Heidolph™ Tuttnauer™ PLAZMAX Plasma Sterilizer

Description

Innovative low temperature sterilizer for heat-sensitive equipment

Plasma Low Temperature Sterilization with Vaporized Hydrogen Peroxide

PlazMax provides an efficient sterilization solution for heat and moisture sensitive equipment in CSSDs and Gastroenterology and Respiratory Endoscopy Clinics. The PlazMax sterilizer inactivates micro-organisms with Hydrogen Peroxide (H2O2) vapor and plasma. It sterilizes medical devices by diffusing H2O2 into the chamber and then converting the H2O2 molecules into a plasma state. The sterilization occurs inside the chamber by means of H2O2 vapor. The PlazMax utilizes the bacterium killing power of free radicals in the H2O2 molecules released by applying heat to the H2O2 gas in the vaporizer. The combined use of H2O2 vapor and plasma, safely and quickly sterilizes medical instruments and materials without leaving dangerous residues, thus offering an effective, reliable, economical, and easy sterilization method.

Sterilization Process:

• Air removal from chamber
• Preparation for diffusion
• Diffusion (sterilization stage) - instruments are exposed to the H2O2 vapor
• Gas removal from chamber and breaking apart H2O2 molecules
• Repeat diffusion stage (sterilization) and H2O2 gas removal
• Aeration stage - removal of residue

Features:

• 50-160L chamber volume
• Gastrointestinal GI endoscope sterilizer
• Deep H2O2 penetration
• Green technology - non-toxic emissions to the environment
• Real-time graphical display of cycle parameters
• Vertical sliding door and hands-free opening device
• Regular sterilization cycles for non-hollow loads
• Advanced sterilization cycles for hollow loads
• Unique endoscope cycle
• Chemical indicators, biological indicators and sealing and packaging products available for comprehensive validated sterilization

Bundles Include:

• Freight and installation
• H2O2 bottles, filled - case of 4 bottles
• PCD lumen kit
• Minibio auto reader
• Self-contained super rapid biological indicator, 30 minutes
• Chemical indicator (strip)
• Chemical indicator (tape)

Specifications

• Autoclavable: Not Autoclavable
• Color: Silver
• Depth (Metric) Outside: 1029 mm
• Depth (Metric) Tray: 90 cm
• Depth (English) Tray: 35.43 in.
• Capacity (English): 42.79 gal.
• Capacity (Metric): 162 L
• Depth (Metric) Chamber: 924 mm
• Depth (English) Chamber: 36.38 in.
• For Use With (Application): Sterilization of heat-sensitive equipment
• Product Type: Sterilizer
• Temperature (English): 122°F
• Temperature (Metric): 50°C
• Display: Digital
• Includes: Bundle includes freight and installation, filled H202 bottles (case of 4), PCD lumen kit, Minibio auto reader, self-contained super rapid biological indicator (30 minutes), chemical indicator (strip), chemical indicator (tape)
• Frequency: 50 Hz
• Programmability: Non-sterile
• Voltage: 230 V
• Wattage: 4300 W
• Width (English) Tray: 15.75 in.
• Width (Metric) Tray: 40 cm
• Sterility: Non-sterile
• No. of Shelves: 2
