Thermo Scientific™ Heratherm Light Chambers 750 L

Description

Accurate and even light distribution with Long-lasting LED lighting for (ICH) light testing, plant growth and animal hatching — relative humidity and temperature are controlled to meet specified environment.

Accurate control of three parameters - Temperature above and below ambient, relative humidity and light - provide great environment in testing applications and for biological research with plants and animals. Choice of ICH module provides capability for efficient ICH light testing in Pharma.

• Uniform Temperature / relative humidity / light exposure for samples.
• Energy-efficient Peltier technology supports temperature stability and uniformity with lower energy usage compared to traditional compressors and without hazardous refrigerant.
• LED light system provides specified light exposure on 1, 2 or 3 shelves; programmable to adapt light quality / intensity and on/off timing - e.g. for day-night cycles. Choose from two light modules (ordered separately):
  • 1. ICH module, includes UV LED for ICH light testing;can only be used in ELS750 - model with solid outer door - for safety reasons
  • 2. Testing module for plant growth / daylight testing / animal hatching
• Environmentally friendly water-efficient humidification system - with water tank or optional fix water connection for in-house purified water
• Intuitive touchscreen interface with easy programmability of parameter cycles and process duration.
• Two access ports for independent data capture, and internal documentation of set and actual parameter values, along with event log to meet 21 CFR Part 11 requirements for process documentation.
• Data retrieval via USB stick, or Thermo Cloud via OPC-UA standard (with Connect Edge solution)
• Sample and process protection: Assign personalized access with passcode; restrict access with standard key door lock or optional automated door lock; various alarm options to prevent operator of process issues.
• Simplified setup with no technician required; install using standard power cord.
• IQ/OQ qualifications and other services available; visit thermofisher.com/chamberservice.
• Inner glass door keeps environment stable, even when opening outer door. Exterior glass door also available (not for ICH

Specifications

• Alarm Types: Audible and Visible
• Capacity (English): 26.5 cu.ft
• Capacity (English) Shelf: 66 lbs (stationary)
• Capacity (Metric) Shelf: 30 kg (stationary)
• Certifications/Compliance: UL, CE
• Data Outputs: USB, Thermo Cloud via OPC UA
• Capacity (Metric): 750 L
• Chamber Material: Stainless Steel (304/1.4301)
• Lighting: LED
• Material: Powder-coated Galvanized Steel
• No. of Shelves: 3
• Plug Type: Nema 5-20P
• Relative Humidity: 10 to 90%
• Temperature Range (Metric): 15 to 45°C with light; 0 to 70°C w/o light
• Type: Vertical Light Chamber
• Display: 7 in. Touchscreen user interface
• Door Style: Solid outer door with inner glass door
• For Use With (Application): ICH light testing, plant growth, light testing, animal hatching
• Humidity Range: 10 - 80% RH with light; 10 -90% RH w/o light
• Humidity Resolution: 0.1% RH
• Humidity Source: Removable water tank
• Includes: Light modules not included - ICH testing: 333979G01 / Standard: 333980G01
• Ports: 2 access ports
• Programmability: Temperature, relative humidity, light intensity
• Shelf Area (English): 4.9 ft²
• Shelf Area (Metric): 0.46 m²
• Shelf Material: Stainless Steel (304/1.4301)
• Temperature Resolution: 0.1°C
• Temperature Stability: ≤±0.3°C @ 25°C to 40°C
• Temperature Uniformity: ≤±2.0°C @ 25°C to 40°C
• Warranty: 24 months
• Water Consumption: 0.2 - 1.5 L per day; Value depends on settings, usage (e.g. number of door openings), and environmental conditions
• Water Resistivity: 0.05 - 1 MΩ
• Dimensions (L x W x H): 895 x 1080 x 1835 mm / 35.24 x 42.52 x 72.24 in
• Dimensions (LxWxH) Interior: 630 x 840 x 1450 mm / 24.8 x 33.07 x 57.09 in
• Width (English) Shelf: 31.3 in.
• Width (Metric) Shelf: 795 mm
• Shipping Weight (English): 862 lbs
• Shipping Weight (Metric): 391 kg
• Electrical Requirements: 100 - 240V, 50-60Hz, 1700W
• Voltage: 100/240 V
• Wattage: 1700 W
