CD140a Mouse anti-Human, Brilliant Violet 711, Clone: αR1 (also known as Alpha-R1), BD Optibuild™

Mouse Monoclonal Antibody

Supplier:  BD Biosciences 742668

Catalog No. BDB742668

Description

The αR1 monoclonal antibody specifically binds to the human platelet derived growth factor (PDGF) receptor α (PDGFRα), also known as CD140a. CD140a is a 170 kDa single transmembrane glycoprotein expressed on fibroblasts, smooth muscle cells, glial cells and chondrocytes. PDGF receptors α and βare single glycoproteins with intracellular tyrosine kinase domains. They are structurally similar to the M-CSF receptor and CD117 (c-kit). Their ligand, PDGF, is a mitogen for connective tissue cells and glial cells. PDGF plays a role in wound healing and it also acts as a chemoattractant for fibroblasts, smooth muscle cells, glial cells, monocytes and neutrophils. Functional PDGF is secreted in disulfide linked, homodimeric or heterodimeric forms comprised of A or B chains (PDGFAA, PDGF-BB or PDGF-AB). Binding of divalent PDGF induces receptor dimerization with three possible forms: αα, αβ, ββ. The PDGFRαsubunit binds both PDGF A and B chains, whereas the PDGFRβ subunit binds only PDGF B chains. Although both receptor subunits can stimulate mitogenic responses, only the β subunit can induce chemotaxis.TheαR1antibody is specific for PDGFRαand does not crossreact with PDGFRβ. It immunoprecipitates human, monkey, rabbit, pig, dog and cat PDGFRα. It does not recognize hamster, rat or mouse PDGFRα.

The antibody was conjugated to BD Horizon™ BV711 which is part of the BD Horizon Brilliant™ Violet family of dyes. This dye is a tandem fluorochrome of BD Horizon BV421 with an Ex Max of 405nm and an acceptor dye with an Em Max at 711nm. BD Horizon BV711 can be excited by the violet laser and detected in a filter used to detect Cy™5.5 / Alexa Fluor™ 700-like dyes (eg, 712/20nm filter). Due to the excitation and emission characteristics of the acceptor dye, there may be moderate spillover into the Alexa Fluor™ 700 and PerCP-Cy5.5 detectors. However, the spillover can be corrected through compensation as with any other dye combination. BV711 is a tandem fluorochrome of BD Horizon BV421 and an acceptor dye with an emission maximum at 711 nm. This dye offers a very bright choice for the violet laser. Due to the excitation and emission characteristics of the acceptor dye, there may be moderate spillover into the Alexa Fluor™ 700 and PerCP-Cy5.5 detectors. BV711 will also have moderate spillover into the BD Horizon Brilliant™ Violet 786 detector.

Specifications

• Antigen: CD140a
• Clone: αR1 (also known as Alpha-R1)
• Conjugate: Brilliant Violet 711
• Gene Alias: PDGF Receptor α, PDGFRA, PDGFRα, PDGF-R-alpha, PDGFR2, PGFRA, RHEPDGFRA
• Immunogen: Human PDGFRα Transfected Cell Line
• Quantity: 50 μg
• Primary or Secondary: Primary
• Content And Storage: Store undiluted at 4°C and protected from prolonged exposure to light. Do not freeze.

• Classification: Monoclonal
• Concentration: 0.2mg/mL
• Formulation: Aqueous buffered solution containing ≤0.09% sodium azide.
• Host Species: Mouse
• Purification Method: Affinity Purified
• Regulatory Status: RUO
• Target Species: Human
• Isotype: IgG2a κ

Safety and Handling

WARNING: Reproductive Harm - www.P65Warnings.ca.gov
