ACCU-SCOPE™ EXC-120 Series Monocular Microscope with Vertical Camera Port and Achromat Objectives
SDPSCI_ED

This microscope is equipped with a monocular viewing head, vertical camera port with photo tube. Delivers sharp, high contrast objectives on a rugged, die-cast aluminum frame.

$710.05 - $767.52

Specifications

Eyepiece WF 10X/18.5 mm
Head Style Monocular, 30° Inclined, 360° Rotating
Lighting Type LED
Model EXC-121
Objective Types DIN Achromatic
View More Specs

Products 2
Catalog Number Mfr. No. Magnification Power Price Quantity & Availability
Catalog Number Mfr. No. Magnification Power Price Quantity & Availability
S012462
SDPSCI_ED
View Documents
View Product Certificates
View Alternatives and Save Up to
ACCU-SCOPE™
EXC121V3 		4X, 10X, Semi-Plan 40XR
Each for $710.05
Only null left
Add to Cart

S012463
SDPSCI_ED
View Documents
View Product Certificates
View Alternatives and Save Up to
ACCU-SCOPE™
EXC121V 		4X, 10X, Semi-Plan 40XR, 100XR
Each for $767.52
Only null left
Add to Cart

Description

Description

  • Optical system: DIN optical system, f = 160 mm, anti-mold
  • Viewing head: Monocular, inclined 30° and rotatable 360°. Vertical camera port with photo tube (c-mount adapter sold separately, CAT# 2005-5M).
  • Eyepieces: WF10x/18.5 mm field of view. Eyepieces are locked-in to prevent classroom tampering and accept 19 mm reticles
  • Nosepiece: Rear facing, quadruple, ball bearing with positive click stops to ensure parcentration
  • Objectives: Achromat objectives
  • Stage: Rackless mechanical stage
  • Condenser: N.A. 1.25 Abbe condenser on rack and pinion with iris diaphragm and swing-out filter holder
  • Stand: Cast alloy aluminum with built-in fixed focus stop allows for rapid focusing while protecting specimens. Built-in carry handle and cord hanger
  • Illumination: Variable LED illumination with bulb life rated for 20,000 hours. UL approved
  • Focusing System: Coaxial coarse and fine focus controls with an adjustable tension control. All metal gears
  • Accessories: Dust cover, immersion oil and instruction manual included
  • Certification: ISO 9001: 2018 and ISO 14001: 2018, UL approved, CE anti-mold
  • Warranty: 5-year limited warranty for parts, labor and electronic components, 1-year warranty on LED bulb
Specifications

Specifications

WF 10X/18.5 mm
LED
DIN Achromatic
110/240 V
Monocular, 30° Inclined, 360° Rotating
EXC-121
Monocular Microscope
