PureAire Monitoring Systems PureAire Monitoring Systems Oxygen Monitor with 10 ft. Remote Sensor
SDP

Catalog No. 18222007
Change view
Click to view available options
Enclosure Material:
Polycarbonate
1 product options available for selection
Product selection table with 1 available options. Use arrow keys to navigate and Enter or Space to select.
Catalog No. Enclosure Material
18-222-007 Polycarbonate
Use arrow keys to navigate between rows. Press Enter or Space to select a product option. 1 options available.
1 options
Catalog No. 18-222-007 Supplier PureAire Monitoring Systems Supplier No. 99028
Only null left
Add to Cart
Add to Cart

Description

PureAire Monitoring Systems Air Check Oxygen Monitor with remote sensing capabilities

  • Perfect for use in a vacuum environment, OLED printer, nitrogen generator, or machines using nitrogen, and cryogenics
  • Sensor is connected to the monitor using a 3 meter cable for easy connection.
  • Remote controller can operate monitor at distances of up to 1,000 meters (0.6 miles)
  • Long-life zirconium sensor with average life of 10+ years
  • Two-Alarm setpoints for 19.5% and 18.0%
  • Built-in audible alarm 90 db
  • Digital display, and 4-20mA analog output
  • Wall mounting brackets
  • Remote Sensor up 10 ft away
  • CE marked. UL, and CUL approval
  • Simply secure the unit on the wall 1-2 meters from the gas source, plug it in, and power it on.
  • Levels are displayed clearly on the screen for easy access and visibility

Specifications

Temperature (Metric) Operating -40°C to +55°C
Accuracy ±1% of Full Scale
Calibration Factory Calibrated against a NIST Traceable Reference Standard
Certifications/Compliance CE Approval
Depth (English) 3.3 in.
Depth (Metric) 82.5 mm
Electrical Requirements 24 VDC
Enclosure Material Polycarbonate
Height (English) 4.5 in.
Height (Metric) 114.3 mm
Outputs 4-20 mA
Weight (English) 1.6 lb.
Weight (Metric) 0.8 kg
Width (English) 6.5 in.
Width (Metric) 165.1 mm
