ACCU-SCOPE™ Z850 Series Trinocular Zoom Stereo Microscope with ED140 Ring Light on Ball Bearing Boom Stand

The UNITRON™Z850 series model 13106-2 features a trinocular head with a ball bearing boom stand, 0.5x aux objective, quad LED ring light, best-in-class 8x to 50x magnification range with click-stops at 1x, 2x, 3x, 4x and 5x to ensure quick and consistent measurement results.

Supplier:  ACCU-SCOPE™ 131062

Catalog No. 01-189-289

Description

• Binocular viewing head with 45° viewing angle
• Widefield 10x/22 mm focusing eyepiece.
• 22 mm FOV
• 0.8x to 5.0x zoom magnification range
• 6.3:1 zoom ratio
• Magnification range 4x to 25x (with 10x eyepieces and included 0.5x auxiliary objective), with click stops at 1x, 2x, 3x, 4x and 5x
• Interpupillary distance adjustment 52 mm to 75 mm
• Field of view 55 mm to 8.8 mm
• 211 mm working distance
• Includes LED140 ring light with built-in intensity control
• Ball bearing boom stand with bonder arm focusing mount
• Bonder arm (E-Arm)
• Airtight and anti-mold design

Specifications

• Magnification Power: 4X to 25X
• Head Style: Binocular, 45° Inclined
• Eyepiece: WF 10X/22 mm

• Objective Types: Zoom Stereo
• Lighting Type: LED
