Circulating Baths
Huber USA UNISTAT 815
- Hydraulically sealed design for improved thermofluid lifespan
- Operating temperature range: -85 °C to 250 °C
- Temperature stability: ±0.01 K
- Controller: Pilot ONE with 5.7" color touchscreen
- Cooling capacity: 1,500 W at -80 °C
- Heating capacity: 2,600 W (primary), 2,000 W (secondary)
- Digital interfaces: Ethernet, USB, RS232
- Max delivery pressure: 0.9 bar
- Flow rate: 40 L/min
- Safety features: Overtemperature protection, low level protection
- Dimensions: 460 mm x 604 mm x 1465 mm
- Voltage requirement: 460 VAC, 3 Phase, 60 Hz
- 4-year warranty (registration required)
Huber USA Ministat 125, Refrigerated Heating Circulator Bath
‐ Temperature range: -25°C ... +150°C - Cooling capacity (15°C): 0,3 kW‐ Cooling capacity (0°C): 0,21 kW‐ Heating capacity: 1 kW‐ Pressure pump max.: 22 l/min / 0,7 bar‐ Suction pump max. : 16 l/min / 0,4 bar‐ Pump connection: M16x1 male ‐ Power supply: 115V 1~ 60Hz
Across International Ai 200°C 15L SST Compact Desktop Heated Recirculator 220V
The Ai H200 stainless steel series heated recirculators with 2,800 watts heater offer outstanding performance and high reliability as well as quiet operation and ease-of-use. Powerful force/suction pump provides constant flow rates, while the 2nd generation PID controller gives you the ideal solution when you need precise temperature control.
Huber USA CC-118A, Clear View Circulator Bath
‐ Temperature Range: (15) 25°C ... +100°C‐ Heating capacity: 1,5 kW‐ Pressure pump max.: 27 l/min / 0,7 bar‐ Suction pump max.: 22 l/min / 0,4 bar‐ Bath volume: 18 l‐ Power supply: 110V 1~ 50/60Hz
Huber USA UNISTAT 705 WITH CONTROLLER
- Operating temperature range: -75 to 250 °C
- Temperature stability at -10 °C: 0.01 K
- Heating capacity: 3000 W
- Cooling capacity at 0 °C: 650 W
- Cooling capacity at -40 °C: 600 W
- Pump flow rate: 55 L/min
- Pump pressure: 0.9 bar
- Controller: Pilot ONE
- Display: 5.7 in color touchscreen
- Internal temperature sensor: Pt100
- External sensor connection: Pt100
- Interfaces: Ethernet, USB (Host and Device), RS232
- Refrigeration unit: Air-cooled, CFC- and HCFC-free
- Voltage requirement: 208 VAC, 60 Hz, Single Phase
- Dimensions (W x D x H): 425 x 400 x 720 mm
- Weight: 90 kg
Julabo USA Inc CORIO CD-800F R1270 EA 115V
Refrigerated/heating circulator, JULABO, CORIO CD-800F, 115V/60Hz, R1270 Refrigerant. -40…+150C. 1kW heater. Cooling power 850W at 20C 750W at 0C 400W at -20C 250W at -30C 110W at -40C. Pump 16LPM 4.8 PSI. USB plus data-logging. M16x1 pump fittings with 8 and 12mm barbs. 5...7.5L bath tank. 13 x 18.5 x 27.6 in. 93lbs
Julabo USA Inc MAGIO MX-2500F R1270 EA 230V
Refrigerated/heating circulator, JULABO, MAGIO MX-2500F 230V/60Hz, R1270 Refrigerant; -50…+200 °C; 3kW heater. Cooling: 2.5kW at 20C; 1.8kW at 0C; 850W at -20C, 500W @ -30C, 300W at -40C. Adjustable pressure/suction pump 16-31L/min, 3.5-13.3PSI. Color touchscreen UI with USB, RS232/RS485, Ethernet, MODBUS communication, USB data-logging; Pt100 port, multi-lingual, programmable. M16x1 pump fittings 8 and 12mm barbs. 5-7.5L bath tank. 15.7 x 19.7 x 33.9 in, 135lbs, with locking casters
Sigma Aldrich Fine Chemicals Biosciences IKAR ULTRA TURRAXR dispers1EA
IKAR ULTRA TURRAXR dispers1EA
Chemglass Life Sciences Oil Bath, 950mL, 150 x 75mm, 120V, 800W
Our new low form oil bath is constructed completely of stainless steel and provides for rapid heating of flasks, beakers, etc. Heating rates run between 10-15 per minute with excellent thermal response. Since the bath is constructed entirely of non-magnetic stainless steel, the contents of the vessel along with the oil itself are able to be magnetically stirred. Each bath is supplied complete with a stainless steel lid to keep the oil clean during storage. Although all sizes of the baths are fitted with a 120V heater, a temperature controller such as the CG-15001 is required to maintain the desired heating temperature. Unit is equipped with a permanently attached 13 inch, 3-wire grounded cord having stainless steel overbraid and a female Twist-Lock connection. Each bath comes complete with a 6 foot grounded extension cord with Twist-Lock connection.
