Distillation Labware
Glassware and replacement parts designed to carry out distillations in laboratory settings; includes condensers, distillation heads, receivers, etc. Products are available for various scales and for specialty distillations.
Distillation is a process used widely in the laboratory or in wider working environments for separating or purifying liquids or liquid mixtures based on the different boiling points of individual components.
Distillation Applications:
• Separation and purification of miscible liquid mixtures in organic chemistry
• Drying of solid residues and/or solvent removal
• Fractional distillation of liquids from polymers and petroleum products
• Removal of particulates or other solid contaminants
• As part of a water purification system for production of distilled water for laboratory use
• Specialist steam distillation-based applications such as Kjeldahl analysis of nitrogen and proteins in food, beverage, or environmental samples
What Types of Distillation Equipment Are Available?
Conventional distillation apparatus, typically comprising individual, jointed borosilicate glassware components assembled by the user (depending upon the application), using appropriate clamps, stands, and supports. Most conventional distillation assemblies combine a round-bottomed distilling flask to contain and heat the liquid(s) that require purification, fitted with a stoppered or jointed neck to which is attached a downward-sloping, inclined side-arm for connection to a condensing unit to cool the heated vapors back down to their liquid state. Heating mantles are the preferred heat source for improved temperature control. These conventional distillation units are also available supplied complete and ready-assembled for added convenience and ease of use.
Specialized automated distillation equipment, notably units designed for the determination of volatile acidity and alcoholic strength by volume in wines, musts, and alcoholic beverages, and units designed for Kjeldahl nitrogen or protein determinations.
Chemglass Life Sciences 125mL Solvent Distillation Still Head, Airfree, Schlenk
125mL Solvent Distillation Still Head, Airfree, Schlenk. Still head in 125mL capacity for use in re-purification of solvents under inert atmosphere. One-piece design of condenser and storage reservoir eliminates multiple connections usually associated with distillation setup. 0-4mm Chem-Vac™ Chem-Cap valves provide for grease-free, leakproof seals. Lower 3-way valve (C) allows for solvent return to flask, take-off or storage in graduated reservoir. Syringe access port (B) incorporates a 4mm PTFE stopcock with a 14/20 outer joint for use with CG-3022 septum stoppers permitting repeated syringe punctures or changes of the septum without breaching the integrity of the solvent. Valve (A) allows for isolation of the still from the inert gas source. Valve (D) permits evacuation and purging of the receiver flask. Uptake tube (F) is a 24/40 inner joint, while the takeoff connection (E) is a 14/20 inner joint. Design Suggested by Dr. Thomas Oberhauser.
Chemglass Life Sciences Condenser, ''CR'' Assembly, For Rotary Evaporators, Plastic Coated
Condenser, ''CR'' Assembly, For Rotary Evaporators, Plastic Coated. Two piece cold trap style condenser for use with rotary evaporators. Condenser has a 45/40 lower inner drip joint, a 19/38 stopcock plug, and removable hose connections using GL-14 threads. Condenser is supplied complete with PTFE centering ring along with plastic caps and serrated hose connections. Plastic coating is on the outer portion of condenser only.
Chemglass Life Sciences Distillation Head, Vigruex, Jacketed, 10/30 Thermometer Joint, 24/40 Joint Size, 200mm Column Length, Approx. 325mm Height x 350mm Width
Distillation Head, Vigruex, Jacketed, 10/30 Thermometer Joint, 24/40 Joint Size, 200mm Column Length, Approx. 325mm Height x 350mm Width. Vacuum jacketed Vigreux distillation head having a sealed on condenser, braced for strength. The top outer joint is for a 1” immersion 10/18 or 10/30 thermometer. Vacuum adapter has an inner joint and a sealed in drip tip. Condenser length is 100mm on the 14/20 size and 200mm on the 24/40 and 29/42 sizes.
Chemglass Life Sciences Distilling Receiver, 10mL, Moisture Test, Barrett, 14/20 Joint Size, 2mm PTFE Stopcock , Approx. 190mm Height x 75mm Width
Distilling Receiver, 10mL, Moisture Test, Barrett, 14/20 Joint Size, 2mm PTFE Stopcock , Approx. 190mm Height x 75mm Width. Similar to CG-1261 but with the uptake tube vacuum jacketed to improve distillation performance. The jacket eliminates the possibility of condensation or recrystallization of distillate in the sidearm. The 5ml has subdivisions of 0.20ml; 10ml has subdivisions of 0.1ml; the 20ml has subdivisions of 0.2 from 0 to 3ml and 0.5 from 3 to 20mL. Available with glass or PTFE stopcocks.
Chemglass Life Sciences Bump Trap, 250mL, Rotary Evaporator, 24/40 Top Outer, 29/42 Lower Inner
Bump Trap, 250mL, Rotary Evaporator, 24/40 Top Outer, 29/42 Lower Inner. Used between the vapor tube and evaporation flask on a rotary evaporator to prevent contents of the flask from being drawn into the condenser in the event of “bumping.” Traps have a 24/40 top outer joint and the listed size of lower inner joint.
Chemglass Life Sciences Distilling Column, Water Jacketed, 24/40 Joint, 200mm
Distilling Column, Water Jacketed, 24/40 Joint, 200mm. Jacketed distilling column has indentations on the inner tube to support packing material. The jacket allows the column to be used as a condenser. Column has a top outer and lower inner standard taper joint. Available in joint sizes other than those listed. All sizes have an I.D. of approximately 10mm.
Chemglass Life Sciences Distilling Receiver, 10mL, Moisture Test, Barrett, 19/22 Joint Size, 2mm PTFE Stopcock , Approx. 190mm Height x 65mm Width
Distilling Receiver, 10mL, Moisture Test, Barrett, 19/22 Joint Size, 2mm PTFE Stopcock , Approx. 190mm Height x 65mm Width. Barrett style distilling receiver used to determine the water content in petroleum or bituminous material. Receiver is made according to ASTM specifications, with the addition of the top outer standard taper joint and lower stopcock. The 2mL has sub-divisions of 0.02mL; the 5ml has subdivisions of 0.20mL; 10ml has subdivisions of 0.1mL; the 20mL has subdivisions of 0.2 from 0 to 3mL and 0.5 from 3 to 20mL. Available with glass or PTFE stopcocks.
Chemglass Life Sciences Adapter, Distillation, 105°, 19/22 Outer
Adapter, Distillation, 105¿, 19/22 Outer. Distillation adapter with a top outer standard taper joint. Tapered delivery tube is bent at a 105¿ angle to the outer joint and extends into open receivers.
Chemglass Life Sciences Distilling Receiver, 10mL, Moisture Test, Dean-Stark, 24/40 Joint Size, Approx. 250mm Height x 90mm Width
Distilling Receiver, 10mL, Moisture Test, Dean-Stark, 24/40 Joint Size, Approx. 250mm Height x 90mm Width. Similar to CG-1258 but with the addition of an overflow tube between the uptake tube and the graduated receiver.
Chemglass Life Sciences Distilling Column, 24/40 Joint, 200mm, Vigreux
Distilling Column, 24/40 Joint, 200mm, Vigreux. Vigreux style column with indentations that run the entire length of the column for improved vapor-liquid contact. Column length refers to the effective length, measured from the lowest to highest indent in the column. Column has a top outer and lower inner standard taper joint.
Chemglass Life Sciences Adapter Only, Vacuum, 24/40 Joint
Vacuum adapter replacement part for the CG1279 series of distilling receivers. 24/40 joint.
Petroleum Analyzer Corporation Pour Point Test Tube complies with requirements of ASTM D5950
Pour Point Test Tube complies with requirements of ASTM D5950 & D97
Chemglass Life Sciences Bump Trap, 500mL, Rotary Evaporator, 24/40 Top Outer, 29/42 Lower Inner
Bump Trap, 500mL, Rotary Evaporator, 24/40 Top Outer, 29/42 Lower Inner. Used between the vapor tube and evaporation flask on a rotary evaporator to prevent contents of the flask from being drawn into the condenser in the event of “bumping.” Traps have a 24/40 top outer joint and the listed size of lower inner joint.
Ace Glass, Inc. RECEIVER ONLY RECEIVER ONLY
5mL distilling receiver for use with NC0800432 distillation apparatus.
