HPLC Guard Columns and Cartridges
Optimize Technologies EXP Trap Cartridge, 4.6mm x 5mm, 3.0µm EXP, C18, 3pk
The Hand-Tight EXP™ Trap Column is rated to 20,000+ psi. This unique design connects directly to any injection valve (with 10-32 threads) or in-line with 1/16” tubing for unparalleled convenience and efficiency. The EXP™ System enables chemists to quickly remove detergents or salts which can affect the ionization process in MS work. This trapping technique can concentrate the sample directly on-line, allowing for increased recovery of precious sample material compared to off-line techniques. Free-Turn™ architecture allows users to change cartridges by hand without breaking fluid connections on the holder inlet/outlet. The EXP™ Trap Column family now offers packed beds available in 2, 5, 10, 15, 20 and 30mm lengths with diameters ranging from 1-4.6mm and bed volumes from 1.6-600µL. Please contact your representative directly if you're interested in a length other than 5mm.
Optimize Technologies EXPGuard Column Cartridge, 1mm x 5mm, C4, 3µm, 3pk
The EXP™ Guard Column cartridge system is rated to 15,000psi with hand-tight replaceable cartridges. This unique design connects directly to any UHPLC column with the auto-adjusting Titanium Hybrid Ferrule and EXP™ Fittings, providing repeated zero-dead-volume connections and easy adjustability between various column types. Free-Turn™ architecture allows the user to change cartridges by hand without breaking fluid connections on the holder inlet/ outlet. The combination of low-dispersion and ultra high-pressure capabilities provides effective protection with negligible effects on retention time, plate count, and peak shape. Use with EXP™ Direct Connect and In-line Holders.
Waters Corp BioSuite Diol (OH) Guard Column, 5 µm, 6 mm X 40 mm, 1/pk
BioSuite SEC Columns are available in 4.6 mm, 7.5 mm, and 7.8 mm i.d. analytical and 21.5 mm i.d. preparative and guard columns.
Optimize Technologies EXPGuard Column Cartridge, 3.0mm x 5mm, C4, 3µm, 3pk
The EXP™ Guard Column cartridge system is rated to 15,000psi with hand-tight replaceable cartridges. This unique design connects directly to any UHPLC column with the auto-adjusting Titanium Hybrid Ferrule and EXP™ Fittings, providing repeated zero-dead-volume connections and easy adjustability between various column types. Free-Turn™ architecture allows the user to change cartridges by hand without breaking fluid connections on the holder inlet/ outlet. The combination of low-dispersion and ultra high-pressure capabilities provides effective protection with negligible effects on retention time, plate count, and peak shape. Use with EXP™ Direct Connect and In-line Holders.
Optimize Technologies EXP Guard Column Cartridge, 1.5mm x 5mm, C4, 1.8µm, 3pk
The EXP™ Guard Column cartridge system is rated to 15,000psi with hand-tight replaceable cartridges. This unique design connects directly to any UHPLC column with the auto-adjusting Titanium Hybrid Ferrule and EXP™ Fittings, providing repeated zero-dead-volume connections and easy adjustability between various column types. Free-Turn™ architecture allows the user to change cartridges by hand without breaking fluid connections on the holder inlet/ outlet. The combination of low-dispersion and ultra high-pressure capabilities provides effective protection with negligible effects on retention time, plate count, and peak shape. Use with EXP™ Direct Connect and In-line Holders.
Mac-Mod Avantor Alltima CN, 100 Å, 5 µm, 4.6 x 7.5 mm Guard Cartridges (3/pk)
vantor Alltima columns combines a range of different phase chemistries with base deactivated silica. Avantor Alltima columns provides stable bonding for long column lifetimes. Avantor Alltima columns are made of high purity silica that provide excellent column stability with multiple selectivity options.
Sepax Technologies Inc Sepax HPLC Column HP-Amino, Guard cartridge with holder, 3 µm, 120 Å, 2 x 10 mm
Synthesized with polymeric chemistry, HP-Amino phase is bonded with aminopropyl functional group. HP-Amino phase is compatible with versatile mobile phases from non-aqueous solvents, such as hexane/ethyl acetate and chloroform/methanol, to aqueous solutions. It is recommended for separations of sugars, nucleotides, basic organic compounds, as well as the pharmaceuticals.
Optimize Technologies EXP Guard Column Cartridge, 2.1mm x 5mm, C4, 1.8µm, 3pk
The EXP™ Guard Column cartridge system is rated to 15,000psi with hand-tight replaceable cartridges. This unique design connects directly to any UHPLC column with the auto-adjusting Titanium Hybrid Ferrule and EXP™ Fittings, providing repeated zero-dead-volume connections and easy adjustability between various column types. Free-Turn™ architecture allows the user to change cartridges by hand without breaking fluid connections on the holder inlet/ outlet. The combination of low-dispersion and ultra high-pressure capabilities provides effective protection with negligible effects on retention time, plate count, and peak shape. Use with EXP™ Direct Connect and In-line Holders.
Sepax Technologies Inc Sepax HPLC Column Proteomix WCX, NP5, Guard cartridge with holder, 4 x 10 mm
Proteomix ion-exchange phases have been innovatively developed for achieving high ion-exchange capacity, a breakthrough technology for non-porous resins. Proteomix packing support is composed of a rigid, spherical, highly cross-linked poly(styrene divinylbenzene) (PS/DVB) non-porous bead with particle size selections of 1.7, 3, 5 and 10 µm. The PS/DVB resin surface is grafted with a highly hydrophilic, neutral polymer thin layer with the thickness in the range of nanometer. The hydrophobic PS/DVB resin surface is totally covered by a hydrophilic coating that eliminates non-specific bindings with biological analytes, leading to high efficiency and high recovery separations for biological molecules.
Waters Corp XSelect CSH Phenyl VanGuard Cartridge, 130 , 3.5 m, 3.9 mm X 5 mm, 3/pk
XSelect CSH Phenyl VanGuard Cartridge, 130 , 3.5 m, 3.9 mm X 5 mm, 3/pk
Mac-Mod Avantor ACE SIL, 100 Å, 5 µm, 3.0/4.6 x 10 mm Guard Cartridges (5/pk)
Avantor ACE Excel UHPLC and HPLC columns are manufactured with 100 Å Ultra-Inert Base Deactivated Silica specifically designed for your HPLC method development needs - Note SuperC18 is 95 Å Avantor ACE HPLC columns are available in a wide range of bonded phases (i.e. C18, C18-AR, C18-PFP, C18-Amide, CN-ES, SuperC18, NH2, C8, C4, Phenyl, AQ, CN and Sil). Avantor ACE Excel UHPLC and HPLC columns are avaialble in 1.7, 2, 3, and 5 µm particle sizes in all analytical column sizes. All Avantor ACE Excel columns are known for their excellent peak shape and batch to batch reproducibility. Columns are packed in 1000 bar UHPLC hardware. Note: Avantor ACE Excel UHPLC guard columns are available for all 1.7 and 2 µm particle sizes across all 2.1 mm - 4.6 mm column ID - Note: H0011 connects directly to the analytical column - Guard column cartridges are available in 3-packs. For 3 and 5 µm Excel columns use same guard systems used for Avantor ACE HPLC analytical columns.
Mac-Mod Avantor Alltima Phenyl, 100 Å, 5 µm, 2.1 x 7.5 mm Guard Cartridges (3/pk)
vantor Alltima columns combines a range of different phase chemistries with base deactivated silica. Avantor Alltima columns provides stable bonding for long column lifetimes. Avantor Alltima columns are made of high purity silica that provide excellent column stability with multiple selectivity options.
Waters Corp WATERS CORPORATION Guard Cartridge, MS C18, 5 μm, 30 x 10 mm
This guard cartridge features MS C18 chemistry with a 5 μm particle size and 30 x 10 mm dimensions, suitable for preparative column applications. It requires a compatible 30 x 10 mm cartridge holder.
- Designed to be compatible with mass spectrometry applications
- Provides sharp peaks, good sensitivity, and large peak capacities
- Trifunctional bonding chemistries deliver long lifetimes over a wide pH range
- Provides high throughput with excellent resolution and ultra–low bleed
- Compatible with pH range 1–12
Waters Corp SunFire VanGuard Cartridge, C8, 100Å, 5 μm, 2.1 x 5 mm
Waters SunFire VanGuard Cartridge, C8, 100Å, 5 μm, 2.1 x 5 mm
