HPLC Guard Columns and Cartridges
Waters Corp Waters Spherisorb Amino (NH2) Guard Cartridge, 80 Å, 5 μm, 4.6 mm x 10 mm, 3 pk
These Amino (NH2) guard cartridges feature a silica-based aminopropyl bonded sorbent and are classified as USP L8. They are suitable for anion-exchange, normal-phase, and HILIC separations. Designed to protect analytical columns, these cartridges extend lifespan by preventing suspended particles and chemical contaminants from reaching the analytical column. The NH2 (Amino) packing has an intermediate ligand density and a 2.0 percent prescribed carbon load.
- Utilizes same high-performance packing materials as analytical columns for long-lasting performance.
- Developed for applications requiring higher capacity for biological fluid purification or temperature control.
- Manufactured in a cGMP, ISO 9001-certified facility using ultra-pure reagents.
- Each batch is chromatographically tested with neutral, acidic, and basic analytes for consistent, reproducible performance.
Waters Corp ACQUITY UPLC VanGuard Pre-column, Amide, 300Å, 1.7 μm, 2.1 mm × 5 mm
These columns analyze intact glycoproteins, fragments, and glycopeptides. Each batch undergoes quality control with a performance test standard, including Ribonuclease A and B glycoforms, ensuring batch-to-batch consistency. The kit contains one column and a vial of the standard for immediate benchmarking. The standard can be reordered for continuous monitoring, with each batch prepared under strict quality control, confirmed by a certificate of analysis.
- Amide chemistry
- Hydrophilic interaction (HILIC) separation mode
- Hybrid particle substrate
- pH range 2 to 10
- Maximum pressure 18000 psi (1240 bar)
- Not endcapped
- Particle size 1.7 μm
- Pore size 300 Å
- QC tested for glycoprotein
- VanGuard pre-column
- Compatible with UPLC/UHPLC
- BEH particle technology
- Inner diameter 2.1 mm
- Length 5 mm
- 3 units per package
Advanced Materials Technology HALO 400 Å Diphenyl, 3.4 µm, 2.1 x 150 mm
Ideal for large protein analysis
Well suited for high speed protein separations
Alternate selectivities with C4 and ES-C18
USP: L11
Available Particle Sizes: 3.4 µm
Ligand: diphenylmethyl
USP: L11
Pore Size: 400 Å
Low pH/T Limit: 2/90 ⁰C
High pH/T Limit: 9/40 ⁰C
Endcapped: Yes
Waters Corporation Guard Cartridge, SCX, 10 × 4.6 mm, 5 μm
These Spherisorb Guard Cartridges are designed for SCX type columns. They are ideal for protecting analytical columns and extending their lifespan in chromatographic applications.
- Guard cartridge for SCX type columns.
- Dimension: 10 × 4.6 mm.
- Particle size: 5 μm.
- Supplied in a pack of three.
Showa Denko America Inc Asahipak NH2P-50G 2A
Guard columns for NH2P-50 series columns, dimensions: 2.0 mm ID x 10 mm L
Waters Corp Waters Sentry Guard Cartridge, C8, 4 μm, 3.9 mm x 20 mm
The Nova-Pak C8 Sentry Guard Cartridge utilizes 4 μm particle technology for higher resolution and faster chromatography. It protects analytical HPLC columns by filtering out chemicals and particulates from the mobile stream.
- Utilizes 4 μm particle technology for higher resolution and more efficient separations.
- Protects analytical HPLC columns from damage by filtering out chemicals and particulates.
- Operates effectively across a 2 to 8 pH range.
- Manufactured under stringent conditions for batch-to-batch consistency.
- Allows for faster chromatography, enabling the use of shorter columns to decrease solvent usage or longer columns for complex mixtures.
- Maximum pressure: 6000 psi (415 Bar).
- Endcapped: Yes.
- Particle shape: Spherical.
- Units per package: 2.
Waters Corp XBridge Protein BEH SEC Guard Column, 200Å, 2.5 μm, 4.6 mm X 30 mm
The XBridge Protein BEH SEC Guard Column is designed for Size Exclusion Chromatography (SEC) applications, utilizing 2.5 μm Ethylene Bridged Hybrid (BEH)-based particles with a diol-bonded surface. It separates proteins from 10,000 to 450,000 Daltons and is compatible with UHPLC, UPLC, and HPLC systems for gel filtration in aqueous systems.
- Utilizes ethylene bridged hybrid (BEH)-based particle technology for robust and reliable separations.
- Optimized diol-bonded surface chemistry for consistent performance.
- Separates proteins from 10,000 to 450,000 Daltons.
- Compatible with UHPLC, UPLC, and HPLC systems.
- Protects analytical columns by trapping particulates and strongly retained compounds.
- Features low silanol activity for minimal secondary interactions.
- Withstands pressures up to 4500 psi.
- Designed for gel filtration in aqueous environments.
Waters Corp Torus DEA Prep Guard Cartridge, 130à , 5 µm, 19 mm X 10 mm, 1/pk
Torus DEA Prep Guard Cartridge, 130à , 5 µm, 19 mm X 10 mm, 1/pk
NANOMICRO TECHNOLOGIES INC NanoChrom Technologies, BioCore SEC-120 LC Analytical Column, 1.8 m, 4.6300 mm, Stainless Steel
BioCore SEC is a family of high performance, size exclusion chromatography columns designed for separating a broad range of biomolecules based on size. This column technology involves the creation of a neutral hydrophilic layer on the surface of specially designed, high-strength, monodispersed silica particles, combined with well-established column packing processes. BioCore SEC-120 columns are suited for aggregate determination of peptides, small proteins and related substances.
