Mechanical Sieves
Mesh device used to strain solids from liquids and manually separate particles by size; sieves can be constructed of metal or plastic. Products include sets, macro and micro sieve sizes, sifters and beads, etc.
What Is a Sieve?
Sieves are mesh strainers. They are typically round, with solid metal walls connected to a woven metal screen. They are often used with sieve receivers that collect the material that falls through the sieve. To prevent loss and contamination of the material, it can be protected by a sieve cover. Sieve covers are also necessary for covering the top sieve when multiple sieves are stacked on a laboratory shaker.
What Is Sieving?
Sieving is a technique for separating a sample into particles of different sizes. Sieving can be used to separate stones from sand and is used in the food industry to help eliminate contamination by foreign bodies.
Analysis by sieving may require a single sieve or a set of mesh sieves, arranged by decreasing size of the mesh openings. Air flow, liquid, vibration, or another mechanical method is used to move the sample particles through the screens.
Critical variables include sample size, agitation parameters, duration, and end point determination. Sample properties, like hygroscopic or electrostatic tendencies, can present analytical challenges, and some samples may need to be suspended in a liquid for accurate measurement.
Types of Sieves
Sieve frames and meshes may be stainless steel or brass. Common diameters are 3, 8, and 12 in. and 200 and 300mm; non-standard sieves may have other diameters, including 6, 10, and 18 in. Heights range from 1 to 9 in. and may be designated as full, intermediate, or half-height.
ASTM E-11 establishes criteria and tolerances for the openings in the woven wire mesh for standard sieve sizes. Some sieves are also traceable to NIST or must meet ISO 3310-1.
Chemglass Life Sciences Cell Screen, 400 Mesh, SST
Cell Screen, 400 Mesh, Stainless Steel . Component of the CLS-5020 Stainless Steel tissue grinder cel dissociation sieves. Pictured are the complete tissue grinders, but this item is cell screen only. 400 mesh is equivalent to 37 micron and 0.0015 inches.
Gilson Company Inc 8" All Stainless Sieve Pan, Full Height
Sieve Pan, 8in (203mm) diameter Stainless Steel full height Pan for ASTM E11 8in Test Sieves is placed at the bottom of a sieve stack to collect fines passing through the bottom sieve.
Gilson Company Inc 3in (76mm) diameter ASTM E11 Test Sieve, No. 200
3in (76mm) diameter ASTM E11 Test Sieve has stainless steel woven-wire cloth with No. 200 (75µm) openings and full height stainless steel frame. Overall height is 1-3/4in and stacked height is 1-1/8in. Features: Individually serial numbered, Compliant with ASTM E11 requirements for Compliance Sieves. Included Items: 3” Sieve, All Stainless, Full Height, No. 200, Certificate of Conformance to ASTM E11 requirements.
MSC Vermont Gage Plug Gage, 0.3310 in Diameter, 2.0000 in Overall Length, Tool Steel, Class ZZ Plus
This plug gage is designed for precise measurement and inspection applications. Made from durable tool steel, it features a Class ZZ Plus accuracy for reliable performance.
- Diameter of 0.3310 in.
- Overall length of 2.0000 in.
- Class ZZ Plus accuracy.
- Constructed from tool steel.
- Tolerance of 0.000200 in.
- 10 Micro coating/finish.
- Suitable for go inspection, setting micrometers, verniers, and other measuring devices.
- Includes a certificate of accuracy with NIST traceability.
- Manufactured to ASME B89.1 standards.
- Made in the United States.
Cole-Parmer 3"-Diameter Sieve, Full Height Stainless Steel, No. 70 (212)
For use with Cole-Parmer sieve shaker (59986-01), sold separately. Order optional stainless steel cover (59988-03) and full-height receiving pan (59988-07), sold separately.
Gilson Company Inc 3in (76mm) diameter ASTM E11 Test Sieve, No. 35
3in (76mm) diameter ASTM E11 Test Sieve has stainless steel woven-wire cloth with No. 35 (500µm) openings and full height stainless steel frame. Overall height is 1-3/4in and stacked height is 1-1/8in. Features: Individually serial numbered, Compliant with ASTM E11 requirements for Compliance Sieves. Included Items: 3” Sieve, All Stainless, Full Height, No. 35, Certificate of Conformance to ASTM E11 requirements.
Fritsch Milling And Sizing Inc Test Sieve 400/65 mm Mesh = 20 Astm (0,850 mm)
test sieve 400/65 mm mesh = 20 ASTM (0,850 mm)
Biodesign Inc of Ny CellMicroSieves, 25 micron pore size, 2 x 3 foot (61 x 91.5 cm) roll
CellMicroSieves (TM) filters manufactured by BioDesign Inc of New York allow the separation of multiple cell types using a filter that will not bind cells or proteins. Eleven pore sizes are available in sheets (3 sheets of 12 by 12 inches per package), rolls (2 feet by 3 feet), and 47mm circles (10 per package) that are extremely useful for specific cell type separation, stem cell isolation, hybridoma production, collection of cells from media, and many other uses where a strong non-binding specific sized pore filter is needed. Can be repeatedly steam sterilized retaining its pore size. A pure nylon thread product with no extractable materials that is specifially made for biologial research.
Fritsch Milling And Sizing Inc Sieve Insert P-15 1mm Trapez Perf., Chromium-Free Steel
Sieve insert p-15 1mm trapez perf., chromium-free steel
Sieve inserts determine the final fineness of a sample.
Sieve inserts with trapezoidal perforation and square perforations are offered. Sieve inserts with trapezoidal perforations improve size reduction through extra shearing action. Sieve inserts with square perforation are recommended for the grinding of brittle materials and materials of medium fineness with a narrow grain band.
For the sample preparation according to RoHS and WEEE (for the poof of hexavalent chromium) and for the XRF analysis we especially recommend chromium free steel ST12 sieve inserts.
For all other applications sieve inserts made of stainless steel may be used, since these are harder and therefore more resilient against abrasion.
Chemglass Life Sciences Cell Screen, 30 Mesh, SST
Cell Screen, 30 Mesh, Stainless Steel . Component of the CLS-5020 Stainless Steel tissue grinder cel dissociation sieves. Pictured are the complete tissue grinders, but this item is cell screen only. 30 mesh is equivalent to 595 micron and 0.0232 inches.
