Tubing Connectors and Fittings
Chemglass Life Sciences 500mL Gas Balloon with Threaded Valve
500mL Gas Balloon with Threaded Valve. Gas balloon having a Chem-Cap 0-4mm high vacuum valve.
Chemglass Life Sciences 4 Ring Hose Connection, "A" = 14.0, "B" = 19.0, "C" = 20.5, "D" = 20; "E" = 19
4 Ring Hose Connection, "A" = 14.0, "B" = 19.0, "C" = 20.5, "D" = 20; "E" = 19. Serrations are tooled on both ends of an 8" length of tubing. Hose connections are SOLD IN PACKAGES OF 10 SERRATED CONNECTORS (5 pieces tooled on both ends).
Chemglass Life Sciences 4 Ring Hose Connection, "A" = 20.0, "B" = 25.0, "C" = 27.5, "D" = 22; "E" = 22
4 Ring Hose Connection, "A" = 20.0, "B" = 25.0, "C" = 27.5, "D" = 22; "E" = 22. Serrations are tooled on both ends of an 8" length of tubing. Hose connections are SOLD IN PACKAGES OF 10 SERRATED CONNECTORS (5 pieces tooled on both ends).
Chemglass Life Sciences Stopper, Cylindrical, Economy, 24/40
Stopper, Cylindrical, Economy, 24/40. For use in standard taper outer joints. Economy style with open bottom.
Bellco Glass, Inc. Flow-Control Tube CLAMP,1/2OD
Flow Control Tube Clamp ½". Plastic flow-control tube clamp. MADE IN THE USAMax.tube od: 1/2" (13mm)Max. Pressure: not ratedTemperature range: 32° to 200°fColor: white (opaque)Material: acetalSterilization: stem (autoclave)Materials meet: not ratedTubing: use with pvc, silicone, latex & rubber with a durometer of 35a-60aShut off clampPKG/QTY: 10
Chemglass Life Sciences Adapter, Flow Control, Straight, 2mm Stpk, 29/26 Inner Joint
Adapter, Flow Control, Straight, 2mm Stpk, 29/26 Inner Joint. Used to regulate the flow of gases or liquids into reaction systems. PTFE stopcock has a bore of 2mm. Hose connection has an O.D. of 8mm at the middle serration.
Chemglass Life Sciences 14/20 Inner Joint, Medium Length, on 13mm OD x 2.2mm W tubing
Adapter, Thermometer, Inlet, 10° Offset, 29/26 Inner Joint. Adapter has a #7 Chem-Thread at the top for vacuum tight seal of plain stem thermometers or any other tube having an O.D. between 4 and 7mm. When used with vertical side neck flasks, thermometers or bleed tubes can be angled into the bottom of the flask. Supplied complete with a compression cap and Viton o-ring.
Chemglass Life Sciences Adapter, Inlet, 29/42 Inner Joint, Hose Connection
Adapter, Inlet, 29/42 Inner Joint, Hose Connection. With a serrated hose connection for vacuum or for the introduction of gases. The #7 Chem-Thread at the top is for a vacuum tight seal of plain stem thermometers or any other tube having an O.D. between 4 and 7mm. Serrated hose connection has an O.D. of 10mm at the largest serration. Supplied complete with a compression cap and Viton o-ring.
Chemglass Life Sciences 24/40 Adapter Complete with Tubing, Stopcock and Fittings
24/40 Adapter Complete with Tubing, Stopcock and Fittings. Sampling adapter for use with a 24/40 outer joint on the reaction kettle lid. Adapter is supplied complete with a 90° bore valve enabling connection to a luer type syringe for product sampling. Adapter has three inlets for use with 1/8” OD PTFE tubing or optional 5mm OD silicone septa. Adapter and valve have 1/4”-28 female threads. Adapter is supplied complete with (3) CG-1164-N-02 Nuts, (3) CG-1164-F-02 ferrules and (2) CG-1166-10 solid plugs. Sampling valve is also supplied complete with nuts and ferrules. See CG-1037-16 for pierceable silicone septa.Complete adapter is supplied with 90° valve, 3-port 24/40 PTFE Adapter and 10ft of 1/8” OD PTFE tubing.
Chemglass Life Sciences Adapter, Thermometer, Inlet, 24/40 Inner Joint, 70mm Height
Adapter, Thermometer, Inlet, 24/40 Inner Joint, 70mm Height. Adapter has a tubulation at the top for use with a CG-1040 rubber fitting. Fitting permits insertion of plain stem thermometers or bleed tubes. Supplied complete with one CG-1040 rubber fitting.
Chemglass Life Sciences Adapter, Vacuum Take-Off, Long Stem, 14/20 Joint Size
Adapter, Vacuum Take-Off, Long Stem, 14/20 Joint Size. With standard taper top outer and lower inner joints with sealed in lower tube extending below inner joint. Tubing extends 100mm below the joint on the 14/20 and 19/22 sizes and 200mm on the 24/40, 29/26 and 29/42 sizes. Serrated hose connection having an O.D. of 10mm at the largest serration for connection to vacuum source.
Chemglass Life Sciences Adapter, Universal, Inlet, 14/20 Inner Joint, #9 Chem-Thread, Hose Connection, Accepts O.D./ 7-9mm, O-Ring/110
Adapter, Universal, Inlet, 14/20 Inner Joint, #9 Chem-Thread, Hose Connection, Accepts O.D./ 7-9mm, O-Ring/110. Adapter has the listed size of Chem-Thread at the top for a vacuum tight seal of a variety of tubing diameters. Will accept glass, metal or heavy wall plastic tubes having diameters between 7 to 18mm O.D. such as thermometer wells, gas dispersion tubes, plain stem funnels, etc. Serrated hose connection has an O.D. of 10mm at the largest serration. Adapters are supplied complete with a Celcon compression cap and Viton o-ring.
Chemglass Life Sciences Adapter, PTFE, 1/8in Thermocouple, 14/20 Inner Joint
Adapter, PTFE, 1/8in Thermocouple, 14/20 Inner Joint. PTFE adapter for use with either 1/8 or 1/4 thermocouples. Adapter has an outer Viton o-ring to form a grease-free, airtight seal between the adapter and the listed size of outer joint. The compression nut works in conjunction with the upper Viton to provide a airtight seal between the adapter and thermocouple. Adapter design permits use with CG-145 Keck clips.
Chemglass Life Sciences Adapter, Vacuum Take-Off, Long Stem, 24/40 Joint Size
Adapter, Female Luer Lock, Vacuum, 1/4"-28 Thread, 14/20 Inner. Adapter has a 1/4” -28 thread that accepts a female luer lock adapter which provides a convenient way to connect solid phase extraction (SPE) cartridges, tubes, or syringes with a male luer lock fitting to a standard male taper inner joint. The adapter provides for easier sample concentration and clean-up while reducing the chances of cross-contamination. Hose connection is 10mm OD at the largest serration. Supplied complete with 1 each CG-1055-20; 1/4”-28 Female to Female luer lock adapter.
Chemglass Life Sciences Adapter, Flow Control, 90°, 2mm Stpk, 19/22 Inner Joint
Adapter, Flow Control, 90¿, 2mm Stpk, 19/22 Inner Joint. Used to regulate the flow of gases or liquids into reaction systems. Stopcock has a bore of 2mm. Hose connection has an O.D. of 8mm at the middle serration.
