Square or Rectangle Cuvettes and Cells
Chemglass Life Sciences UV-Cuvette, Semi-Micro
UV-Cuvette, Semi-Micro. UV-Transparent Cuvettes are a disposable alternative to quartz cuvettes in DNA, RNA and protein analysis as well as many other applications between 220nm and 900nm. Use the semi-micro size UV-Cuvettes for sample volumes between 1.5 and 3.0mL and the macro UV-Cuvettes for samples larger than 2.5 up to 4.5mL.UV-Cuvettes eliminate the tedious & time-wasting cuvette washing & the risk of sample carry-over associated with reusable quartz cuvettes. Process QC applications avoid the need for qualified SOP’s for cuvette cleaning.The proprietary plastic material offers chemical compatibility superior to that of conventional plastic cuvettes of acrylic or polystyrene, and may be used with most polar organic solvents.Cuvettes have recessed windows to help protect against scratching and fit most commercial spectrophotometers and photometers. They are grouped by mold cavity number to maximize consistency between cuvettes and reduce variation in extinction coefficient.
Chemglass Life Sciences Cuvette, PMMA, Semi-Micro
Cuvette, PMMA, Semi-Micro. These cuvettes are an excellent choice for most spectrophotometry applications in the visible range. Manufactured from polystyrene (PS) or polymethyl methacrylate (PMMA or ‘Acrylic’), they provide accurate, reliable results, even at wavelengths as low as 300nm and are grouped by manufacturing mold cavity number to ensure the lowest variation in extinction coefficient. These disposable cuvettes are available in macro and semi-micro sizes to accommodate most sample volumes. Semi-micro cuvettes require only 1.5mL of sample volume. Cuvettes include an arrow mark to indicate direction of transmission and reduce variation. Compatible with most spectrophotometers and photometers.
Fireflysci Type 4 Micro Fluorescence Cuvette with PTFE Cover (Material: UV Quartz) (Lightpath 5X5X33mm)
Type 4 Micro Fluorescence Cuvette with PTFE Cover (Material: UV Quartz) (Lightpath 5X5X33mm)• Cuvette has an open top with a PTFE lid which rests on the top• Material is UV Quartz (transmits over 80% between 190-2,500nm)• Four windows and the base optically polished for fluorescence measurements• Lightpath is 5x5x33mm• Outside dimensions 7.5x7.5x33mm• Inside Dimensions- 3x3x40mm• Capacity- 0.64mL. *Does not come with the black holder/adapter.*
Fireflysci Type 9FL Semi-Micro Fluorescence Cuvette with PTFE Cover (Material: Optical Glass) (Lightpath 10mm)
Type 9FL Semi-Micro Fluorescence Cuvette with PTFE Cover (Material: Optical Glass) (Lightpath 10mm)• Cuvette has an open top with a PTFE lid which rests on the top• Material is UV Quartz (transmits over 80% between 340-2,500nm)• Four windows and the base optically polished for fluorescence work• Lightpath is 10mm• Outside dimensions 12.5x12.5x45mm• Inside Dimensions- 10x4x45mm• Capacity- 1.4mL
Fireflysci Type 20 Demountable O-Shaped Circular Dichroism Cuvette (Material: IR Quartz) (Lightpath: 1mm)
Type 20 Demountable O-Shaped Circular Dichroism Cuvette (Material: IR Quartz) (Lightpath: 1mm)• Cuvette is a o-shaped demountable spectrophotometer cuvette with a removable window• Sample can be pipetted on the grooved slide and cover slide placed on top• Cover slide is 1.25mm thick • Material is IR Quartz (transmits over 80% between 220-3,500nm)• Two windows optically polished• Lightpath is 1mm• Outside dimensions 3.5x12.5x45mm• Inside Dimensions- 1x10x38mm• Capacity- 360µL
Fireflysci Type 21 Macro Cuvette with PTFE Stopper (Material: UV Quartz) (Lightpath: 1mm)
Type 21 Macro Cuvette with PTFE Stopper (Material: UV Quartz) (Lightpath: 1mm)• Cuvette has an airtight PTFE stopper which plugs into the top• Material is UV Quartz (transmits over 80% between 190-2,500nm)• Two windows optically polished• Lightpath is 1mm• Outside dimensions 3.5x12.5x55mm• Inside Dimensions- 1x10x45mm• Capacity- 0.4mL
Fireflysci Type 9FL Semi-Micro Fluorescence Cuvette with PTFE Cover (Material: UV Quartz) (Lightpath 10mm)
Type 9FL Semi-Micro Fluorescence Cuvette with PTFE Cover (Material: UV Quartz) (Lightpath 10mm)• Cuvette has an open top with a PTFE lid which rests on the top• Material is UV Quartz (transmits over 80% between 190-2,500nm)• Four windows and the base optically polished for fluorescence work• Lightpath is 10mm• Outside dimensions 12.5x12.5x45mm• Inside Dimensions- 10x4x45mm• Capacity- 1.4mL
Fireflysci Type 20 Demountable O-Shaped Circular Dichroism Cuvette (Material: UV Quartz) (Lightpath: 0.1mm)
Type 20 Demountable O-Shaped Circular Dichroism Cuvette (Material: UV Quartz) (Lightpath: 0.1mm)• Cuvette is a o-shaped demountable spectrophotometer cuvette with a removable window• Sample can be pipetted on the grooved slide and cover slide placed on top• Cover slide is 1.25mm thick • Material is UV Quartz (transmits over 80% between 190-2,500nm)• Two windows optically polished• Lightpath is 0.1mm• Outside dimensions 2.6x12.5x45mm• Inside Dimensions- 0.1x10x38mm• Capacity- 36µL
Fireflysci Type 20 Demountable O-Shaped Circular Dichroism Cuvette (Material: UV Quartz) (Lightpath: 0.2mm)
Type 20 Demountable O-Shaped Circular Dichroism Cuvette (Material: UV Quartz) (Lightpath: 0.2mm)• Cuvette is a o-shaped demountable spectrophotometer cuvette with a removable window• Sample can be pipetted on the grooved slide and cover slide placed on top• Cover slide is 1.25mm thick • Material is UV Quartz (transmits over 80% between 190-2,500nm)• Two windows optically polished• Lightpath is 0.2mm• Outside dimensions 2.7x12.5x45mm• Inside Dimensions- 0.2x10x38mm• Capacity- 72µL
Chemglass Life Sciences Tubing, Quartz, 13mm ID x 15mm OD, 4ft Length
Tubing, Quartz, 13mm ID x 15mm OD, 4ft Length. General Electric Type 214 grade clear fused quartz tubing. Tubing is stocked in 4ft lengths.
