Microscope Lamps and Accessories
Electron Microscopy Sciences Formvar Support Film 5-6 nm thick on Square 200 mesh Nickel Grid
Support Film on grids has become a main product line for us since the demand for high quality coated grids has increased. To make your microscopy work easier and to save you a great deal of time we offer you a complete line. All of our coated grids are optically checked followed by batch testing in the EM. Packed in grid storage box. Standard coating is 5 to 6 nm thick.
Grid: Nickel
Ted Pella Inc Lacey Carbon Type-A, 300 mesh, Copper, 25/pk
A Lacey carbon film with a removable Formvar backing on the opposite side of the grid. When the Formvar is removed, by dipping in solvent, the Lacey carbon film remains. These films are stable under all EM operating conditions and for use where the presence of Formvar can not be tolerated. Pure Lacey Carbon is more delicate than those with Formvar backing and require more careful handling during specimen preparation. Holes are completely open.
Electron Microscopy Sciences Silicon Test Specimen, Incident L.M.
This Test Specimen is made of a 5 mmx5 mm square of single crystal silicon. It is photo-etched and the squares repeat every 10 um. The dividing lines are 1.9 um wide.
A broader etching line is written every 500 um, which is useful in light microscopy. This is an excellent test specimen for comparing magnification and assessing any distortion in the image field. It is ideally useful in the context of automated counting systems to check for unsuspected distortions. Where critical measurements must be made the sample can be mounted directly onto the calibration specimen so that an internal calibration is obtained on the micro-graph.
Ran Biotechnologies Inc 200g of FO-101 fluorinated oil
200g of FO-101 fluorinated oil (bp 130degC; d1.55; viscosity 0.80cSt)
Electron Microscopy Sciences Howard Thin Coverglass, 28 x 33x0.5mm thick
For use with counting chambers.
Size: 28 x 33 x 0.5 mm thick
Electron Microscopy Sciences Standard Pin SEM Stub Slotted 1/2" Head with 8 mm Pin, Aluminum, 1/8" Pin diameter
Slotted head pin stub mounts with tappered pin ends are for use with Cambridge, Phillips, Camscan, B&L, Etec, Zeiss. Made from ultra-pure aluminum polished finish with a smooth and luster surface.
Head: 1/2"
Pin height: 8 mm
Pin diameter: 1/8"
Electron Microscopy Sciences Paterson Globes and Circles Graticle NG1, 16mm
The graticule consists of a central rectangle, sub-divided into nine smaller rectangles with a number of increasing circles outside the top and bottom horizontal edges. The marked figures are the diameters of the circles in units. 250 units represent the horizontal length of the large rectangle. Rectangle size is 4.5mm x 2.025mm. Circle sizes in microns are 450, 360, 270, 225,180,145, 110, 74, 37, and 18.
Size: 16 mm
Surface: Glass sandwich
Electron Microscopy Sciences PremaDisk Diamond Grinding Disc SM Medium-Hard Bond, 60 µm Particles, 200 mm diameter
PremaDisk Flexible Diamond Grinding Discs offer superior surface finishes that are usually only seen in lapping processes.
The SM disc is a medium-hard resin bond base for fine grinding and polishing of metals, ceramics and glass.
The SH disc is a hard resin bond base for applications where a very sharp edge must be maintained on the workpiece.
Both discs increase productivity by combining optimum surface quality, removal rates, and tool life in the same process.
Particles: 60 µm
Diameter: 200 mm
Electron Microscopy Sciences PremaDisk Diamond Grinding Disc SM Medium-Hard Bond, 60 µm Particles, 250 mm diameter
PremaDisk Flexible Diamond Grinding Discs offer superior surface finishes that are usually only seen in lapping processes.
The SM disc is a medium-hard resin bond base for fine grinding and polishing of metals, ceramics and glass.
The SH disc is a hard resin bond base for applications where a very sharp edge must be maintained on the workpiece.
Both discs increase productivity by combining optimum surface quality, removal rates, and tool life in the same process.
Particles: 60 µm
Diameter: 250 mm
Electron Microscopy Sciences PremaDisk Diamond Grinding Disc SH Hard Bond, 30 µm Particles, 300 mm diameter
PremaDisk Flexible Diamond Grinding Discs offer superior surface finishes that are usually only seen in lapping processes.
The SM disc is a medium-hard resin bond base for fine grinding and polishing of metals, ceramics and glass.
The SH disc is a hard resin bond base for applications where a very sharp edge must be maintained on the workpiece.
Both discs increase productivity by combining optimum surface quality, removal rates, and tool life in the same process.
Particles: 30 µm
Diameter: 300 mm
Electron Microscopy Sciences PremaDisk Diamond Grinding Disc SM Medium-Hard Bond, 60 µm Particles, 300 mm diameter
PremaDisk Flexible Diamond Grinding Discs offer superior surface finishes that are usually only seen in lapping processes.
The SM disc is a medium-hard resin bond base for fine grinding and polishing of metals, ceramics and glass.
The SH disc is a hard resin bond base for applications where a very sharp edge must be maintained on the workpiece.
Both discs increase productivity by combining optimum surface quality, removal rates, and tool life in the same process.
Particles: 60 µm
Diameter: 300 mm
