HPLC method development needs - Note SuperC18 is 95 Å Avantor ACE HPLC columns are available in a wide range of bonded phases (i.e. C18, C18-AR, C18-PFP, C18-Amide, CN-ES, SuperC18, NH2, C8, C4, Phenyl, AQ, CN and Sil). Avantor ACE Excel UHPLC and HPLC columns are avaialble in 1.7, 2, 3, and 5 µm particle sizes in all analytical column sizes. All Avantor ACE Excel columns are known for their excellent peak shape and batch to batch reproducibility. Columns are packed in 1000 bar UHPLC hardware. Note: Avantor ACE Excel UHPLC guard columns are available for all 1.7 and 2 µm particle sizes across all 2.1 mm - 4.6 mm column ID - Note: H0011 connects directly to the analytical column - Guard column cartridges are available in 3-packs. For 3 and 5 µm Excel columns use same guard systems used for Avantor ACE HPLC analytical columns.
Optimize Technologies EXP Trap Cartridge, 1.5mm x 5mm, 3.0µm EXP, 3.0µm EXP, C4, 3pk
The Hand-Tight EXP™ Trap Column is rated to 20,000+ psi. This unique design connects directly to any injection valve (with 10-32 threads) or in-line with 1/16” tubing for unparalleled convenience and efficiency. The EXP™ System enables chemists to quickly remove detergents or salts which can affect the ionization process in MS work. This trapping technique can concentrate the sample directly on-line, allowing for increased recovery of precious sample material compared to off-line techniques. Free-Turn™ architecture allows users to change cartridges by hand without breaking fluid connections on the holder inlet/outlet. The EXP™ Trap Column family now offers packed beds available in 2, 5, 10, 15, 20 and 30mm lengths with diameters ranging from 1-4.6mm and bed volumes from 1.6-600µL. Please contact your representative directly if you're interested in a length other than 5mm.
Sepax Technologies Inc Sepax HPLC Column Antibodix WCX, NP1.7, Guard cartridge with holder, 4 x 10 mm
Antibodix columns are specially designed for high resolution, high efficiency and high recovery separations of antibodies. The packing support is composed of a rigid, spherical, highly cross-linked poly(styrene divinylbenzene) (PS/DVB) non-porous bead. The non-porous resin has particle size of 1.7, 3, 5 and 10 µm. The PS/DVB resin surface is grafted with a highly hydrophilic, neutral polymer thin layer with the thickness in the range of nanometer. On the top of the hydrophilic layer, weak cation-exchange functional groups are attached via a proprietary chemistry, resulting in high capacity ion-exchange layer.
Mac-Mod Princeton 2-Ethylpyridine 60 Å, 5 µm, 4 x 10 mm Guard Cartridges (5/pk)
Princeton Chromatography Achiral SFC columns are designed and manufactured in the US, well known for innovating novel and robust workhorse phase chemistries, for the analysis of achiral SFC applications. Princeton designs myriad phase chemistries to improve the selectivity and efficiency of SFC analysis. Known for originally innovating the 2-EP phase chemistry, explore what Princeton has to offer. Columns are available from analytical to preparative sizes and are available in a wide range of pore sizes, particle sizes, column ID's and lengths. If you do not see something that you want, please just ask!
Mac-Mod Avantor ACE UltraCore SuperC18, 95 Å, 2.5 µm, 4.6 x 5 mm UHPLC Guard Cartridges (3/pk)
Avantor ACE UltraCore solid-core (core-shell) particle columns are ideal for MS work offering improved signal intensity and maximum response. These columns combine high efficiency separations with low back pressure. The Encapsulated Bonding Technology (EBT™) greatly increases the ligand coverage of the silica surface and eliminates the effect of unbonded silanol groups on separations. This higher ligand coverage results in improved inertness, chromatographic performance and stability. Solid Core particle technology provides higher efficiencies per unit back pressure as compared to sub-2-micron UHPLC columns. Columns combine the proven advantages of UHPLC and HPLC columns with Solid Core Particle Technology. Solid-core columns can be used on both UHPLC and HPLC systems. Excellent peak shape and phases stability with extended pH. Highly inert, ultra-low bleed, designed for use with LC/MS compatible buffers. 2.5 and 5 µm particle sizes available.
Mac-Mod Princeton 4-Ethylpyridine 300 Å, 5 µm, 2.1 x 10 mm Guard Cartridges (5/pk)
Princeton Chromatography Achiral SFC columns are designed and manufactured in the US, well known for innovating novel and robust workhorse phase chemistries, for the analysis of achiral SFC applications. Princeton designs myriad phase chemistries to improve the selectivity and efficiency of SFC analysis. Known for originally innovating the 2-EP phase chemistry, explore what Princeton has to offer. Columns are available from analytical to preparative sizes and are available in a wide range of pore sizes, particle sizes, column ID's and lengths. If you do not see something that you want, please just ask!
