HPLC Guard Columns and Cartridges
YMC America, Inc Ph guard 120A 3um 20x3mm
Phenyl columns provide unique selectivity when compared to aliphatic straight chain reversed phase materials such as C18 C8 and C4 YMC-Pack Phenyl is a monomerically-bonded phenyl and is fully endcapped Typical applications include aromatic compounds phenols fullerenes sweeteners
YMC America, Inc Ph-HG guard 120A 10um 10x4mm
Phenyl columns provide unique selectivity when compared to aliphatic straight chain reversed phase materials such as C18 C8 and C4 YMC-Pack Phenyl is a monomerically-bonded phenyl and is fully endcapped Typical applications include aromatic compounds phenols fullerenes sweeteners
YMC America, Inc C8-HG guard 300A 10um 10x4mm
YMC-Pack C8 columns are prepared using exhaustive bonding of a monomeric octylsilane to totally porous and spherical silica gels The functionalized silica is then treated with an endcapping process which produces a moderate 10% carbon loading on the standard 120 pore material Available in three pore sizes YMC-Pack C8 columns will separate many classes of compounds including pharmaceuticals organic chemicals and biologics
Sepax Technologies Inc Sepax HPLC Column Proteomix RP-1000, 5 µm, Guard cartridge with holder, 2 x 10 mm
Proteomix RP packings are porous polystyrene divinylbenzene (PS/DVB) polymer resins with narrow-dispersed particle size distribution. The base matrix of the resin is made of highly cross-linked PS/DVB which functions as reversed phase for chromatographic separation. The phase structure is phenyl and substituted phenyl functional groups that enable hydrophobic interaction. These highly rigid resins are provided with the particle size selection of 5, and 10 µm. In comparison to silica based reversed phase media, Proteomix RP phases have advantages for biomolecule separations with wide pH range (1-14) and high thermal stability. At various column temperatures, the Proteomix RP phases offer special selectivity, high resolution separation with online mass spec analysis capability for proteins such as mAb (monoclonal antibody), ADC (antibody drug conjugate) and related protein fragments.
Waters Corp VanGuard Cartridge, C18, 100Å Pore, 3.5 μm Particle, 3.9 mm x 5 mm
VanGuard Cartridges are designed to extend analytical column lifetime and performance by removing particulate contamination from the mobile phase stream. This cartridge is specifically optimized to protect all 4.6 mm inner diameter analytical columns containing 3.5 μm sorbent particles.
- Extends analytical column lifetime and performance.
- Removes particulate contamination from mobile phase stream.
- Optimized to protect 4.6 mm inner diameter analytical columns with 3.5 μm sorbent particles.
- Features C18 chemistry with reversed phase separation mode.
- Silica particle substrate; spherical particle shape.
- Operates within a pH range of 2 to 8.
- Withstands temperatures up to 45 °C.
- Maximum pressure of 18000 psi (1240 Bar).
- Pore size: 100 Å.
- System: HPLC.
- Carbon load: 8 %.
- Units per package: 3 pk.
Sepax Technologies Inc Sepax HPLC Column Proteomix WCX, NP1.7, Guard cartridge with holder, 4 x 10 mm
Sepax HPLC Column Proteomix WCX, NP1.7, Guard cartridge with holder, 4 x 10 mm
Mac-Mod Avantor ACE CN, 100 Å, 3 µm, 2.1 x 10 mm Guard Cartridges (5/pk)
Avantor ACE Excel UHPLC and HPLC columns are manufactured with 100 Å Ultra-Inert Base Deactivated Silica specifically designed for your HPLC method development needs - Note SuperC18 is 95 Å Avantor ACE HPLC columns are available in a wide range of bonded phases (i.e. C18, C18-AR, C18-PFP, C18-Amide, CN-ES, SuperC18, NH2, C8, C4, Phenyl, AQ, CN and Sil). Avantor ACE Excel UHPLC and HPLC columns are avaialble in 1.7, 2, 3, and 5 µm particle sizes in all analytical column sizes. All Avantor ACE Excel columns are known for their excellent peak shape and batch to batch reproducibility. Columns are packed in 1000 bar UHPLC hardware. Note: Avantor ACE Excel UHPLC guard columns are available for all 1.7 and 2 µm particle sizes across all 2.1 mm - 4.6 mm column ID - Note: H0011 connects directly to the analytical column - Guard column cartridges are available in 3-packs. For 3 and 5 µm Excel columns use same guard systems used for Avantor ACE HPLC analytical columns.
Mac-Mod Avantor ACE Excel C18, 100 Å, 2.1/3.0 x 5 mm UHPLC Guard Cartridges (3/pk)
Avantor ACE Excel UHPLC and HPLC columns are manufactured with 100 Å Ultra-Inert Base Deactivated Silica specifically designed for your HPLC method development needs - Note SuperC18 is 95 Å Avantor ACE HPLC columns are available in a wide range of bonded phases (i.e. C18, C18-AR, C18-PFP, C18-Amide, CN-ES, SuperC18, NH2, C8, C4, Phenyl, AQ, CN and Sil). Avantor ACE Excel UHPLC and HPLC columns are avaialble in 1.7, 2, 3, and 5 µm particle sizes in all analytical column sizes. All Avantor ACE Excel columns are known for their excellent peak shape and batch to batch reproducibility. Columns are packed in 1000 bar UHPLC hardware. Note: Avantor ACE Excel UHPLC guard columns are available for all 1.7 and 2 µm particle sizes across all 2.1 mm - 4.6 mm column ID - Note: H0011 connects directly to the analytical column - Guard column cartridges are available in 3-packs. For 3 and 5 µm Excel columns use same guard systems used for Avantor ACE HPLC analytical columns.
Waters Corp Prep Guard Cartridge, C8 Chemistry, 5 μm Particle Size, 125 Å Pore Size, 30 mm x 10 mm
The 30 mm x 10 mm Prep Guard Cartridge is designed to protect both HPLC and SFC 30 mm ID preparative columns. Placing this guard assembly ahead of the preparative column helps extend column lifetimes and reduce purification costs.
- Protects HPLC and SFC preparative columns.
- Extends column lifetime and reduces purification costs.
- C8 Chemistry; Reversed Phase separation.
- Hybrid, spherical particle substrate.
- pH range: 1 to 12.
- Temperature limit: 60 °C.
- Max pressure: 6000 psi (415 Bar).
- Endcapped; MS C8 bonding; low silanol activity.
- Particle size: 5 μm; Pore size: 125 Å.
- For HPLC preparative systems (LC/MS, LC).
- Inner diameter: 30 mm; Length: 10 mm.
- Carbon load: 12 %.
- 1 unit per package.
Waters Corp Waters Sentry Guard Cartridge, Diol (OH), 125 Å, 10 μm, 3.9 mm x 20 mm
This Sentry Guard Cartridge is a protective piece of lab equipment, placed between the injector and the analytical column, to improve efficiency by obstructing chemical impurities and suspended particles. It consists of 10 μm diol-bonded gel filtration materials, protecting 3.9 mm and 4.6 mm I.D. analytical columns. Manufactured in a cGMP, ISO 9001-certified facility, it ensures quality and durability.
- Protects and preserves analytical columns.
- Obstructs chemical impurities and suspended particles.
- Each batch is chromatographically tested with acidic, basic, and neutral analytes.
- Each piece of equipment is tested before approval for use.
- Increases selectivity, sensitivity, and speed of studies.
Sepax Technologies Inc Sepax HPLC Column HPLC Guard Column, Zenix SEC-300, 3 µm, 4.6 x 50 mm, Light Scattering SEC
Made of 3 µm silica particles, Zenix SEC packing is a breakthrough technology for size exclusion chromatography. Combination of 3 µm silica particle size and proprietary surface technology enables highest separation efficiency and resolution for biological molecules and water soluble polymers. Available pore sizes of Zenix packings are 80, 100, 150 and 300 Å
