Sample Vials
Tubes and vials for general collection, storage, and transportation of samples; available in a variety of colors, sizes, volume capacities, and material compositions; may be sterile, non-sterile, and/or autoclavable; may include caps.
The term “vial” is somewhat undefined and is usually described as a small, cylindrical, and flat-bottomed container used to hold liquids. Most sample vials are made of plastic or glass, and include a separate or attached lid or closure. Sample vials are categorized by material and also by their size or specific purpose.
Glass sample vials are categorized by the type of glass used to make them.
- Type I, Class A glass sample vials are made from low-expansion borosilicate glass
- Type I, Class B glass sample vials are made from an alumino-borosilicate glass
- Type II are made from soda-lime glass
Plastic sample vials may be made from a variety of resins, including:
- Polycarbonate
- Polypropylene
- Polystyrene
- Low-density polyethylene (LDPE)
- High-density polyethylene (HDPE)
Glass sample vials may be clear or amber-colored (to protect the contents from ultraviolet light). Plastic sample vials are available in a range of colors, including amber, natural, and clear resins.
Sample vials may have different types of closures, depending on their use and the material being stored.
- Screw caps
- For both glass and plastic sample vials
- May be closed or open
- Typically made from polypropylene or phenolic resin (with a variety of closure liners, including PE foam, PTFE, cork, tin, etc.)
- Flip-top
- Caps for plastic sample vials may be attached by a tether to the vial itself
- Also called “captive” closures
- Snap caps (external): Both glass and plastic sample vials
- Plug caps (internal): Both glass and plastic sample vials
Stellar Scientific 2.0ML POLYPROPYLENE STANDING M
2.0mL Polypropylene Standing Micro Tube With Molded Graduations And O-Ring Screw-Cap, RNase/DNase Free and STERILE, 1000/CS
Anton Paar 12 ml glass vials (100 pcs)
Pack of 100 glass vials used with a sample changer (Anton Paar Xsample series) to automatically fill up to 12 mL of sample into your Anton Paar measuring instrument.Recommended Cap Standard Cap for 12 ml Vials NC9145272 or High Temperarure Cap for 12 ml Vials NC9035965
Chemglass Life Sciences Vial, Sample, Pre-Cleaned, 40mL, Amber, 28x95mm, GPI 24-400, with PTFE Lined Screw Cap
Vial, Sample, Pre-Cleaned, 40mL, Amber, 28x95mm, GPI 24-400, with PTFE Lined Screw Cap. Clear and amber sample vials are pre-cleaned and certified for volatile organic analysis. Vials are fully assembled with green polypropylene closure and 0.125” PTFE silicone septa. Made from Type 1 borosilicate glass. Certificate of analysis is included in each case. Packed 72 pieces per case.
Microsolv Technology Corporation Vials, Push Top, Storage, Glass, Clear, 15ml. Economical, with ND22 tops. For use with Econo-Storage Push Top Caps. 100/PK.
These Vials are made with 3rd Hydrolytic Glass and quickly open and reseal due to the "Snap" design. These 15ml Vials have a total fill volume of 19.3ml with 48x26mm outer dimensions. Not made for Crimp Caps. Caps for these Vials, sold separately. These vials are not intended for Analytical Testing and should only be used for Storage. Low cost for budget minded laboratories.
Bellco Glass, Inc. Freeze-Dry Ampoule, 2mL Tubular
Type 1 class a Borosilicate glass ideal for freeze drying or cryogenic storage. Tubular firing off constriction on the neck. Rigidly controller bottom to withstand pressure at low temperature.. MADE IN THE USA Tubular round bottom Length:145mm Neck od: 8mm Capacity: 2ml
Microsolv Technology Corporation Vials, Push Top, Storage, Glass, Clear, 5ml. Economical, with ND18 tops. For use with Econo-Storage Push Top Caps. 100/PK.
These Vials are made with 3rd Hydrolytic Glass and quickly open and reseal due to the "Snap" design. These 5ml Vials have a total fill volume of 9.1ml with 40x20mm outer dimensions. Not made for Crimp Caps. Caps for these Vials, sold separately. These vials are not intended for Analytical Testing and should only be used for Storage. Low cost for budget minded laboratories.
Chemglass Life Sciences Vial, 1.5mL, Clear, Large Opening, 12x32mm, 9mm Thread, High Recovery
Vial, 1.5mL, Clear, Large Opening, 12x32mm, 9mm Thread, High Recovery. With a 40% larger opening, this vial is specifically designed to work in robotic arm auto samplers. They also incorporate the unique Step Vial design that precisely centers a limited volume insert in the neck of the vial.
Chemglass Life Sciences Vial, 2.0mL, Clear with White Grad Spot, Standard Opening, 12x32mm, GPI 8-425
Vial, 2.0mL, Clear with White Grad Spot, Standard Opening, 12x32mm, GPI 8-425. Standard opening screw thread vials contain a narrow opening allowing the use of GPI 8-425 closures and septa. This vial is designed to work in a variety of auto samplers requiring narrow neck vials. Available with graduated marking spots and silanized.
Bellco Glass, Inc. Glass Flat Bottom Vial, 1.0mL
DescriptionThis vial is made of clear borosilicate glass and has flat bottom. Sample capacity of 1.0mL, 9mm in diameter, and 30mm in height. Vials compatible with our Multi-Tier Plate System. 100 vials per case.Multi-Tier Plate System, is an adaptable, and reusable system, which features a versatile 96 well base plate that can secure vials ranging from 0.5mL to 2.5mL and the ability to isolate individual vials as needed.The ANSI footprint ensures compatibility with all autosamplers and robotic systems.Product DetailsColor: Clear GlassSize: 9x30mmVolume: 1mLSilanized: NoBottom: FlatCase Quantity: 100Country Of Origin: USA
Chemglass Life Sciences Vial Only, Sample, 3.7mL, Clear, High Recovery, 15x45mm, GPI 13-425
Vial Only, Sample, 3.7mL, Clear, High Recovery, 15x45mm, GPI 13-425. High recovery vial with a conical bottom for complete sample recovery. These vials are the same size or slightly smaller on the OD to allow them to be interchanged with any racks or blocks that accept standard dram or scintillation vials. Packed in an SBS coated white tray complete with SBS partition. Boxes are marked with alpha-numeric coordinates for fast and easy vial identification. Vial only.
Bellco Glass, Inc. 3 mL Sterile Disposable Sampler Tubes with Caps on Sterile 50/pk 1000/cs
3 mL Sterile Disposable Sampler Tubes with Caps on Sterile 50/pk 1000/cs
Chemglass Life Sciences Vial Only, Sample, 11.4mL, Clear, High Recovery, 19x70mm, GPI 15-425
Vial Only, Sample, 11.4mL, Clear, High Recovery, 19x70mm, GPI 15-425. High recovery vial with a conical bottom for complete sample recovery. These vials are the same size or slightly smaller on the OD to allow them to be interchanged with any racks or blocks that accept standard dram or scintillation vials. Packed in an SBS coated white tray complete with SBS partition. Boxes are marked with alpha-numeric coordinates for fast and easy vial identification. Vial only.
