NMR Tubes
Thin, glass tubes of different lengths, wall thicknesses, outer diameters, cambers, concentricities, and I.D. and O.D. tolerances designed to hold samples during nuclear magnetic resonance spectroscopic analysis; may include tube cap.NMR tubes are required for analyzing samples using nuclear magnetic resonance spectroscopy. Choose an NMR tube that most closely matches the frequency (MHz) of your spectrometer.
Typically made of borosilicate glass and offered in seven- and eight-inch lengths, the outer diameter of the tube can range from 3mm to 10mm, with 5mm being the most common. For greater testing precision, look for thin-walled NMR tubes. Quartz NMR tubes with low boron concentrations of boron are also available if boron NMR is used.
NMR tubes are available in reusable or disposable versions. Some versions have screw caps, with or without septa. Polyethylene caps are the most common.
Specifications for NMR tubes may include concentricity and camber.
- Concentricity is how round the tube is and is measured using the inner and outer walls
- Camber is a measure of the tube’s straightness; poor camber can cause the tube to wobble during rotation, which can produce spinning side bands
Nuclear magnetic resonance spectroscopy allows you to observe the local magnetic fields around atomic nuclei. As radio waves excite the nuclei, their resonance is detected by a sensitive radio receiver that provides information about the molecule’s electronic structure. NMR spectroscopy is also used to identify monomolecular organic compounds, proteins, and other complex molecules.
Chemglass Life Sciences Tube, NMR, 5mm, Select Series™, With Caps, 7"" Long, 400 MHz, Concentricity 0.0070mm, Camber 0.0190mm
Tube, NMR, 5mm, Select Series™, With Caps, 7" Long, 400 MHz, Concentricity 0.0070mm, Camber 0.0190mm. NORELL™ Select Series™ NMR Tubes are specifically designed for high-resolution NMR. These tubes are manufactured out of ASTM Type 1 Class A glass, commonly referred to as Pyrex 7740 (Corning), Duran, or Kimax (Kimble) KG-33 glass. Several key properties that make this glass type desirable for NMR are its high degree of thermal shock resistance and low expansion coefficient. This allows for a greater margin of safety from breakage when used in variable temperature applications and freeze/thaw cycling, or any other application where large temperature variations are required in the experiment.
Chemglass Life Sciences NMR Tube Cleaner, Morris, for 5mm X 7in NMR Tube, Complete
NMR Tube Cleaner, Morris, for 5mm X 7in NMR Tube, Complete. The Morris NMR tube cleaner is an inexpensive, durable apparatus which will clean 5mm NMR tubes with as little as 10mL of solvent in one easy operation. Cleaner does not require a stopper on the NMR tube and does not have a fragile side arm. Complete item is supplied with a NMR tube washer, adapter, 250ML HW filter flask and instructions for use.**Designed and developed by Mr. Earl Morris, Georgetown University, Washington DC
New Era Enterprises NMR TUBE, 5MM X7" 100PK
5mm x 7" high field high throughput NMR sample tube. Pack of 100
Chemglass Life Sciences Tube, NMR, Screw Cap, For 600 MHz, 7"" Long
Tube, NMR, Screw Cap, For 600 MHz, 7" Long. NORELL™ Screw Cap NMR Tubes have a convenient screw cap access with the security of a PTFE seal. Supplied with open top cap & PTFE septum for quick and clean access with a 22 gauge standard point needle.
Chemglass Life Sciences Tube, NMR, 5mm, Select Series™, With Caps, 7"" Long, 500 MHz, Concentricity 0.0050mm, Camber 0.0130mm
Tube, NMR, 5mm, Select Series™, With Caps, 7" Long, 500 MHz, Concentricity 0.0050mm, Camber 0.0130mm. NORELL™ Select Series™ NMR Tubes are specifically designed for high-resolution NMR. These tubes are manufactured out of ASTM Type 1 Class A glass, commonly referred to as Pyrex 7740 (Corning), Duran, or Kimax (Kimble) KG-33 glass. Several key properties that make this glass type desirable for NMR are its high degree of thermal shock resistance and low expansion coefficient. This allows for a greater margin of safety from breakage when used in variable temperature applications and freeze/thaw cycling, or any other application where large temperature variations are required in the experiment.
Cole-Parmer Wilmad-LabGlass WG-1000-7 NMR Tube, disposable, 7"L, 100 MHz, 100/pk
NMR tubes are precision machined by melting, grinding, and polishing to meet exact tolerances. Each 5mm tube meets precise wall thickness, exact centerline symmetry, and perfect straightness.
Norell Inc 5mm, 400MHz 7 in. STANDARD SERIES NMR TUBE, 5PK
5mm, 400MHz 7 in. STANDARD SERIES NMR TUBE, 5PK
Norell Inc 5mm, 600MHz 7" SELECT SERIES NMR TUBE, 5 Tubes per pack
Select Series NMR Tubes are ideal for cold refrigeration storage, work with cryo-probes and, variable temperature studies. Key properties that make this glass type desirable for NMR are its high degree of thermal shock resistance and low expansion coefficient. This allows for a greater margin of safety from breakage when used in variable temperature applications and freeze/thaw cycling, or under any other application where large temperature variations are required in the experiment.
Chemglass Life Sciences Liner, PTFE, 5mm, NMR, Tube
Liner, PTFE, 5mm, NMR, Tube. NORELL™ PTFE Liners have a thin-wall construction that minimizes filling-factor losses. They are supplied with a PTFE plug closure. These liners should be used for NMR studies where chemical compounds such as hydrofluoric acid, ammonium bifluroride and concentrated hydroxide solutions are present.C-TL-5-7: Volume at 50mm = ~ 0.35mL for the 5mm NMR Tube
Chemglass Life Sciences Assortment Box: NMR Tube Caps, 100 of each CG1842 cap color
Assortment Box: NMR Tube Caps, 100 of each CG1842 cap color (black, white, yellow, red, green, and blue.)Made from polyethylene, these caps are sized to fit 5mm O.D. NMR sample tubes. Cap fits tightly to stay in place during increased internal vaporization pressure. Available in a pack of 100, or in a convenient divided polypropylene box having 100 each of the 6 listed colors.
Chemglass Life Sciences Tube, NMR, 5mm, Standard Series™, With Caps, 7" Long, 300 MHz, Concentricity ± 0.010mm, Camber ± 0.038mm
Tube, NMR, 5mm, Standard Series™, With Caps, 7" Long, 300 MHz, Concentricity ± 0.010mm, Camber ± 0.038mm. NORELL™ Standard Series™ NMR Tubes are manufactured out of ASTM Type 1 Class B glass, commonly referred to as N-51A. Applications that are suited for using this type of glass are routine NMR, where samples are run under room temperatures with no thermal gradients, for auto-sampling systems or high throughput NMR. Redesigned from the ground up and with emphasis on quality and precision, Norell™ has succeeded in virtually eliminating tube wall and bottom variation. It is not recommended to fuse this glass with standard vacuum manifolds and like, since they are generally made of Type 1 Class A glass.
Chemglass Life Sciences NMR Tube Cleaner, Morris, For 5mm X 8in NMR Tube, Complete
NMR Tube Cleaner, Morris, For 5mm X 8in NMR Tube, Complete. The Morris NMR tube cleaner is an inexpensive, durable apparatus which will clean 5mm NMR tubes with as little as 10mL of solvent in one easy operation. Cleaner does not require a stopper on the NMR tube and does not have a fragile side arm. Complete item is supplied with a NMR tube washer, adapter, 250ML HW filter flask and instructions for use.**Designed and developed by Mr. Earl Morris, Georgetown University, Washington DC
BRUKER BIOSPIN UNRACKED 4" NMR-TUBES,5MM
UNRACKED 4" NMR-TUBES WITH CODED CLOSED CAPS FOR USE WITH SAMPLEJET. Set of certified 100 tubes with coded closed caps designed for high throughput use with SampleJet on a Bruker NMR System
