Distillation Labware
Glassware and replacement parts designed to carry out distillations in laboratory settings; includes condensers, distillation heads, receivers, etc. Products are available for various scales and for specialty distillations.
Distillation is a process used widely in the laboratory or in wider working environments for separating or purifying liquids or liquid mixtures based on the different boiling points of individual components.
Distillation Applications:
• Separation and purification of miscible liquid mixtures in organic chemistry
• Drying of solid residues and/or solvent removal
• Fractional distillation of liquids from polymers and petroleum products
• Removal of particulates or other solid contaminants
• As part of a water purification system for production of distilled water for laboratory use
• Specialist steam distillation-based applications such as Kjeldahl analysis of nitrogen and proteins in food, beverage, or environmental samples
What Types of Distillation Equipment Are Available?
Conventional distillation apparatus, typically comprising individual, jointed borosilicate glassware components assembled by the user (depending upon the application), using appropriate clamps, stands, and supports. Most conventional distillation assemblies combine a round-bottomed distilling flask to contain and heat the liquid(s) that require purification, fitted with a stoppered or jointed neck to which is attached a downward-sloping, inclined side-arm for connection to a condensing unit to cool the heated vapors back down to their liquid state. Heating mantles are the preferred heat source for improved temperature control. These conventional distillation units are also available supplied complete and ready-assembled for added convenience and ease of use.
Specialized automated distillation equipment, notably units designed for the determination of volatile acidity and alcoholic strength by volume in wines, musts, and alcoholic beverages, and units designed for Kjeldahl nitrogen or protein determinations.
Chemglass Life Sciences Distilling Receiver, 2mL, Moisture Test, Barrett, 14/20 Joint Size, 2mm PTFE Stopcock , Approx. 225mm Height x 65mm Width
Distilling Receiver, 2mL, Moisture Test, Barrett, 14/20 Joint Size, 2mm PTFE Stopcock , Approx. 225mm Height x 65mm Width. Barrett style distilling receiver used to determine the water content in petroleum or bituminous material. Receiver is made according to ASTM specifications, with the addition of the top outer standard taper joint and lower stopcock. The 2mL has sub-divisions of 0.02mL; the 5ml has subdivisions of 0.20mL; 10ml has subdivisions of 0.1mL; the 20mL has subdivisions of 0.2 from 0 to 3mL and 0.5 from 3 to 20mL. Available with glass or PTFE stopcocks.
Chemglass Life Sciences Small Condenser Only, Extraction Apparatus, Soxhlet, 34/45
Small condenser. Part of the CG1368 series. Condenser has an enlarged uptake tube to improve condensing capacity.
Chemglass Life Sciences Spacer to Heighten Plate (1 Needed for 1.0ml, 2 Needed for 1.5ml)
Replacement spacer for Multi-Tier Reaction plates (CG191501, CG191502, CG191503).1 Needed for 1.0ml, 2 Needed for 1.5ml.
Chemglass Life Sciences Bump Trap, 500mL, Rotary Evaporator, Modified, 24/40 Top Outer, 29/42 Lower Inner
Bump Trap, 500mL, Rotary Evaporator, Modified, 24/40 Top Outer, 29/42 Lower Inner. Similar to CG-1320, but with the addition of two 4mm drain holes at the base of the inner tube to allow solvent to drain back into the evaporation flask. Traps have a 24/40 top outer joint and the listed size of lower inner joint.
Chemglass Life Sciences Outer Sleeve Only, Condenser, "C" Assembly, Plastic Coated
Outer Sleeve Only, Condenser, "C" Assembly, Plastic Coated. Outer sleeve only replacement part for the CG-1333-10 plastic coated condenser.
Chemglass Life Sciences Distilling Column, 24/40 Joint, 12.5 x 300mm, Hemple
Distilling Column, 24/40 Joint, 12.5 x 300mm, Hemple. Plain distillation column with a row of indentations to support column packing material. Column length listed is for the straight portion above the row of indentations and below the joint. Column has a standard taper top outer and lower inner joint.
Chemglass Life Sciences Distilling Column, 24/40 Joint, 250mm, Vacuum Jacketed
Distilling Column, 24/40 Joint, 250mm, Vacuum Jacketed. Hemple style distilling column, vacuum jacketed to improve performance. Indentations on the inner tube support the packing material. All sizes have an I.D. of approximately 10mm.
Chemglass Life Sciences Distillation Head, Micro, Vigruex, 10/18 Thermometer Joint, 14/20 Outer Joint, Approx. 195mm Height x 185mm Width
Distillation Head, Micro, Vigruex, 10/18 Thermometer Joint, 14/20 Outer Joint, Approx. 195mm Height x 185mm Width. Distillation head with condenser sealed to a Vigreux column. Top thermometer joint is a 10/18 for use with a 1” immersion thermometer. Vacuum adapter has an outer joint and accepts a CG-1279-11 distribution adapter.
Chemglass Life Sciences Distilling Head, Vigreux, Jacketed, 10/30 Thermometer Joint, 24/40 Joint Size, 4mm Glass Stopcock, Approx. 550mm Height x 325mm Width
Distilling Head, Vigreux, Jacketed, 10/30 Thermometer Joint,24/40 Joint Size, 4mm Glass Stopcock, Approx. 550mm Height x 325mm Width. Jacketed fractionation distilling head for use under vacuum. The 10/18 top outer joint is for a 1¿ immersion thermometer while the 10/30 joints are for a 2¿ immersion thermometer. The 24/40 joint size uses 4mm glass or PTFE stopcocks, and are positioned to permit changing of receiver without interruption of the distillation process. The 14/20 size uses 2mm bore glass or PTFE stopcocks.
Chemglass Life Sciences Extractor, Soxhlet, Micro, Condenser only
Condenser replacement part for the micro size Soxhlet extractor (CG137401). CONDENSOR ONLY.
Chemglass Life Sciences Distilling Head, Short Path, 10/30 Thermometer Joint, 24/40 Lower Inner Joint, Approx. 195mm Width x 160mm Height
Distilling Head, Short Path, 10/30 Thermometer Joint, 24/40 Lower Inner Joint, Approx. 195mm Width x 160mm Height. Designed for use with small quantities where hold up between the flask and receiver must be kept to a minimum. The thermometer bulb and stem serve as column packing. Upper hose connections are for cooling lines while the lower connection is for vacuum. Available with Vigreux indentations to improve efficiency. NOTE: The 14/20 size accepts a 1” immersion 7/12 or 10/18 thermometer, while the 24/40 and 29/42 sizes accepts a 2” immersion, 10/30 thermometer.
Chemglass Life Sciences Distilling Column, 19/22 Joint, 130mm, Vigreux
Distilling Column, 19/22 Joint, 130mm, Vigreux. Vigreux style column with indentations that run the entire length of the column for improved vapor-liquid contact. Column length refers to the effective length, measured from the lowest to highest indent in the column. Column has a top outer and lower inner standard taper joint.
Chemglass Life Sciences Distilling Head, Short Path, Improved, Vigreux Indents, 10/30 Thermometer Joint, 24/40 Lower Inner Joint, Approx. 195mm Width x 160mm Height
Distilling Head, Short Path, Improved, Vigreux Indents, 10/30 Thermometer Joint, 24/40 Lower Inner Joint, Approx. 195mm Width x 160mm Height. Similar to CG-1239, but with the condenser being a combination of a cold coil and Liebig. Water flows into hose connection “A” through the coil and exits the outer jacket through hose connection “B”. Head is excellent for use when distilling medium to high boiling point solvents. Top outer joint is a 10/30 for use with a 2” immersion thermometer. Available with or without Vigreux indentations to further improve efficiency.
Chemglass Life Sciences Distilling Head, Short Path, Vigreux Indents, 10/30 Thermometer Joint, 24/40 Lower Inner Joint, Approx. 195mm Width x 160mm Height
Distilling Head, Short Path, Vigreux Indents, 10/30 Thermometer Joint, 24/40 Lower Inner Joint, Approx. 195mm Width x 160mm Height. Designed for use with small quantities where hold up between the flask and receiver must be kept to a minimum. The thermometer bulb and stem serve as column packing. Upper hose connections are for cooling lines while the lower connection is for vacuum. Available with Vigreux indentations to improve efficiency. NOTE: The 14/20 size accepts a 1” immersion 7/12 or 10/18 thermometer, while the 24/40 and 29/42 sizes accepts a 2” immersion, 10/30 thermometer.
