BRANDTECH™ VACUUBRAND™ Replacement Plug for PC3001 Basic Chemistry-Design Diaphragm Vacuum Pump with Speed Control

Catalog No.	Flow Rate
13-889-105	1.2 CFM

Catalog No. 13-889-105 Supplier BRANDTECH™ Supplier No. 20696723

Description

Basic US plug for use with PC3001 Vacuum Pump

This very compact chemistry pumping unit is an excellent solution when working with high boiling solvents. Typical applications are vacuum generation for rotary evaporators, vacuum concentrators and filtrations. With the continuously variable jog wheel, the pumping speed is manually adjustable to the process requirements. There are two optional kits available to easily upgrade the PC 3001 basic to the fully functional PC 3001 VARIOpro complete with CVC 3000 vacuum controller, inlet separator and vapor condenser at the outlet.

• Outstanding chemical resistance and superior vapor tolerance
• High flow rate even at low vacuum
• Excellent ultimate vacuum even with gas ballast
• Continuously adjustable manual adaptation of pumping speed via jog wheel
• Upgradable to PC 3001 VARIOpro system with two accessory packages: Kit 1, with CVC 3000 and inlet separator; Kit 2, with emission condenser and catchpot

Specifications

• Horsepower: 0.16 hp
• Includes: Power cord, manual, speed control
• Motor Speed: 200 to 3000
• Electrical Requirements: 100/120 and 200/230 V 50/60 Hz
• Model: PC-3001
• Plug Type: US
• Temperature (Metric) Storage: -10°C to +60°C
• Temperature (English) Max.: 104°F
• Temperature (Metric) Max: 40°C
• Temperature (Metric) Min.: 10°C
• Flow Rate: 1.2 CFM
• For Use With: Vacuum generation for rotary evaporators, vacuum concentrators and filtrations
• Frequency: 50/60 Hz
• Overall Height (English): 15.74 in.
• Overall Height (Metric): 40 cm
• Overall Length (English): 9.88 in.
• Overall Length (Metric): 25.1 cm
• Overall Width (English): 10.07 in.
• Enclosure Rating: IP20
• Maximum Pressure: 1.1 bar
• Voltage: 100/120, 200/230 V
