Vernier Go Direct™ Mini GC

Teach students chromatography with an affordable, portable gas chromatograph that detects polar and nonpolar compounds. With the easy-to-use Go Direct™ Mini GC, free experiments from the included e-book, and the free Vernier Instrumental Analysis™ app, students can separate, analyze, and identify substances contained in a volatile liquid or gaseous sample.

Supplier:  Vernier GDXGC

Catalog No. S1724323

Description

Teach students chromatography with an affordable, portable gas chromatograph that detects polar and nonpolar compounds. With the easy-to-use Go Direct™ Mini GC and the free Vernier Instrumental Analysis™ app, students can separate, analyze, and identify substances contained in a volatile liquid or gaseous sample.

Go Direct™ Mini GC can connect via Bluetooth™ wireless technology or wired via USB to your device, providing an opportunity for you to choose the solution best for your laboratory.

Developed with Seacoast Science, Go Direct™ Mini GC uses an efficient, software-controlled internal pump system. This design allows the Go Direct™ Mini GC to use room air as the carrier gas, so there is no need to purchase an external carrier gas tank or maintain a gas filtration system.

Easily incorporate gas chromatography into your curriculum using our e-book Chromatography Experiments with the Go Direct Mini GC™ available for free with your purchase.

You can also use this gas chromatograph to identify unknown compounds, monitor chemical reactions, and measure products from a distillation.

Features

• Column - Restek™ MXT-502.2 Column – Siltek-treated stainless steel with proprietary diphenyl/dimethyl polysiloxane phase
• Detector - The unique Seacoast Science carbon-nanotube chemiresistor detector is compatible with air as the carrier gas and provides sensitivity to polar and nonpolar compounds.
• Utility - External power supply rated for 100–240 VAC, 1.5 A 50–60 Hz
• Carrier Gas - Ambient air
• Environmental Conditions - Temperature: 5°C to 40°C Humidity: 95% or less, (non-condensing environment)
• Liquid Injection Volume - 0.01 to 0.6 μL
• Operating Pressure - 1 to 21 kPa

Includes

• Go Direct Mini GC
• Mini USB Cable
• AC power supply
• Hamilton™ Syringe (1.0 μL volume)
• Two extra septa (a third septum is already installed)
• Chromatography Experiments with the Go Direct Mini GC™, an electronic lab book with five investigations, available as a free download from your Vernier account
• Carrying case

Specifications

• Grade: High School and College
• Material: Plastic
• Temperature Range (Metric): 30°C to 160°C with a maximum heating ramp of 10°C/min.
• Length (English): 4.25 in.
• Width (English): 5.24 in.
• Weight (English): 3 lb.

• Interface: Wireless: Bluetooth™ wireless technology; Wired: USB
• For Use With (Application): Chromatography - separate, analyze, and identify substances contained in a volatile liquid or gaseous sample
• Dimensions (L x W): 108 x 133 mm (4.25 x 5.24 in.)
• Length (Metric): 108 mm
• Width (Metric): 133 mm
• Electrical Requirements: 24 VDC, 2.5 A from an external power supply

Safety and Handling

WARNING: Cancer - www.P65Warnings.ca.gov
