Square or Rectangle Cuvettes and Cells
Fireflysci Type 9 Semi-Micro Cuvette with PTFE Cover (Material: UV Quartz) (Lightpath: 40mm)
Type 9 Semi-Micro Cuvette with PTFE Cover (Material: UV Quartz) (Lightpath: 40mm)• Cuvette has an open top with a PTFE lid which rests on the top• Material is UV Quartz (transmits over 80% between 190-2,500nm)• Two windows optically polished• Lightpath is 40mm• Outside dimensions 42.5x12.5x45mm• Inside Dimensions- 40x4x45mm• Capacity- 5.6mL
Fireflysci Type 9FLP Disposable Semi-Micro Fluorescence Cuvettes (Lightpath: 10mm) (Material: PMMA)
Type 9FLP Disposable Semi-Micro Fluorescence Cuvettes (Lightpath: 10mm) (Material: PMMA)• Cuvette has an open top with optional push caps that fit into the top (part # for the caps is PLCAPS100)• Comes in a box of 100• Material is PMMA (transmits over 80% between 285-900nm)• Four windows and the base optically polished• Lightpath is 10mm• Outside dimensions 12.5x12.5x45mm• Inside Dimensions- 10x4x45mm• Capacity- 1.5mL
Fireflysci Type 20 Demountable O-Shaped Circular Dichroism Cuvette (Material: IR Quartz) (Lightpath: 1mm)
Type 20 Demountable O-Shaped Circular Dichroism Cuvette (Material: IR Quartz) (Lightpath: 1mm)• Cuvette is a o-shaped demountable spectrophotometer cuvette with a removable window• Sample can be pipetted on the grooved slide and cover slide placed on top• Cover slide is 1.25mm thick • Material is IR Quartz (transmits over 80% between 220-3,500nm)• Two windows optically polished• Lightpath is 1mm• Outside dimensions 3.5x12.5x45mm• Inside Dimensions- 1x10x38mm• Capacity- 360µL
Fireflysci Type 61 Macro Cuvette with Graded Seal Tube (Material: UV Quartz) (Lightpath: 10mm)
Type 61 Macro Cuvette with Graded Seal Tube (Material: UV Quartz) (Lightpath: 10mm)• Cuvette has a graded seal tube on top with a quartz-to-pyrex bond. Additional Pyrex Glass structures can be fused to the top• Material is UV Quartz (transmits over 80% between 190-2,500nm)• Two windows optically polished• Lightpath is 10mm• Outside dimensions 12.5x12.5x125mm• Inside Dimensions- 10x10x45mm• Capacity- 3.5mL
Fireflysci Type 4 Micro Fluorescence Cuvette with PTFE Cover (Material: UV Quartz) (Lightpath 5X5X33mm)
Type 4 Micro Fluorescence Cuvette with PTFE Cover (Material: UV Quartz) (Lightpath 5X5X33mm)• Cuvette has an open top with a PTFE lid which rests on the top• Material is UV Quartz (transmits over 80% between 190-2,500nm)• Four windows and the base optically polished for fluorescence measurements• Lightpath is 5x5x33mm• Outside dimensions 7.5x7.5x33mm• Inside Dimensions- 3x3x40mm• Capacity- 0.64mL. *Does not come with the black holder/adapter.*
Azzota Corp 40mm Pathlength Standard Fluorometer Cuvette, 14Ml, Glass
40mm Pathlength Standard Fluorometer Cuvette, 14ml, Glass
Fireflysci Type 701M Sub-Micro Cuvette (Material: Black UV Quartz) (Lightpath: 10mm) (Z-Dimension: 8.5mm) (Capacity: 100ul)
Type 701M Sub-Micro Cuvette (Material: Black UV Quartz) (Lightpath: 10mm) (Z-Dimension: 8.5mm) (Capacity: 100µl)• Cuvette has an open top with a PTFE threaded stopper which pushes into the top• Material is UV Quartz (transmits over 80% between 190-2,500nm)• Black quartz is to block out and absorb any stray light• Two 2x5mm windows optically polished• Lightpath is 10mm• Outside dimensions 12.5x12.5x45mm• Inside Dimensions- 10x2x5mm• Capacity- 100µl
Fireflysci Type 29 Semi-Micro Cuvette with PTFE Stopper (Material: UV Quartz) (Lightpath: 10mm)
Type 29 Semi-Micro Cuvette with PTFE Stopper (Material: UV Quartz) (Lightpath: 10mm)• Cuvette has an airtight PTFE stopper which plugs into the top• Material is UV Quartz (transmits over 80% between 190-2,500nm)• Two windows optically polished• Lightpath is 10mm• Outside dimensions 12.5x12.5x55mm• Inside Dimensions- 10x4x45mm• Capacity- 1.4mL
Fireflysci Type 1 Macro Cuvette with PTFE Cover (Material: IR Quartz) (Lightpath:100mm)
Type 1 Macro Cuvette with PTFE Cover (Material: IR Quartz) (Lightpath: 100mm)• Cuvette has an open top with a PTFE lid which rests on the top• Material is IR Quartz (transmits over 80% between 220-3,500nm)• Two windows optically polished• Lightpath is 100mm• Outside dimensions 102.5x12.5x45mm• Inside Dimensions- 100x10x45mm• Capacity- 35mL
Fireflysci Type 18 Standard Micro Cuvette with PTFE Cover (Material: Optical Glass) (Lightpath: 10mm)
Type 18 Standard Micro Cuvette with PTFE Cover (Material: Optical Glass) (Lightpath: 10mm)• Cuvette has an open top with a PTFE lid which rests on the top• Material is Optical Glass (transmits over 80% between 340-2,500nm)• Two windows optically polished • Lightpath is 10mm• Outside dimensions 12.5x12.5x45mm• Inside Dimensions- 10x2x45mm• Capacity- 0.7mL
Fireflysci Type 21 Macro Cuvette with PTFE Stopper (Material: UV Quartz) (Lightpath: 1mm)
Type 21 Macro Cuvette with PTFE Stopper (Material: UV Quartz) (Lightpath: 1mm)• Cuvette has an airtight PTFE stopper which plugs into the top• Material is UV Quartz (transmits over 80% between 190-2,500nm)• Two windows optically polished• Lightpath is 1mm• Outside dimensions 3.5x12.5x55mm• Inside Dimensions- 1x10x45mm• Capacity- 0.4mL
Fireflysci Type 1 Macro Cuvette with PTFE Cover (Material: Optical Glass) (Lightpath: 2mm)
Type 1 Macro Cuvette with PTFE Cover (Material: Optical Glass) (Lightpath: 2mm)• Cuvette has an open top with a PTFE lid which rests on the top• Material is Optical Glass (transmits over 80% between 340-2,500nm)• Two windows optically polished• Lightpath is 2mm• Outside dimensions 4.5x12.5x45mm• Inside Dimensions- 2x10x45mm• Capacity- 0.7mL
Cole-Parmer Jenway Disposable Plastic Cuvettes, Visible, 2.4 to 4.5 mL, 10 mm Path; 100/PK
Find cuvettes, a cuvette rack, and the replacement lamp for your colorimeter.
BYK Gardner P-Glass Cuvette, Square, 10 x 10 mm
For color measurement of liquids square, rectangle and cylindrical cuvettes can be used. Both precision as well as inexpensive disposable tubes are available. The precision cuvettes ensure reproducible results – even for critical solutions as clear as water. For daily QC disposable cuvettes save time and money.
