Graphite
Electron Microscopy Sciences Graphene on Silicon Nitride with 2.5 µm holes, 6-8 layers, 2.1-2.8 nm thick, 78.5-83.2% Transparency
High quality graphene chemical vapor deposition graphene is layered on a silicon nitride TEM substrate. The substrate is 200 um thick 3.0mm hexagonal silicon with a 0.5 x 0.5 mm aperture and 200 nm thick silicon nitride membrane with approximately 6,400 2.5 um holes. Graphene coverage of the TEM grid is better than 75 percent.
The substrate is a solid hexagonal disk with a greenish hue. The graphene film appears as a near-transparent to light-grey film on the surface of the microporous Silicon Nitride membrane.
Layers: 6-8 layers
Thickness: 2.1-2.8 nm
Transparency: 78.5-83.2%
Electron Microscopy Sciences Graphene on Silicon Nitride with 2.5 µm holes, 1 layer, 0.35 nm thick, 96.4% Transparency
High quality graphene chemical vapor deposition graphene is layered on a silicon nitride TEM substrate. The substrate is 200 um thick 3.0mm hexagonal silicon with a 0.5 x 0.5 mm aperture and 200 nm thick silicon nitride membrane with approximately 6,400 2.5 um holes. Graphene coverage of the TEM grid is better than 75 percent.
The substrate is a solid hexagonal disk with a greenish hue. The graphene film appears as a near-transparent to light-grey film on the surface of the microporous Silicon Nitride membrane.
Layers: 1 layer
Thickness: 0.35 nm
Transparency: 96.4%
Strem, An Ascensus Company CAS# 7440-44-0. 2kg. Activated carbon. MFCD00133992
CAS# 7440-44-0. 2kg. Activated carbon. MFCD00133992. Molecular Weight: 12.011. Molecular Formula: C. Color/form: 4 x 10 mesh black gran. Strem# 06-0050. http://www.strem.com/catalog/v/06-0050/
Sigma Aldrich Fine Chemicals Biosciences Activated charcoal suitable for cell culture, suitable for plant cell culture | 7440-44-0 | MFCD00133992 | 500G
Activated charcoal suitable for cell culture, suitable for plant cell culture | Mol Wt: 12.01 | 7440-44-0 | MFCD00133992 | 500G
Electron Microscopy Sciences Pyrolytic Graphite Stripper Film, 5 µm thick, 25.4 mm x 25.4 mm, 1.0 mg /sq cm pressure
Smooth pyrolytic graphite stripper film is used in radiation sources, nuclear particle high energy density research, and medical diagnostic imaging instruments Pyrolytic graphite film offers major customer benefits relative to alternative materials such as amorphous carbon film or polycrystalline graphite films. These result in higher strength than alternative materials and films last 5 times longer than alternative materials.
Size: 25.4 mm x 25.4 mm
Thickness: 5 µm
Pressure: 1.0 mg /sq cm
Sigma Aldrich Fine Chemicals Biosciences Activated charcoal | 7440-44-0 | MFCD00133992 | 175g
Activated charcoal | powder, -100 particle size (mesh), decolorizing | MW:12.01 | 7440-44-0 | MFCD00133992 | 175g
Electron Microscopy Sciences Synthesized Graphene Powder
Graphene is the ideal support film for electron microscopy. It provides an invisible, crystalline background that enables the unrivaled TEM characterization of organic and inorganic nanomaterials. Graphene is atomically thin, chemically inert, consists of light atoms, and possesses a highly ordered structure. Graphene is electrically and thermally conductive, and is the strongest material ever measured.
We offer ultrahigh-quality graphene that is produced through the substrate-free gas-phase method which results in a highly ordered structure that is composed of 99% carbon by mass (1% hydrogen).
Sigma Aldrich Fine Chemicals Biosciences Activated charcoal NORIT ROW 0.8 SUPRA, pellets | 7440-44-0 | MFCD00133992 | 500g
Activated charcoal NORIT ROW 0.8 SUPRA, pelletsPurity: | MW: 12.01 | 7440-44-0 | MFCD00133992 | 500g
Sigma Aldrich Fine Chemicals Biosciences Activated charcoal suitable for cell culture, suitable for plant cell culture | 7440-44-0 | MFCD00133992 | 2.5KG
Activated charcoal suitable for cell culture, suitable for plant cell culture | Mol Wt: 12.01 | 7440-44-0 | MFCD00133992 | 2.5KG
Electron Microscopy Sciences Graphene on Silicon Nitride with 2.5 µm holes, 3-5 layers, 1.0-1.7 nm thick, 85.8-90.4% Transparency
High quality graphene chemical vapor deposition graphene is layered on a silicon nitride TEM substrate. The substrate is 200 um thick 3.0mm hexagonal silicon with a 0.5 x 0.5 mm aperture and 200 nm thick silicon nitride membrane with approximately 6,400 2.5 um holes. Graphene coverage of the TEM grid is better than 75 percent.
The substrate is a solid hexagonal disk with a greenish hue. The graphene film appears as a near-transparent to light-grey film on the surface of the microporous Silicon Nitride membrane.
Layers: 3-5 layers
Thickness: 1.0-1.7 nm
Transparency: 85.8-90.4%
Electron Microscopy Sciences Graphene on Silicon Nitride with 2.5 µm holes, 2 layers, 0.7 nm thick, 92.7% Transparency
High quality graphene chemical vapor deposition graphene is layered on a silicon nitride TEM substrate. The substrate is 200 um thick 3.0mm hexagonal silicon with a 0.5 x 0.5 mm aperture and 200 nm thick silicon nitride membrane with approximately 6,400 2.5 um holes. Graphene coverage of the TEM grid is better than 75 percent.
The substrate is a solid hexagonal disk with a greenish hue. The graphene film appears as a near-transparent to light-grey film on the surface of the microporous Silicon Nitride membrane.
Layers: 2 layers
Thickness: 0.7 nm
Transparency: 92.7%
Electron Microscopy Sciences SEM Pyrolytic Graphite Planchet 12.7 x 3.2 mm, 3.2 mm thick
For SEM. Very light weight, 5'9's pure, solid crystal with no granular components. Withstands cryogenic and temperatures in excess of 3000 degree C. Smooth surface polished to 1 micron glassy finish.
Diameter: 12.7
Thickness: 3.2 mm
Sigma Aldrich Fine Chemicals Biosciences Activated Charcoal meets USP testing specifications | 7440-44-0 | MFCD00133992 | 125G
Activated Charcoal meets USP testing specifications | Mol Wt: 12.01 | 7440-44-0 | MFCD00133992 | 125G
Sigma Aldrich Fine Chemicals Biosciences Activated Charcoal Norit(R) Norit CA1, wood, chemically activated, powder | 7440-44-0 | MFCD00133992 | 1KG
Activated Charcoal Norit(R) Norit CA1, wood, chemically activated, powder | Mol Wt: 12.01 | 7440-44-0 | MFCD00133992 | 1KG
