Pump Parts and Accessories
Chemglass Life Sciences Graded Seal, 1/2in OD Kovar to Borosilicate
Graded Seal, 1/2in OD Kovar to Borosilicate. For connection of borosilicate glass components to metal. Kovar length is approximately 25mm on all sizes, while the borosilicate tubing is approximately 100mm.
Chemglass Life Sciences #50 Internal Bushing, Open Top, 49mm Opening, PTFE, #225 Viton O-Ring
#50 Internal Bushing, Open Top, 49mm Opening, PTFE, #225 Viton O-Ring. Bushing for use with CG-360 internal glass threads. Supplied with one Viton o-ring.
Chemglass Life Sciences Vacuum Trap, Serrated Hose Connections, Complete, Trap Bottle is 32mm Body OD x 200mm Overall Length, 29/42 Jt.
Vacuum Trap, Serrated Hose Connections, Complete, Trap Bottle is 32mm Body OD x 200mm Overall Length, 29/42 Jt. Two piece construction for easy removal of condensate. Inlet and outlet are 180º apart for installation into a variety of vacuum systems. Stopper has a standard taper inner joint and body has an outer joint. Body length is the overall length from the top of the joint to the bottom of the round bottom. Serrated hose connections have an O.D. of 13mm at the smallest serration and 16mm at the largest serration.
Chemglass Life Sciences Valve, Chem-Vac™, Chem-Cap, Hi-Vac, Metering, 90, 0-4mm Bore
Valve, Chem-Vac™, Chem-Cap, Hi-Vac, Metering, 90, 0-4mm Bore. CHEM-VAC™ CHEM-CAP metering valve has an extended tip on the plug to allow semi-needle valve control of gases and liquids. Valve has two sidearms sealed to the barrel at a 90 angle to one another. See CG-971 for replacement CHEM-CAP metering plug and CG-903 for glass portion only.
Chemglass Life Sciences PTFE Seal only, fits GL-18 Cap
PTFE Seal only, fits GL-18 Cap. Cap is made from PBT (thermoplastic polyester) and will withstand temperatures from -45 to 200º C. PTFE seal is also available separately.
Chemglass Life Sciences PTFE Seal only, fits GL-14 Cap
PTFE Seal only, fits GL-14 Cap. Cap is made from PBT (thermoplastic polyester) and will withstand temperatures from -45 to 200º C. PTFE seal is also available separately.
Chemglass Life Sciences PTFE Gasket for Stainless Steel Lid, 300mm
PTFE Gasket for Stainless Steel Lid, 300mm. Stainless steel, 7 openings. Component of 1968B01.
Chemglass Life Sciences 10mm PTFE Gasket
10mm PTFE Gasket. PTFE gasket is 0.015" thick with an opening to fit Chemglass stirrer shafts. Gasket is placed below the CG-2048 Safety collar to prevent wear as a result of the collar rotating against the stirrer bearing. Also useful as a dust cover. SOLD 12/PKG.
Chemglass Life Sciences 30mm PTFE Gasket
30mm PTFE Gasket. PTFE gasket is 0.015" thick with an opening to fit Chemglass stirrer shafts. Gasket is placed below the CG-2048 Safety collar to prevent wear as a result of the collar rotating against the stirrer bearing. Also useful as a dust cover. SOLD 12/PKG.
Chemglass Life Sciences Silicone Seals, For Duran Filtering Flask
Replacement silicone seals for Duran filter flasks. Sold in packs of 10.
Electron Microscopy Sciences Edwards EMF3 Oil Mist Filter
Oil mist filters help with exhaust mist from the vacuum pump which sticks to any surface that it touches and becomes a dust magnet. Mist filters capture oil mist from the outlet of pumps, which would otherwise be ejected into the atmosphere. This may happen with gas ballast or when pumping at high gas throughputs. You can also return oil trapped in the mist filter back to the pump, although you must ensure that the process gases will not contaminate the pumpor pump oil.
Protection from oil mist emissions as required by COSHH and health and safety regulations. Use of optional oil return kits results in reduced oil level maintenance and savings in pump oil and if the oil element becomes blocked. An integral pressure relief valve opens. For the E2M1.5.
Electron Microscopy Sciences Vacuum Pump Exhaust Filter including adapter
Vacuum pump exhaust filters for vacuum rotary vane pumps remove all visible oil mist and smoke from vacuum pump exhaust, even when it is saturated with oil. The high efficiency filter cartridge continuously drains the collected liquid, allowing recovery of expensive lubricating fluid. Filters are for pumps with flow ratings ranging of 3 cfm in non-hazardous/non-corrosive applications. Port size is 1/2" NPT.
The filter eliminate 99% oil mist and smoke from vacuum pump exhaust and prevents oil accumulation in ductwork. Expensive lubricating oils is automatically returned to pump. Using the filter will eliminate potential OSHA and EPA violations.
Specifications
Maximum Flow Rate: 3 CFM.
Material: Nylon. Maximum Seals: None.
Maximum Temperature: 121 C.
Shipping Pressure: 15PSIG.
Dimensions: 2" Dia. x 3.7" H.
Weight: .25lbs (0.1kg).
Electron Microscopy Sciences Lyophilization Complete Tear Off Seals, 13 mm I.D., 20 mm O.D.
Aluminum lyophilization seals are unlined. Seal can be completely removed. Fits mouth ID 13mm x OD 20mm.
Electron Microscopy Sciences Lyophilization Three Leg Stoppers for 13mm ID, 20 mm O.D.
Manufactured from the highest quality raw materials. Fits mouth with:
I.D.: 13 mm
O.D.: 20 mm
Material: Gray chlorobutyl/50
Electron Microscopy Sciences Lyophilization Two Leg Stoppers for 13mm ID, 20 mm O.D.
Manufactured from the highest quality raw materials. Fits mouth with:
I.D.: 13 mm
O.D.: 20 mm
Material: Gray chlorobutyl/50
