General Microscope Accessories
General accessories for use with microscopes. Products include lens oil, lens cleaner, slide dispensers, microscope covers, vessel holders, light cubes, and flow cells.
Many parts of your microscope can be updated or replaced including microscope lamps, lenses, and eyepieces. Replacement lamps, light sources, and power cords can extend the working lives of your microscopy equipment. New or replacement objectives and lenses can help increase the total magnification available with your microscope.
Add greater magnification or exchange your eyepiece for one with a reticule to more easily estimate the sizes of the items being viewed.
Replace or update your mechanical stage or clamps or add cell culture vessel adapters to facilitate specimen positioning.
Condensers can also be replaced, and conversion kits are available to add phase contrast, polarization, fluorescence, or other capabilities to your current system.
Some microscopes can be adapted for use with still or video cameras. Look for cameras and adapters designed for your specific microscope brand. Film and documentation-related products may also be available to support your record-keeping.
Temporary, semi-permanent, and more long-term slide storage options include:
- Slide racks that securely hold slides during staining procedures
- Folding fiberboard or plastic slide holders with horizontal indentations that keep microscope slides in place
- Slide storage boxes with vertical dividers; made from fiberboard, plastic, and wood and available in multiple sizes
- Slide holders and mailers for transporting slides safely
- Slide storage systems and cabinets for large quantities of slides or archival storage
Electron Microscopy Sciences JEOL SEM Cylinder Mount 2" surface, 1/4" height, Aluminum
Cylinder specimen mounts are for use with JEOL scanning electron microscopes. The mounts are made from ultra-pure aluminum with a standard lathe finish.
Head: 2"
Height: 1/4"
Electron Microscopy Sciences JEOL SEM Cylinder Mount 1-1/4" surface, 3/8" height, Aluminum
Cylinder specimen mounts are for use with JEOL scanning electron microscopes. The mounts are made from ultra-pure aluminum with a standard lathe finish.
Head: 1-1/4"
Height: 3/8"
Electron Microscopy Sciences Double FIB Sample and Grid Holder, Pin, 1/2"
Holds a FIB sample mounted on two standard 1/2" (12.7 mm) pin stubs for FIB milling and lift-out procedures. Conveniently holds two FIB grids close to the sample to mount prepared TEM lamellae on the FIB grid for TEM imaging. Cost-effective holder suitable for all FIB/SEM systems which accept pin mount holders, including the FEI, ZEISS and Tescan systems. For the JEOL and Hitachi systems, use a pin mount adapter.
Overall Dimensions: 36.5 x 12.7 x 11.6 mm (1.44" x 0.5" x 0.46").
Pin: Standard 3.2 mm ( 1/8").
Material: Vacuum grade aluminum with brass screws.
Includes Philips screwdriver #0.
Electron Microscopy Sciences V-1 Quality, 15 x 15 mm, 0.15- 0.21 mm thick
EMS Mica Sheets offer a clean surface for EM applications, carbon filming and particle spraying, as well as for AFM applications. There are two types of mica: muscovite and phlogopite. Generally, one differs from the other by color (Muscovite is Ruby, Green or White; Phlogopite is Amber, Yellow, or Silver). The maximum operating temperature for Muscovite is about 500-600 degree C and for Phlogopite is about 800-900 degree C. Our line consists of High Quality Muscovite Mica. This mica peels off very thin up to 0.0001" uniform layers, exposing "virgin" mica upon splitting.
Muscovite, potash type mica, sometimes known as granitic mica, is the best of all micas in dielectric strength, perfection of cleavage, and transparency. It has the chemical formula: H2KAI3(Si04)3. Clear. Hard, of uniform color, nearly flat, free of all stains, foreign inclusion, cracks, and other similar defects.
Quality: V-1
Size: 15 x 15 mm
Thickness: 0.15- 0.21 mm
Electron Microscopy Sciences CryoCapsule High Pressure Freezing
The CryoCapsule is used in High Pressure Freezing (HPF) and correlative light and electron microscopy (CLEM). Comparable to a small petri dish, it is composed of a landmarked sapphire disc and a gold spacer ring (50um thick) maintained together by a plastic ring. The specimens are encapsulated between the support sapphire disc (carbon landmarked) and a covering sapphire disc.
The CryoCapsule is loaded into a specific adaptor (HPM010, HPM100, HPF compact 02). Live cell imaging is done directly on the specimen in the CryoCapsule prior to HPF. Post-HPF, the specimen is processed for freeze substitution and room temperature sectioning.
CryoCapCell has developed a set of tools to manipulate the CryoCapsule in most scientific environments.
Electron Microscopy Sciences Scale with Cross Line Microscope Graticle NE7, 24.5 mm, 10 mm with 0.1 mm spacing
Used as a horizontal and a vertical scale, they are especially useful when interested in measurement in different axis. Horizontal micrometer scale 10mm long with crosslines at 0.1mm spacing. Surface chrome image.
Size: 24.5 mm
Divisions: 10 mm with 0.1 mm spacing
Surface: Chrome image
Electron Microscopy Sciences Microscope Graticule NE1 Horizontal, 24.5 mm, 10 mm with 0.1 mm subdivisions
These scales are used for the measuring of lengths of specimen or distances between points on a variety of different shaped objects. By dividing the division of the chosen graticule by the magnification of the objective one obtains an approximate value that each division will represent on the stage. Vertical micrometer scale.
Size: 24.5 mm
Electron Microscopy Sciences Crossed Scale Microscope Graticle NE17, 24.5 mm, 10 mm with 0.1 mm subdivisions
Used as a horizontal and a vertical scale, they are especially useful when interested in measurement in different axis. Crossed micrometer scale.
Size: 24.5 mm
Divisions: 10 mm with 0.1 mm subdivisions
Surface: Chrome image
Electron Microscopy Sciences Scale with Cross Line Microscope Graticle NE7, 20.4 mm, 10 mm with 0.1 mm spacing
Used as a horizontal and a vertical scale, they are especially useful when interested in measurement in different axis. Horizontal micrometer scale 10mm long with crosslines at 0.1mm spacing. Surface chrome image.
Size: 20.4 mm
Divisions: 10 mm with 0.1 mm spacing
Surface: Chrome image
Electron Microscopy Sciences Scale with Cross Line Microscope Graticle NE7, 27 mm, 10 mm with 0.1 mm spacing
Used as a horizontal and a vertical scale, they are especially useful when interested in measurement in different axis. Horizontal micrometer scale 10mm long with crosslines at 0.1mm spacing. Surface chrome image.
Size: 27 mm
Divisions: 10 mm with 0.1 mm spacing
Surface: Chrome image
Electron Microscopy Sciences Miller Squares Graticle NE57, 23 mm, 9:1 Large to small square
The ratio of large to small squares is 9:1. Originally designed for hematology, they can be utilized for rapid counting of any evenly spread field of particle. References: American J. of Clin. Pathol. Vol.20, 1950, page 1079. "Time Saving Device For Counting Reticulocyte." G.Brescher and Schneiderman. Practicle Haemotology – J.D. Dacy. Published by J.A. Churchill. 2nd Edition 1956 page 25.
Size: 23 mm
Divisions: 9:1 Large to small square
Surface: Glass sandwich
Electron Microscopy Sciences Whipple Grid Graticle NE29, 27 mm, 100 squares in 7 mm
Originally designed for water particle analysis, but may be used for other aspects of particle counting. Grid showed: Ratio of full square to smallest is 50:1. Area is 2500:1. Reference: Microscopy of Drinking Water.
Size: 27 mm
Divisions: 100 squares in 7 mm
Electron Microscopy Sciences Grain Sizing Reticle NG61, 25 mm
For the determination of non-metallic inclusion content of steel. NG60 meets EN 10247 and NG61 Meets ISO 4976. Both are scaled for use eith 10x objective magnification Pattern
Size: 25 mm
Method: ISO 4967
Electron Microscopy Sciences Crossed Scale Microscope Graticle NE17, 23 mm, 10 mm with 0.1 mm subdivisions
Used as a horizontal and a vertical scale, they are especially useful when interested in measurement in different axis. Crossed micrometer scale.
Size: 23 mm
Divisions: 10 mm with 0.1 mm subdivisions
Surface: Chrome image
Electron Microscopy Sciences Crossed Scale Microscope Graticle NE17, 27 mm, 10 mm with 0.1 mm subdivisions
Used as a horizontal and a vertical scale, they are especially useful when interested in measurement in different axis. Crossed micrometer scale.
Size: 27 mm
Divisions: 10 mm with 0.1 mm subdivisions
Surface: Chrome image
