Stirrer Accessories
Chemglass Life Sciences 3/4" Upper Female Motor Adapter (Black)
3/4" Upper Female Motor Adapter (Black). Tru-Stirrer Shaft Coupling Replacement Component.
Chemglass Life Sciences 12.7mm Tru-Stir Stirrer Shaft Coupling, 5/16" Upper Male Coupling, For Use with CG-2047 Flex Shaft
12.7mm Tru-Stir Stirrer Shaft Coupling, 5/16" Upper Male Coupling, For Use with CG-2047 Flex Shaft. The design of our Tru-Stir stirrer shaft coupling eliminates the need to use rubber hose or universal adapters to attach your stirrer shafts to overhead stir motors. Coupling incorporates a unique helical S.S. spring permitting up to 1/4¿ of offset misalignment and 45¿ of angular misalignment. Coupling is rated for 24 in-lbs of torque without the backlash normally associated with common coil springs. Lower portion of coupling has a nylon adapter with a one piece collar for attachment to 12.7mm (OD) stirrer shafts. Upper adapters permit the coupling to be used with CG-2047 flexible drive shafts. Male Upper Coupling is 5/16". Overall length of the coupling is 4¿. Supplied complete with an allen wrench set.
Chemglass Life Sciences 5/8" Upper Female Motor Adapter (Gold)
5/8" Upper Female Motor Adapter (Gold). Tru-Stirrer Shaft Coupling Replacement Component.
Chemglass Life Sciences 12mm Upper Female Motor Adapter (Green)
12mm Upper Female Motor Adapter (Green). Tru-Stirrer Shaft Coupling Replacement Component.
Chemglass Life Sciences 1/2" Upper Female Motor Adapter (Aqua Marine)
1/2" Upper Female Motor Adapter (Aqua Marine). Tru-Stirrer Shaft Coupling Replacement Component.
Chemglass Life Sciences Motor Adapter, 5/16" Male to 3/8" Female
Motor Adapter, 5/16" Male to 3/8" Female. Replacement part for CG204701 Flexible Drive Shaft.
Chemglass Life Sciences Stirrer Turbine, Upper, PTFE, Pilot Plant, 100mm OD, fits 19mm Shaft, 13/64in Blade Thickness
Stirrer Turbine, Upper, PTFE, Pilot Plant, 100mm OD, fits 19mm Shaft, 13/64in Blade Thickness. PTFE six blade turbine style agitator for use with reactor stirrer shafts. Shaft opening is drilled straight through to permit positioning at any height on the shaft.
Chemglass Life Sciences 3/8" to 5/16" Male Adapter
3/8" to 5/16" Male Adapter. Tru-Stirrer Shaft Coupling Replacement Component.
Chemglass Life Sciences 6mm Stirrer Shaft Coupling, Universal, 1/4" OD Stud
6mm Stirrer Shaft Coupling, Universal, 1/4" OD Stud. Coupling incorporates a universal joint to compensate for misalignment of drive motor and glass stirrer shaft. Nylon bushing compresses around shaft using an allen screw. Stainless steel stud attaches directly to the chuck of a stirrer motor. Supplied complete with an allen wrench.PLEASE NOTE: OTHER THAN OUR CG-2097 PROCESS REACTOR STIRRER SHAFTS, CHEMGLASS 19MM OD STIRRER SHAFTS HAVE A REDUCED TOP DIAMETER OF 12.7MM. WHEN ORDERING A UNIVERSAL COUPLING FOR A CHEMGLASS 19MM OD STIRRER SHAFT, USE PART NUMBER CG-2046-03.
Chemglass Life Sciences 19mm Tru-Stir Stirrer Shaft Coupling, 5/8" Upper Female Coupling
19mm Tru-Stir Stirrer Shaft Coupling, 5/8" Upper Female Coupling. The design of our Tru-Stir stirrer shaft coupling eliminates the need to use rubber hose or universal adapters to attach your stirrer shafts to overhead stir motors. Coupling incorporates a unique helical S.S. spring permitting up to 1/4¿ of offset misalignment and 45¿ of angular misalignment. Coupling is rated for 24 in-lbs of torque without the backlash normally associated with common coil springs. Lower portion of coupling has a nylon adapter with a one piece collar for attachment to 19mm (OD) stirrer shafts. Female Upper Coupling is 5/8". Overall length of the coupling is 4¿. Supplied complete with an allen wrench set.
Chemglass Life Sciences 10mm Stirring Shaft, Chem-Stir, Polished, For Use With 1000mL-4L Flasks, 480mm OAL, Complete with PTFE Nut and Bolt
10mm Stirring Shaft, Chem-Stir, Polished, For Use With 1000mL-4L Flasks, 480mm OAL, Complete with PTFE Nut and Bolt. A 10mm OD precision ground and polished stirrer shaft with our patented** Chem-Stir blade attachment system. Shaft (C) has been manufactured with a ring at the lower end to permit attachment of the blade (B) with a PTFE nut (D) and bolt (A). Shaft is supplied complete with PTFE nut and bolt set. For use with PTFE bearings such as the CG-2077. Polished shaft will not cause abrasion to the sealing surfaces of the PTFE bearing, thereby allowing a vacuum tight seal. Uses the same PTFE nut and bolt blade attachment method as the CG-2074 ground shaft. PLEASE NOTE: STIRRER BLADES MUST BE PURCHASED SEPARATELY.THESE SHAFTS ARE NOT TO BE USED WITH ANY TYPE OF GLASS BEARING. FOR GROUND SHAFTS USED WITH GLASS BEARINGS SEE CG-2074.
Chemglass Life Sciences Agitator, PTFE, 10mm, Four Blade, 75mm Dia, Fits Shaft Size 10mm, 45° Impeller Angle
Agitator, PTFE, 10mm, Four Blade, 75mm Dia, Fits Shaft Size 10mm, 45¿ Impeller Angle. Agitators are made entirely of PTFE and glass filled PTFE and are for use with 10mm OD stirrer shaft CG-2075-B. Available in 45¿, 60¿ and 90¿ impeller angles. The 45¿ and 60¿ impellers are set up to stir downwards in a clockwise direction and upwards when rotated counter-clockwise. Agitator hub is open so that it can be positioned anywhere along the stirrer shaft and locks onto shaft with a glass filled TFE screw.
