BINDER™ Series KBF - Humidity Test Chambers, with Large Temperature / Humidity Range
The KBF fulfills all important ICH requirements, from precision to programming and documentation. With flexible water supply options for all installation locations.
$20855.00 - $43294.00
Specifications
| Chamber Material | Stainless Steel |
|---|---|
| Material | Stainless Steel |
| Plug Type | US |
| Relative Humidity | 10 to 80% |
| Temperature Range (Metric) | 0°C to 70°C |
| Catalog Number | Mfr. No. | Capacity (Metric) | Price | Quantity & Availability | |||||
|---|---|---|---|---|---|---|---|---|---|
| Catalog Number | Mfr. No. | Capacity (Metric) | Price | Quantity & Availability | |||||
|
50-287-5639
|
BINDER™
90200494 |
127 L |
Each for $20,855.00
|
|
|||||
|
50-287-5750
|
BINDER™
90200495 |
262 L |
Each for $23,099.00
|
|
|||||
|
50-287-5643
|
BINDER™
90200496 |
472 L |
Each for $26,002.00
|
|
|||||
|
50-287-5680
|
BINDER™
90200497 |
727 L |
Each for $29,698.00
|
|
|||||
|
50-287-5705
|
BINDER™
90200498 |
1070 L |
Each for $34,846.00
|
|
|||||
|
50-287-5632
|
BINDER™
90200499 |
1610 L |
Each for $43,294.00
|
|
|||||
Description
- Temperature range: 0°C to +70°C
- Humidity range: 10% to 80% RH
- Proven APT.line™ preheating chamber technology
- Up to 40% lower energy consumption compared to the previous model
- Energy-efficient cooling with modern inverter cooling unit
- Cooling with climate-neutral R-600a refrigerant
- Door heating to prevent condensation
- Adjustable fan speed
- Humidity regulation with capacitive humidity sensor and responsive steam humidification
- Robust housing design with HIT sandwich technology
- Stainless-steel inner chamber
- Inner doors made of metal oxide-coated safety glass
- Two racks made of stainless steel
- Large access port with silicone plug
- Tabletop units (up to model 130) are stackable with stacking adapter
- Floor-standing units (from model 260) featuring robust twin casters, with brakes at the front
- Intuitive touchscreen controller with time-segment and real-time programming
- Ergonomically adjustable control terminal (from model 470)
- Signal triangle with light-up status display (from model 470)
- Internal data logger, measured values can be read out in open format via USB
- Class 3.3 independent temperature safety device (DIN 12880) with visual and acoustic alarms
- Unit self-test for comprehensive status analysis
- Data interfaces: Ethernet, USB
- BINDER Multi Management Software APT-COM™ basic edition
- Optional light modules for ICH photostability testing (for models 260, 470, 720)
- Optional LED light modules for plant growth (for models from 260)
Specifications
| Stainless Steel | |
| US | |
| 0°C to 70°C | |
| TFT Touch | |
| 50/60 Hz |
| Stainless Steel | |
| 10 to 80% | |
| Humidity Test Chamber | |
| 120 V |
