Distillation Labware
Glassware and replacement parts designed to carry out distillations in laboratory settings; includes condensers, distillation heads, receivers, etc. Products are available for various scales and for specialty distillations.
Distillation is a process used widely in the laboratory or in wider working environments for separating or purifying liquids or liquid mixtures based on the different boiling points of individual components.
Distillation Applications:
• Separation and purification of miscible liquid mixtures in organic chemistry
• Drying of solid residues and/or solvent removal
• Fractional distillation of liquids from polymers and petroleum products
• Removal of particulates or other solid contaminants
• As part of a water purification system for production of distilled water for laboratory use
• Specialist steam distillation-based applications such as Kjeldahl analysis of nitrogen and proteins in food, beverage, or environmental samples
What Types of Distillation Equipment Are Available?
Conventional distillation apparatus, typically comprising individual, jointed borosilicate glassware components assembled by the user (depending upon the application), using appropriate clamps, stands, and supports. Most conventional distillation assemblies combine a round-bottomed distilling flask to contain and heat the liquid(s) that require purification, fitted with a stoppered or jointed neck to which is attached a downward-sloping, inclined side-arm for connection to a condensing unit to cool the heated vapors back down to their liquid state. Heating mantles are the preferred heat source for improved temperature control. These conventional distillation units are also available supplied complete and ready-assembled for added convenience and ease of use.
Specialized automated distillation equipment, notably units designed for the determination of volatile acidity and alcoholic strength by volume in wines, musts, and alcoholic beverages, and units designed for Kjeldahl nitrogen or protein determinations.
Chemglass Life Sciences Vacuum Trap Body Only, 40/50
Vacuum Trap Body Only, 40/50. Replacement part for CG451507 vacuum trap.
Ace Glass, Inc. Tube, distillation, trap-trap, 24/40 standard taper joints, 2mmglass stopcock, No-Air, Schlenk
Tube, distillation, trap-trap, 24/40 standard taper joints, 2mmglass stopcock, No-Air, Schlenk
Ace Glass, Inc. 12 SECTION SNYDER COLUMN 12 SECTION SNYDER COLUMN
12-section Snyder column for use in distillation applications. Column is floating ball type with 24/40 joints. Each section is approximately 51mm long.
Ace Glass, Inc. Vigreux column, 24/40, 18 inch effective length
Vigreux column, 24/40, 18 inch effective length
Chemglass Life Sciences Condenser, Reflux, 300mm, 24/40 Joint, 125mm Coil Length, GL-14 Screw Cap, Removable Hose Connections
Condenser, Reflux, 300mm, 24/40 Joint, 125mm Coil Length, GL-14 Screw Cap, Removable Hose Connections. Coil style reflux condenser with a large diameter jacket and coil, similar to CG-1213-L but with detachable hose connections. Connections are made of polypropylene and provide a safe and easy way of connecting and disconnecting flexible tubing to the condenser. Supplied complete with two GL open top screw caps and two bent polypropylene hose connections. Condensing area is the same as CG-1213-L.
Ace Glass, Inc. Receiver, moisture test, 10mL, 29/42
10mL moisture test receiver with 29/42 standard taper joint. Suitable for ASTM D 95 and E 123. Subdivided 0.1mL to 2.0mL, and 0.2mL above 2.0mL.
Chemglass Life Sciences Condenser, Liebig, 525mm, 29/42 Joint, 400mm Jacket Length
Condenser, Liebig, 525mm, 29/42 Joint, 400mm Jacket Length. Condenser has a standard taper outer joint at the top and a lower inner drip tip joint. Hose connections have an O.D. of 10mm at the middle serration.
Chemglass Life Sciences Condenser, Liebig, 520mm, 24/40 Joint, 400mm Jacket Length
Condenser, Liebig, 520mm, 24/40 Joint, 400mm Jacket Length. Condenser has a standard taper outer joint at the top and a lower inner drip tip joint. Hose connections have an O.D. of 10mm at the middle serration.
Chemglass Life Sciences Condenser, Liebig, 620mm, 24/40 Joint, 500mm Jacket Length
Condenser, Liebig, 620mm, 24/40 Joint, 500mm Jacket Length. Condenser has a standard taper outer joint at the top and a lower inner drip tip joint. Hose connections have an O.D. of 10mm at the middle serration.
Chemglass Life Sciences Condenser, 45/50 Joint, Reflux, 315 x 100mm
Condenser, 45/50 Joint, Reflux, 315 x 100mm. Compact high efficiency reflux condenser employs a double wall thimble shape bulb sealed into the outer jacket. Serrated hose connections for water connection extend through the outer bulb and have an O.D. of 10mm at the middle serration. While the overall height of this condenser is only 210-215mm, it has the efficiency of a standard 400mm Liebig or West condenser.
Chemglass Life Sciences Condenser, Double Coil, 895cm², High Efficiency, 45/50 Joints, 400 x 80mm, GL-14 Screw Caps, Removable Hose Connections
Condenser, Double Coil, 895cm¿, High Efficiency, 45/50 Joints, 400 x 80mm, GL-14 Screw Caps, Removable Hose Connections. High efficiency double coil condenser, similar to a rotary evaporator condenser but with 45/50 joints. Condenser has an O.D. of 80mm and is 400mm overall length. Coolant connections are made using removable hose connections with GL-14 threads. Supplied complete with two polypropylene hose connections and caps.
Chemglass Life Sciences Condenser, Gooseneck, Small, 24/40 Inner Joint, Distilling
Condenser, Gooseneck, Small, 24/40 Inner Joint, Distilling. Unique one-piece distilling condenser is actually a 75º adapter, highly efficient coil condenser and vacuum adapter in a compact one-piece unit. Available with a choice of three sizes of condensers with uptake inner joint as listed. Top thermometer joint is a 10/30 outer for use with a 3in immersion CG-3506 thermometer. Receiver joint on all sizes is a 24/40 inner having a sealed-in drip tip.
