Fisherbrand™ UV Crosslinker with Adjustable Height

Catalog No.	Electrical Requirements
13-245-222	230VAC 50/60Hz
13-245-221	120VAC 50/60Hz

Catalog No. 13-245-222

Description

Includes

Includes Five 254nm Bulbs (13-245-223)

Provides a safe, time-efficient solution with a controlled amount of ultraviolet radiation.

• Ideal for cross-linking DNA or RNA to membranes, in preparation for multiple probings of Southerns, Northerns, dot or slot blots
• The unit comes equipped with five 254nm Shortwave Bulbs
• No more manual calibration required when switching between wavelengths
• UV Crosslinker AH comes calibrated for 254nm Shortwave Bulbs as well as 306nm and 368nm bulbs
• Change your bulbs and select your bulb choice on the display
• Large UV protective window allows for easier process inspection
• Two modes of operation - Energy or Time
• Open Door Safety mechanism
• Energy Efficient electronic ballasts
• Small footprint
• Replacement bulbs available; see cat. no. 13-245-223

Certifications

CSA, UL listed, CE marked

Warranty and Services

Two years

Specifications

• Frequency: 50/60 Hz
• Voltage: 230VAC
• Certifications/Compliance: CSA, UL, CE
• Depth (English): 14.37 in.
• Depth (Metric): 36.4 cm
• Electrical Requirements: 230VAC 50/60Hz
• For Use With (Application): Cross linking dna or rna to membranes, in preparation for multiple probings of southern's, northern's, dot or slot blots
• Height (English): 10.25 in.
• Height (Metric): 26 cm
• Includes: Five 254nm shortwave bulbs
• Model: 234100-2
• Operating Modes: Energy or time
• Temperature Range (English): 60°F to 82°F
• Temperature Range (Metric): 16°C to 28°C
• Wattage: 80 w
• Weight (English): 30 lb.
• Weight (Metric): 13.6 kg
