General Spectrometer Accessories
Glass Expansion DuraMist DC Nebulizer 1mL/min, Includes NFT-050 UniFit Connector with 0.50mm ID x 1.3mm OD x 700mm long tubing (1 piece)and 70-803-0969 Gas Fitting with Ratchet Nebulizer connector
DuraMist DC Nebulizer 1.0mL/min, includes UniFit Connector with 0.50mm ID x 1.3mm OD x 700mm long tubing (1 pc) and DC Gas Fitting Type 11 with ratchet connector (1 pc). Compatible with Vista/700-ES Series ICP-OES, 4100/4200 MP-AES.Optimum nebulizer gas flow rate is 0.7L/min & sample flow rate is 1.0mL/min. Recommended not to exceed optimum 1.0mL/min sample flow rate; however, lower gas & sample flow rates are OK. The backpressure should read ~40 psi at 0.7L/min gas flow rate. DuraMist is an economical inert nebulizer for high-precision analysis & the highest tolerance to TDS, up to 30%. Made from PEEK, it tolerates up to 5% HF.Replacement parts include P/Ns NC1625341 and 70-803-0969.Recommend nebulizer maintenance tools are Fluka RBS25 (P/N NC9000117) & Eluo Nebulizer Cleaning Tool (P/N 501907353). When nebulizer is not in use, best to store in the provided hard plastic case.Glass Expansion is ISO 9001:2015 certified by AB Certification, No. AU4501-9001
Glass Expansion SeaSpray DC Nebulizer 0.4mL/min, Includes NFT-16-50 UniFit Connector with 0.50mm ID x 1.6mm OD x 700mm long tubing (1 piece) and 70-803-1105 Type 13 DC Fitting with Ratchet Nebulizer connector
SeaSpray DC Nebulizer 0.4 mL/min, includes UniFit Connector with 0.50mm ID x 1.6mm OD x 700mm long tubing (1 pc.) and DC Gas Fitting Type 13 with ratchet connector (1 pc.). Compatible with Advion-Interchim Solation, Agilent 7700/7800/7850/7900/8800/8900, and Horiba.Optimum nebulizer gas flow rate is 1.0 L/min and sample flow rate is 0.4 mL/min. Recommended not to exceed optimum 0.4 mL/min sample flow rate; however, lower gas and sample flow rates are OK. The backpressure should read ~40 psi at 1.0 L/min gas flow rate. Can tolerate up to 20% TDS. We recommend the use of the Elegra Argon Humidifier to achieve best performance with high TDS.Replacement parts include P/Ns 502702959 and 501907289.Recommend nebulizer maintenance tools are Fluka RBS25 (P/N NC9000117) and Eluo Nebulizer Cleaning Tool (P/N NC9462559). When nebulizer is not in use, best to store in the provided hard plastic case.Glass Expansion is ISO 9001:2015 certified by AB Certification, No. AU4501-9001
Glass Expansion Elegra Argon Humidifier
Elegra Argon Humidifier. Compatible with Shimadzu ICP-OES 7/8/9/9800 Series / ICPM-8500, ICPMS-2030. An argon humidifier is commonly used in ICP analyses involving samples with high concentrations of dissolved solids. It helps to alleviate salt deposits in the nebulizer & torch injector, allowing uninterrupted & maintenance-free operation. Compact, durable, cost-effective design with a non-pressurized water reservoir, & no heating or electric power required. An easy-to-use bypass switch allows you to take the Elegra off-line without disconnecting argon lines. Highly efficient membrane humidification technology that consistently maintains signal stability for samples with high TDS. Inert & metal-free eliminates possibility of contamination. Simple to use & maintain with maximum & minimum fill lines ensuring you are always operating under optimum conditions.Replacement Elegra Membrane, P/N 70-803-1286.Glass Expansion is ISO 9001:2015 certified by AB Certification, No. AU4501-900
Glass Expansion Eluo HF Nebulizer Cleaner for new OpalMist, PolyCon or DuraMist (N0777712)
Eluo Nebulizer Cleaner for OpalMist and DuraMist Nebulizers. Compatible with Glass Expansion OpalMist and DuraMist nebulizers. Used to clear nebulizer clogs. If the sample capillary becomes blocked with particulates, use the Eluo Nebulizer Cleaning Tool to backflush the blockage. The Eluo is only recommended for Glass Expansion OpalMist and DuraMist nebulizers. For Glass Expansion¿s SeaSpray, MicroMist, Conikal, and Slurry nebulizers, use the Eluo Glass Concentric version (NC9462559).If nebulizer blockages are frequent, consider adding the re-useable Guardian in-line filter (NC0897716). The Guardian in-line filter provides a simple and effective way to eliminate the risk of a blockage, and the filter can be cleaned using a simple attachment for the Eluo (NC0801128). Fluka RBS-25 Concentrate 1L (NC9000117) is an excellent cleaning solution for nebulizers and other sample introduction components.Glass Expansion is ISO 9001:2015 certified by AB Certification, No. AU4501-9001
Perkin Elmer US LLC Standard Glass Baffled Cyclonic Spray Chamber for NexION 300/350
This O-ring-free baffled cyclonic spray chamber, made of borosilicate glass, comes standard with NexION Q, X, and D models. It relies on momentum to efficiently and quickly remove the larger droplets from the sample mist decreasing any opportunity for occlusion or agglomeration of the smaller droplets. The result is higher efficiency, better precision, and faster washouts than other spray chamber designs. For use with ball joint injectors.
Glass Expansion Quartz Torch with single slot for Optima 8x00 (N0780130, N0780131, 8003-0344)
Quartz Torch, 1-Slot demountable quartz torch standard for PerkinElmer Optima 8x00 Series ICP-OES (N0780130).Standard torch for routine aqueous applications, but not inert to samples containing hydrofluoric acid (HF).Glass Expansion is ISO 9001:2015 certified by AB Certification, No. AU4501-9001
Electron Microscopy Sciences Omniprobe Short-Cut™ Coupons Backside Thinning, Mo/Cu, 45° Angle
TEM sample grid coupon designed specially for use in the Short-Cut™ tool. The center portion is a standard 3 mm grid into which the sample loaded needle is swaged and cut.
Material: Mo/Cu
Angle: 45°
Perkin Elmer US LLC Elegra Argon Humidifier
This assembly includes: Elegra Humidifier Gas Connector Humidifier Gas Line, 1/4-28 Ratchet EzyLok Assembly EzyLok Kit Features and Benefits: Compact design. No heating or electric power required. Non-pressurized water reservoir. An easy-to-use bypass switch allows you to take the Elegra off-line without disconnecting argon lines. Highly efficient membrane humidification technology. Improved signal stability for samples with high TDS. Simple to use and maintain. Facilitates long, uninterrupted run times. Inert metal-free construction eliminates possibility of contamination. Rugged and durable polymer casing. Maximum and minimum fill marks ensure that you are always operating under optimum conditions.
Perkin Elmer US LLC Axial Flat Mirror Kit for Avio 500
Includes: mounted mirror with o-ring and one set of large nitrile gloves.
Perkin Elmer US LLC High Matrix Quartz Torch for NexION 1000/2000
This torch provides a longer lifetime when analyzing high matrix samples.
Perkin Elmer US LLC SeaSpray Glass Nebulizer, 2.0 mL/min, for ELAN/NexION 300/350
The SeaSpray Concentric Nebulizer is ideal for samples with high dissolved solids and offers outstanding nebulization effciency for trace level analysis. It offers freedom from clogging while nebulizing solutions near the limit of solubility of most mineral salts, and conferring signifcant sensitivity gains. All SeaSpray Nebulizers are supplied with the EzyLok argon connector.
