HPLC Columns
Waters Corp CORTECS Premier T3 VanGuard FIT Column, Reversed Phase, 2.7 μm, 2.1 x 100 mm
The CORTECS Premier T3 VanGuard FIT Column is a high-performance liquid chromatography column for reversed-phase separations. It features a 2.7 μm silica particle with T3 bonding technology for robust retention of analytes. This column integrates MaxPeak High Performance Surface hardware to mitigate interactions and a VanGuard FIT design for extended lifetime.
- Compatible with 100% aqueous mobile phases.
- High efficiency and reduced backpressure.
- Ultra-low column MS bleed, long lifetimes, and excellent peak shape.
- MaxPeak High Performance Surface technology minimizes unwanted analyte interactions.
- VanGuard FIT design protects against contaminants, removes particulate and chemical contamination, and extends column longevity.
- Ensures consistent connections and easy installation with a quarter-turn.
- Quickly restores performance by replacing the VanGuard FIT Cartridge.
Waters Corp Tubing Kit, Stainless Steel, UPLC, 6 Column
This tubing kit contains stainless steel tubing assemblies for implementing CM-A active column managers onto an ACQUITY H-Class PLUS system. It supports a six-column configuration and can also be used to replace existing stainless steel tubing in this setup. The kit includes the relevant Active Preheater for a PLUS system.
- Designed for UPLC system configurations
- Suitable for Arc Premier, UPLC H-Class, and Patrol instruments
- Replaces stainless steel tubing in six-column setups
- Includes an active preheater for PLUS systems
Waters Corp Shodex Column, 7 μm, 8 mm ID, 300 mm Length
The Shodex KW-804 Column is a high-performance Gel Filtration column primarily designed to support legacy methods. It features Diol (OH) chemistry and utilizes Size Exclusion Chromatography (SEC) for separation. This column is built with a spherical silica particle substrate and is ideal for HPLC systems, especially for protein applications.
- Diol (OH) chemistry
- Utilizes Size Exclusion Chromatography (SEC) separation mode
- Spherical silica particle substrate
- Particle size of 7 μm
- Supports pH range of 2 to 8
- Inner diameter of 8 mm
- Length of 300 mm
- Parker-style endfitting
- Packed with water as the solvent
- Designed for HPLC systems
- Classified under USP L20
- Intended for protein applications
- Each package contains 1 column
Waters Corporation ACQUITY UPLC Column, 1.7 μm, 2.1 mm, 150 mm
The ACQUITY BEH C8 sorbent provides improved peak shape and enhanced chromatographic performance. Its trifunctionally bonded BEH particles offer a wide usable pH range (1 to 12), superior low pH stability, and ultra-low column bleed.
- Less retentive than ACQUITY BEH C18 sorbent
- Wide usable pH range: 1 to 12
- Superior low pH stability and ultra-low column bleed
- Chemistry: C8, Reversed Phase separation mode
- Particle substrate: Hybrid, Spherical shape
- Particle size: 1.7 μm
- Pore size: 130 Å
- Maximum pressure: 18000 psi (1240 bar)
- Inner diameter: 2.1 mm, Length: 150 mm
- Units per package: 3 pk
- eCord enabled
Waters Corp CORTECS Phenyl Column, 90à , 1.6 µm, 3 mm X 100 mm, 3/pk
CORTECS Phenyl Column, 90à , 1.6 µm, 3 mm X 100 mm, 3/pk
Waters Corp XBridge Premier BEH Phenyl Column, 3.5 μm, 4.6 x 100 mm, 1 pk
These XBridge Premier BEH Phenyl 3.5 μm, 4.6 x 100 mm columns offer complementary selectivity for polyaromatic compounds. Featuring a highly stable phenyl sorbent, they ensure ultra-low column bleed, extended lifetimes, and excellent peak shape. MaxPeak Premier hardware minimizes analyte/surface interactions, preventing poor peak shape and signal loss.
- Reversed phase separation.
- Hybrid, spherical particles with low silanol activity.
- pH range of 1 to 12; temperature limits up to 80°C (low pH) or 60°C (high pH).
- Maximum pressure: 6000 psi (415 bar).
- Endcapped with phenyl-hexyl bonding technology.
- 130 Å pore size and 185 surface area.
- Parker-style endfitting.
- Designed for HPLC and LC, USP classification L11.
- 15% carbon load, suitable for small molecules.
Waters Corp XBridge Peptide BEH C18 Prep Guard Cartridge, 130à , 10 µm, 30 mm X 10 mm, 1K - 15K, 1/pk
XBridge Peptide BEH C18 Prep Guard Cartridge, 130à , 10 µm, 30 mm X 10 mm, 1K - 15K, 1/pk
Waters Corp Preparative Column, C4, 300 Å, 10 μm
These protein BEH C4 OBD columns are quality control (QC) tested and optimized for the separation of proteins based on size, hydrophobicity, and isoelectric point. Featuring a trifunctional C4 ligand, fully end-capped and bonded to ethylene-bridged hybrid (BEH) particles, they offer less retention compared to traditional C18 phases, which helps to minimize protein carryover, increase protein recovery, and improve peak capacity.
- Trifunctional C4 ligand, fully end-capped.
- QC tested with protein standards for reproducible performance.
- Less retentive than traditional silica-based C18 phases.
- Minimizes protein carryover, increases protein recovery, and improves peak capacity.
- Particle size: 10 μm.
- Pore size: 300 Å.
- pH range: 1 to 10.
- Maximum pressure: 6000 psi (415 Bar).
- Dimensions: 19 mm inner diameter, 250 mm length.
Waters Corp Waters CSH Fluoro-Phenyl Column, 130Å, 3.5 μm, 4.6 mm × 75 mm
This column is designed to maximize selectivity differences and provides method development freedom, especially with low pH mobile phases. Its non-encapped sorbent enhances the retention of acidic compounds.
- Chemistry: PFP/Fluoro-Phenyl
- Separation mode: Reversed Phase
- Particle substrate: Hybrid
- pH range: 1 to 8
- Maximum pressure: 6000 psi (415 Bar)
- Endcapped: No
- Silanol activity: Low
- Particle shape: Spherical
- System: HPLC
- Particle technology: CSH
- USP classification: L43
- Carbon load: 10%
- Units per package: 1 package
Waters Corp Bondapak C18 Radial-Pak Column, 125Å, 15 - 20 µm, 8 mm X 100 mm, 1/pk
Bondapak C18 is available in two different particle sizes, 15-20µm and 37-55µm, providing easy method transfer from µBondapak through preparative scale up. If you are developing a new purification protocol, Bondapak provides the best balance between resolution, throughput and cost.
Waters Corp Torus 2-PIC OBD Prep Column, 130Å Pore, 5 μm, 50 × 150 mm
The Torus 2-PIC OBD Prep Column is engineered to enhance the efficiency of the ACQUITY UPC2 system for swift and dependable achiral separations. This column simplifies the method development process, provides excellent peak shape, and reduces or eliminates the need for additives, while offering additional selectivity for various compounds and improving robustness.
- Specifically designed to utilize the full power of the ACQUITY UPC2 system for fast and robust achiral separations.
- Simplifies the method development process.
- Provides excellent peak shape.
- Eliminates or reduces the need for additives.
- Offers additional selectivity for a broad range of compounds.
- Ensures improved robustness.
Waters Corp Viridis OBD Prep Column, 2-Ethylpyridine, 130Å, 5 μm
These Supercritical Fluid Chromatography (SFC) columns are engineered for enhanced reproducibility in laboratory-scale purification. They integrate state-of-the-art media manufacturing with industry-leading column technology, suitable for analytical and preparative chromatography.
- Utilizes Optimum Bed Density (OBD) Technology for mechanical stability and extended column lifespan.
- Offers achiral SFC selectivities with particle technologies like Ethylene Bridged Hybrid (BEH) and Charged Surface Hybrid (CSH).
- Achieves excellent peak geometries for basic achiral chemicals under SFC conditions by reducing surface silanol activity.
- Produced in specialized facilities adhering to cGMP and ISO 9001 standards, ensuring high-quality manufacturing.
Waters Corp Preparative SFC Column, Viridis Silica, 5 μm, 10 × 250 mm
The Viridis Silica column with a 5 μm particle size is a Preparative SFC Column. It has dimensions of OBD 10 × 250 mm. Viridis Silica Columns are designed for achiral SFC separations and are known for exhibiting good retention, peak shape, and selectivity properties.
- Highly reproducible and predictable due to tight product specifications.
- Very low metal content.
- Available for both analytical screening and in preparative dimensions for purification.
- Allows for optimization and scaling up of separation methods to preparative OBD columns.
Waters Corp CORTECS Column, C18, 90Å, 2.7 μm, 3 mm X 30 mm
CORTECS C18 Columns are general purpose, high-efficiency columns based on a solid-core particle that offer balanced retention of acids, bases and neutrals at low and mid-range pH.
- Chemistry: C18
- Separation mode: Reversed Phase
- Particle substrate: Silica
- pH range: 2 pH to 8 pH
- Temperature limits: 45°C
- Maximum pressure: 18000 psi (1240 Bar)
- Endcapped: Yes
- Silanol activity: Low
- Particle shape: Spherical
- Particle size: 2.7 μm
- Endfitting type: Parker-style
- Pore size: 90 Å
- Format: Column
- Surface area: 100
- System: HPLC
- Particle technology: Solid Core
- USP classification: L1
- Inner diameter: 3 mm
- Length: 30 mm
- Carbon load: 6.6 %
- eCord: Yes
- Units per package: 3 pk
