Accuflow Systems Saint-Gobain Tubing, Tygon S3 E-3603, 5/32 in I.D., Non-DEHP

Catalog No. 502365921
Encompass_Preferred

Clear, flexible non-DEHP laboratory tubing formulated from a bio-based thermoplastic elastomer (TPE). Designed for general laboratory connections, analytical instrumentation, vacuum and gas lines, and food-contact applications, it offers a smooth inner bore, good mechanical strength, and reliable chemical compatibility for fluid transfer.

  • Material: Bio-based thermoplastic elastomer (TPE).
  • Inner diameter: 5/32 in (4.0 mm).
  • Outer diameter: 7/32 in (5.6 mm).
  • Wall thickness: 1/32 in (0.8 mm).
  • Length: 50 ft (15 m).
  • Durometer hardness: 56 Shore A.
  • Maximum working pressure: 17 psi at 73°F (1.2 bar at 23°C).
  • Vacuum rating: 12 in Hg at 73°F (305 mm at 23°C).
  • Maximum recommended operating temperature: 165°F (74°C).
  • Sterilization methods: Autoclave, gamma radiation, ethylene oxide gas.
  • Compliance: Non-DEHP, US FDA food contact criteria, NSF-51, USP/ISO biocompatibility standards, REACH.

Catalog No. 50-236-5921 Supplier Accuflow Systems Supplier No. ACF00009
May include imposed supplier surcharges.
Add to Cart
Add to Cart

missing translation for 'validMainframeMsg'

Clear, flexible non-DEHP laboratory tubing formulated from a bio-based thermoplastic elastomer (TPE). Designed for general laboratory connections, analytical instrumentation, vacuum and gas lines, and food-contact applications, it offers a smooth inner bore, good mechanical strength, and reliable chemical compatibility for fluid transfer.

  • Material: Bio-based thermoplastic elastomer (TPE).
  • Inner diameter: 5/32 in (4.0 mm).
  • Outer diameter: 7/32 in (5.6 mm).
  • Wall thickness: 1/32 in (0.8 mm).
  • Length: 50 ft (15 m).
  • Durometer hardness: 56 Shore A.
  • Maximum working pressure: 17 psi at 73°F (1.2 bar at 23°C).
  • Vacuum rating: 12 in Hg at 73°F (305 mm at 23°C).
  • Maximum recommended operating temperature: 165°F (74°C).
  • Sterilization methods: Autoclave, gamma radiation, ethylene oxide gas.
  • Compliance: Non-DEHP, US FDA food contact criteria, NSF-51, USP/ISO biocompatibility standards, REACH.
