Distillation Labware
Glassware and replacement parts designed to carry out distillations in laboratory settings; includes condensers, distillation heads, receivers, etc. Products are available for various scales and for specialty distillations.
Distillation is a process used widely in the laboratory or in wider working environments for separating or purifying liquids or liquid mixtures based on the different boiling points of individual components.
Distillation Applications:
• Separation and purification of miscible liquid mixtures in organic chemistry
• Drying of solid residues and/or solvent removal
• Fractional distillation of liquids from polymers and petroleum products
• Removal of particulates or other solid contaminants
• As part of a water purification system for production of distilled water for laboratory use
• Specialist steam distillation-based applications such as Kjeldahl analysis of nitrogen and proteins in food, beverage, or environmental samples
What Types of Distillation Equipment Are Available?
Conventional distillation apparatus, typically comprising individual, jointed borosilicate glassware components assembled by the user (depending upon the application), using appropriate clamps, stands, and supports. Most conventional distillation assemblies combine a round-bottomed distilling flask to contain and heat the liquid(s) that require purification, fitted with a stoppered or jointed neck to which is attached a downward-sloping, inclined side-arm for connection to a condensing unit to cool the heated vapors back down to their liquid state. Heating mantles are the preferred heat source for improved temperature control. These conventional distillation units are also available supplied complete and ready-assembled for added convenience and ease of use.
Specialized automated distillation equipment, notably units designed for the determination of volatile acidity and alcoholic strength by volume in wines, musts, and alcoholic beverages, and units designed for Kjeldahl nitrogen or protein determinations.
Petroleum Analyzer Corporation CRM W/Cert ASTM D86 Diesel 255Ml
CRM Atm Distillation Diesel appr. 170 to 370°C, 255ml
Chemglass Life Sciences Valve, 0-4mm, 90°, Exposed O-ring Tip
Valve, 0-4mm, 90, Exposed O-ring Tip. Hi-vac valve with two sidearms sealed to the barrel at a 90 angle to one another. Designed with a precision external thread for fine control.
Chemglass Life Sciences Distillation Vessel, 500mL, Receiving, Cylindrical, 105mm OD, ChemRxnHub, Compatable with CG-1947-A100
Distillation Vessel, 500mL, Receiving, Cylindrical, 105mm OD, ChemRxnHub, Compatible with CG-1947-A100. Cylindrical shaped distillation receiving vessel for use with ChemRxnHub benchtop systems for collecting distillate. The top of the vessel has two 0-8 Chem-cap valves with 1/2¿ OD Swagelock side arms that offer a convenient way to connect the receiver to CG-1975 PTFE tubing and compression fittings. Bottom of vessel has 0-14 drain valve with a 1/2¿ OD swagelock sidearm. The body of vessel has approximate volume graduations on the front and back. Vessel body diameter is compatible with CG-1947-A clamps which provide an easy way to support the receiver on the frame or hood lattice.
Chemglass Life Sciences Adapter, Distilling/Splitting, 24/40, Angled, 0-4mm Valve, 1/2" Compression Fitting, Process Reactor
Adapter, Distilling/Splitting, 24/40, Angled, 0-4mm Valve, 1/2" Compression Fitting, Process Reactor. Compact and simple distilling/splitter adapter for use with Chemglass process reactors lids that have a 10¿ angled side neck (CG-1946-B). Vapor flows upward freely through the large vapors holes to the condenser. Distillate flow is directed using the valve to either the receiving flask or back to the reactor. Control valve is either a 0-4mm or a 0-12mm PTFE with a 1/2¿ OD distillate takeoff for use with CG-1975 compression fittings and TFE tubing. Plugs are supplied complete with CG-309 Perfluoro o-rings.
Chemglass Life Sciences 350mL Tube, Storage, 24/40 Outer Joint, Airfree, Schlenk
350mL Tube, Storage, 24/40 Outer Joint, Airfree, Schlenk. Similar to AF-0522, but cylindrical in shape. 0-8mm valve size. PLEASE NOTE: STIR BARS LARGER IN DIAMETER THAN THE OPENING OF THE VALVE, OR STANDARD TAPER JOINT, CAN BE SEALED INTO VESSELS DURING MANUFACTURING. PLEASE CALL FOR DETAILS.
Ace Glass, Inc. Trap, bump, drain holes, 250mL, 24/40 top, 24/40 bottom
250mL bump trap for use between a rotary evaporators steam tube and evaporator flask, preventing fluid from being drawn into the condenser. Trap has 24/40 top and bottom joints. Improved design incorporates two drain holes to expedite the return of solvent to the evaporator flask.
Chemglass Life Sciences Clamp, Two-Prong Extension, Medium, Dual Adjust, 9.02in OAL
Clamp, Two-Prong Extension, Medium, Dual Adjust, 8in OAL. Nickel-plated zinc alloy clamp has high tensile strength and corrosion resistance. Fully enclosed stainless steel springs provide smooth operation. Two-prong clamps are available in single and dual adjustment. The medium clamp has a 1 1/2¿ (38mm) maximum grip size with a 1/2¿ (13mm) O.D. extension arm. The large clamp has a 2 1/2¿ (64mm) maximum grip size with a 5/8¿ (16mm) O.D. extension arm. Complete with removable vinyl and fiberglass sleeve covers.
Chemglass Life Sciences Replacement Steam Duct for Buchi R-200/R-205 Rotary Evaporators, 29/42 Steam Duct
Replacement vapor (steam) tube adapter for Bchi R-200/205 rotary evaporators. Adapters have a 50mm OD top flange with a tapered interior to fit the Bchi sealing ring. Lower portion of the adapter has the listed standard taper inner joint. Each tube is supplied complete with corresponding size Keck clip.NOTE: ITEMS WILL REPLACE THE BUCHI PART NUMBERS AS LISTED. CHEMGLASS ITEMS ARE TO BE USED WITH THE KECK CLIP, NOT THE BUCHI COMBI-CLIP.
Chemglass Life Sciences 48mL HW Pressure Vessel, Cylindrical, #15 Internal Thread, Complete, 38mm O.D. x 114mm Length, Bushing Size/15
48mL Heavy Wall Pressure Vessel, Cylindrical, #15 Internal Thread, Complete, 38mm O.D. x 114mm Length, Bushing Size/15. Heavy wall pressure vessels have an internal thread for use with PTFE bushings as pressure seals. The design allows hand tightening/loosening for easy access into the vessel. O-ring is positioned on the bushing above the thread for improved sealing. Supplied complete with vessel, PTFE bushing & Viton o-ring. Optional Perfluoro o-ring has the chemical resistance & service temperature range similar to Kalrez 4079. See CG-362, CG-364, and CG-366 for optional PTFE Bushings.IMPORTANT NOTICE: ALL CHEMGLASS PRESSURE VESSELS ARE TESTED AT 150 PSI, OR APPROX TWO AND ONE-HALF TIMES THEIR RECOMMENDED WORKING PRESSURE. HOWEVER, CHEMGLASS DOES NOT GUARANTEE THE VESSEL FROM BREAKING UNDER PRESSURE, DUE TO THE NATURE OF MATERIAL AND CONDITIONS BEYOND OUR CONTROL. CHEMGLASS RECOMMENDS THE USE OF SAFETY SHIELDS AND/OR OTHER SAFETY EQUIPMENT.
Chemglass Life Sciences Condenser, 45/50 Joint, Reflux, 315 x 100mm
Condenser, 45/50 Joint, Reflux, 315 x 100mm. Compact high efficiency reflux condenser employs a double wall thimble shape bulb sealed into the outer jacket. Serrated hose connections for water connection extend through the outer bulb and have an O.D. of 10mm at the middle serration. While the overall height of this condenser is only 210-215mm, it has the efficiency of a standard 400mm Liebig or West condenser.
Chemglass Life Sciences Distillation Head, 250mL, Solvent, Modified, 14/20 Inner Joint On Take-Off
Distillation Head, 250mL, Solvent, Modified, 14/20 Inner Joint On Take-Off. Designed to maintain distilled solvents in an inert atmosphere. Top of main vapor tube is open and an additional vapor tube has been added to decrease risk of pressure buildup. Upper sampling port has a 4mm PTFE stopcock with a 14/20 outer joint for use with CG-3022 septa. Lower drain is centered to allow total drainage of storage head. Double oblique 2mm bore PTFE stopcock on the 250 through 1000mL sizes allows for removal of distilled solvent or return to flask. The 250mL size has a 4mm double oblique stopcock. Both the uptake tube and top outer joints are 24/40, while the take-off tube is supplied with a 14/20 inner joint.**Design suggested by Dr. A.K. Saksena, Schering Plough Research Institute, Kenilworth NJ.
Chemglass Life Sciences Distilling Head, Vigreux, Jacketed, 10/18 Thermometer Joint, 14/20 Joint Size, 2mm PTFE Stopcock, Approx. 255mm Height x 310mm Width
Distilling Head, Vigreux, Jacketed, 10/18 Thermometer Joint,14/20 Joint Size, 2mm PTFE Stopcock, Approx. 255mm Height x 310mm Width. Jacketed fractionation distilling head for use under vacuum. The 10/18 top outer joint is for a 1¿ immersion thermometer while the 10/30 joints are for a 2¿ immersion thermometer. The 24/40 joint size uses 4mm glass or PTFE stopcocks, and are positioned to permit changing of receiver without interruption of the distillation process. The 14/20 size uses 2mm bore glass or PTFE stopcocks.
