Microplate Readers and Reader Accessories
Microplate readers are a type of spectrophotometer designed specifically for analyzing multiple samples in multi-well plates.
The readers detect light signals that result from biological, chemical, biochemical, or physical reactions. The signals are produced by, converted by, or transmitted through the samples and are measured by a detector. The detectors are usually photomultiplier tubes (PMT), which convert the released photons into electricity. The current is quantified by the reader’s software to produce the numerical result.
In some cases, samples are first excited by exposure to light of specific wavelengths. Filters or monochromators are used to select or restrict the wavelengths needed for emission or detection.
Single-mode microplate readers commonly measure absorbance, fluorescence, or luminescence. Multi-mode plate readers may measure absorbance, fluorescence, and luminescence with options for fluorescence polarization (FP). They may also include lasers for time-resolved fluorescence (TRF), TR-FRET, Amplified Luminescent Proximity Homogeneous Assays (ALPHA), and cell imaging.
Features may include:
- Monochromator- or filter-based wavelength selection
- Visible only or UV/Vis spectrum, fluorescence, and luminescence
- Multiple photomultiplier tubes (PMTs) for simultaneous assays
- Temperature and CO2/O2controls
- Modular design for adding functionality
Microplate readers are used for high-throughput screening (HTS), biomarker assays, nucleic acid and protein quantification, kinetics, ELISA assays, homogeneous time resolved fluorescence (HTRF) for measuring cytokines, bioluminescence resonance energy transfer (BRET), and other techniques.
Revvity Health Sciences Inc HTRF Human Fibronectin EDA Detection Kit, 10,000 Assay Points
HTRF Human Fibronectin EDA Detection Kit, 10,000 Assay Points
Miele, Inc. ID 180 INJECTOR
Injector nozzle with plastic supports, Ø 0 3/16 (4), length 180 mm.Suitable for standard mobile injector units and injector basketsSuitable for measuring flasks and test tubes. MIELE INC mfg# 03810360
Revvity Health Sciences Inc HTRF Human & Mouse Total BRD4 Detection Kit, 10,000 Assay Points
HTRF Human & Mouse Total BRD4 Detection Kit, 10,000 Assay Points
Revvity Health Sciences Inc Flat Bottom (Coarse) Generator Probe, 30 x 195 mm
Flat Bottom (Coarse) Generator Probe, 30 x 195 mm
Molecular Devices Microplate Reader, Multi-Mode, Top/Bottom Read, 200-1000 nm
The SpectraMax M4 is a multi-mode microplate reader designed for absorbance, fluorescence, luminescence, and time-resolved fluorescence assays. It supports top and bottom reads and is engineered for flexible, routine laboratory measurements across a range of assay types.
- Multi-mode detection: absorbance, fluorescence, luminescence, TRF.
- Top and bottom reading for flexible assay configurations.
- Absorbance range 200-1000 nm, fluorescence/luminescence/TRF 250-850 nm.
- Dual-monochromator based detection for spectral flexibility.
- Compatible with standard microplate formats, including 96-well plates.
- Suitable for enzyme assays, nucleic acid and protein quantitation, and reporter assays.
Molecular Devices FlexStation 3 Microplate Reader, 16-Channel Pipettor, Dual Monochromator
The FlexStation 3 is a monochromator-based multi-mode microplate reader with integrated fluidics and an optional pipettor head for automated reagent addition and kinetic assays.
- Measures absorbance, fluorescence intensity, fluorescence polarization, luminescence, and time-resolved fluorescence.
- Integrated 16-channel pipettor for automated reagent addition and plate-to-plate transfers.
- Compatible with 96-well and 384-well microplate formats.
- Dual monochromators allow flexible excitation and emission wavelength selection without filter changes.
- Programmable onboard fluidics support timed reagent addition and real-time kinetic measurements.
- Designed for robot integration and supports validation workflows such as IQ/OQ.
Molecular Devices Microplate Reader, Multimode, 200-1000 nm, 6-384 Wells
The SpectraMax M2 is a dual-monochromator multimode microplate reader for absorbance, fluorescence, time-resolved fluorescence, and luminescence assays across 6-384 well plates and cuvette formats.
- Multimode detection for absorbance, fluorescence intensity, time-resolved fluorescence, and luminescence.
- Wavelength range: absorbance 200-1000 nm, fluorescence excitation 250-850 nm, fluorescence emission 360-850 nm.
- Supports 6, 12, 24, 48, 96, and 384 well plate formats.
- Dual-mode cuvette port for cuvette-based assays and dual monochromators for tunable wavelength selection.
- Power: 100-240 Vac, 3 A, 50/60 Hz; power consumption under 125 W.
- Includes PathCheck optical pathlength normalization, kinetic and endpoint read modes, and robot compatibility.
Lonza Walkersville Nebula® Multimode Reader, Multi-mode reader that is used to perform fluorescent and absorbance endotoxin tests.
The Nebula® Multimode Reader is part of the quantitative endotoxin detection system that supports both absorbance and fluorescent based endotoxin detection assays.
Leica Biosystems Leica Microsystems Filter Cube 405 nm (for Leica fluorescence microscopes)
Filter cube for 405 nm fluorescence imaging. Provides the excitation, dichroic, and emission filtering required for capturing fluorescence excited near 405 nm. Intended as a drop-in accessory for compatible microscope filter turrets to enable bright, high-contrast imaging of blue/violet-excited fluorophores in research and clinical workflows.
- Provides 405 nm excitation band for fluorescence imaging.
- Includes matched excitation, dichroic, and emission filter elements.
- Designed for drop-in installation in compatible filter turret assemblies.
- Suitable for imaging DAPI, Hoechst, and similar 405 nm-excited fluorophores.
- Used in fixed and live-sample fluorescence microscopy workflows.
Sigma Aldrich Fine Chemicals Biosciences Hellma(R) fluorescence cuvettes, semi Micro Suprasil(R) quartz, spectral range 200-2500 nm, pathlength 10x4 mm, chamber volume 1000 muL | 1EA
Hellma(R) fluorescence cuvettes, semi Micro Suprasil(R) quartz, spectral range 200-2500 nm, pathlength 10x4 mm, chamber volume 1000 muL | 1EA
