Distillation Labware
Glassware and replacement parts designed to carry out distillations in laboratory settings; includes condensers, distillation heads, receivers, etc. Products are available for various scales and for specialty distillations.
Distillation is a process used widely in the laboratory or in wider working environments for separating or purifying liquids or liquid mixtures based on the different boiling points of individual components.
Distillation Applications:
• Separation and purification of miscible liquid mixtures in organic chemistry
• Drying of solid residues and/or solvent removal
• Fractional distillation of liquids from polymers and petroleum products
• Removal of particulates or other solid contaminants
• As part of a water purification system for production of distilled water for laboratory use
• Specialist steam distillation-based applications such as Kjeldahl analysis of nitrogen and proteins in food, beverage, or environmental samples
What Types of Distillation Equipment Are Available?
Conventional distillation apparatus, typically comprising individual, jointed borosilicate glassware components assembled by the user (depending upon the application), using appropriate clamps, stands, and supports. Most conventional distillation assemblies combine a round-bottomed distilling flask to contain and heat the liquid(s) that require purification, fitted with a stoppered or jointed neck to which is attached a downward-sloping, inclined side-arm for connection to a condensing unit to cool the heated vapors back down to their liquid state. Heating mantles are the preferred heat source for improved temperature control. These conventional distillation units are also available supplied complete and ready-assembled for added convenience and ease of use.
Specialized automated distillation equipment, notably units designed for the determination of volatile acidity and alcoholic strength by volume in wines, musts, and alcoholic beverages, and units designed for Kjeldahl nitrogen or protein determinations.
Chemglass Life Sciences Distilling Receiver, 3mL, 14/20 Joint, Graduated, 210mm height x 90mm width
Distilling Receiver, 3mL, 14/20 Joint, Graduated, 210mm height x 90mm width. Cow type receiver has a single standard taper outer joint at the top. The four lower graduated receiver tubes can be accessed via a syringe for product recovery. Tubes are graduated from 0 to 3mL in 0.2mL subdivisions.
Chemglass Life Sciences Adapter, Distillation, 45/50 Joint Size, Side Inner Joint At 75°
Adapter, Distillation, 45/50 Joint Size, Side Inner Joint At 75¿, with standard taper outer joint at the top, and inner joints on the bottom and sidearm, all being the same size. Inner joints are at a 75¿ angle to one another.
Chemglass Life Sciences Adapter, Vacuum Take-Off, Style "A", 105°, 45/50 Joint Size
Adapter, Vacuum Take-Off, Style "A", 105¿, 45/50 Joint Size. With standard taper top outer and lower inner joints with sealed in drip tip. Adapter is bent at a 105¿ angle for use in vacuum distillation. Serrated hose connection has an O.D. of 10mm at the largest serration for connection to vacuum source.
Chemglass Life Sciences Condenser, High Efficiency, 590mm, 45/50 Joint, 465mm Jacket Length, 100mm OD Jacket
Condenser, High Efficiency, 590mm, 45/50 Joint, 465mm Jacket Length. This unique design combines some of the best features for refluxing in a single condenser. Coolant, introduced into the upper hose connection, fills a large cold finger that is wrapped with coils. After the coolant travels through the coils, it enters the water jacket to maximize cooling surface along the vapor path. Angled take off joint is a standard taper 24/40, and the angled take off joint for the 45/50 size is a standard taper 29/42. Hose connections for the 24/40 size condenser are 10mm at the largest serration. Hose connections for the 45/50 size are 15mm at the largest serration.
Chemglass Life Sciences Adapter, Distilling Trap, Kjeldahl, 29/42 Top Outer, 14/20 Lower Inner
Adapter, Distilling Trap, Kjeldahl, 29/42 Top Outer, 14/20 Lower Inner. Similar to CG-1032, but with joints of non-similar sizes at the upper and lower portion of the adapter. Dimensions are the same as the CG-1032.
Chemglass Life Sciences 1000ml Trap Body Only
1000ml Trap Body Only. Replacement part for CG453104 vacuum trap.
Ace Glass, Inc. Head, micro distilling, 20-400 top, 14/10 bottom
Head, micro distilling, 20-400 top, 14/10 bottom
Chemglass Life Sciences Condenser C, 55/50, 750mm
Condenser C, 55/50, 750mm. Condenser replacement part for the CG137303 extraction apparatus. Fits Size C apparatus.
Ace Glass, Inc. 14/10 100mm distillation column
14/10 100mm long Vigreux distillation column. Length in millimeters refers to the effective length as measured from the lowest to the highest indent of the column.
Chemglass Life Sciences Adapter Only, Distribution, 24/40 Joint
Distribution adapter replacement part for the CG1279 series of distilling receivers. 24/40 joint.
Chemglass Life Sciences Condenser Only, 40ml Sublimer
Condenser Only, 40ml Sublimer. Replacement part for CG303401 sublimator.
Chemglass Life Sciences Condenser Only, 15ml Sublimer
Condenser Only, 15ml Sublimer. Replacement part for CG303601 sublimation apparatus.
