Addition Funnels
Ace Glass, Inc. 250mL 15mm equalizing add funnel
250mL, 15mm equalizing addition funnel with graduations for use with ACE pressure reactors. Funnel is heavy walled and features a #15 Ace-Thred at the top, bottom drip tip, pressure equalizing arm, and 0-3mm threaded PTFE stopcock plug.
Ace Glass, Inc. Funnel, addition, jacketed, 500mL, 24/40 joints, 4mm PTFE stopcock
500mL graduated addition funnel with outside jacket for cooling and/or heating. Jacket extends from just below shoulder of vessel down to the bottom tube just below the stopcock. Stopcock is a 4mm bore PTFE plug. Bottom drip tube extends to the edge of the lower, 24/40 inner standard taper joint. Top outer reinforced joint is also 24/40. Side hose barbs are size D for 3/8 I.D. tubing.
Ace Glass, Inc. 250mL 24/40 addition funnel, PTFE stopcock plug, ungraduated
250mL short stem addition funnel with 24/40 top and bottom joints, and a PTFE stopcock plug. Funnel is not graduated.
Ace Glass, Inc. Funnel, addition, 1000mL, offset 24/40 bottom joint
Funnel, addition, 1000mL, offset 24/40 bottom joint
Chemglass Life Sciences 125mL Addition Funnel, Graduated, 24/40 Joint Size, 0-2mm PTFE Valve, 340mm OAH
125mL Addition Funnel, Graduated, 24/40 Joint Size, 0-2mm PTFE Valve, 340mm OAH. Cylindrical style graduated addition funnel has a threaded, grease-free extended tip valve. Design of all PTFE plug permits semi-needle valve action. With a standard taper top outer joint and lower inner joint, both being the same size, and pressure equalizing arm. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 60mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm PTFE Stpk, 220mm OAH
60mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm PTFE Stopcock, 220mm OAH. Cylindrical style addition funnel similar to CG-1710, but with a PTFE stopcock. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 25mL Addition Funnel, Graduated, 19/22 Joint Size, 2mm PTFE Metering Stpk, 205mm OAH
25mL Addition Funnel, Graduated, 19/22 Joint Size, 2mm PTFE Metering Stopcock, 205mm OAH. Cylindrical style addition funnel with a PTFE adjustable bore metering plug. Turning the adjustment knob allows flow rate to be controlled from dropwise to full flow. For replacement stoppers see CG-3000.
Chemglass Life Sciences 60mL Addition Funnel, 19/22 Joint Size, 2mm PTFE Stpk, 225mm OAH
60mL Addition Funnel, 19/22 Joint Size, 2mm PTFE Stopcock, 225mm OAH. Cylindrical style addition funnel with a standard taper top outer joint and lower inner joint, both being the same size. With pressure equalizing arm and PTFE stopcock. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 60mL Addition Funnel, 14/20 Joint Size, 2mm Stpk, 0-2mm PTFE Valve, 235mm OAH
60mL Addition Funnel, 14/20 Joint Size, 2mm Stopcock, 0-2mm PTFE Valve, 235mm OAH. Cylindrical style addition funnel with a threaded, grease-free extended tip valve. Design of all PTFE plug permits semi-needle valve action. With a standard taper top outer joint and lower inner joint, both being the same size, and pressure equalizing arm. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 25mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm Glass Stpk, 200mm OAH
25mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm Glass Stopcock, 200mm OAH. Cylindrical style addition funnel graduated with a double scale of numbers, one up from the stopcock and one down from the capacity line. With a standard taper top outer joint and lower inner joint, both being the same size, and pressure equalizing arm. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Ace Glass, Inc. 500mL graduated cylindrical funnel, 24/40 top, 24/40 bottom
500mL graduated cylindrical funnel with 24/40 joints at top and bottom. Features include drip stem, and double scale graduations calibrated from stopcock. Drip stem does not extend beyond the joint, thereby eliminating a possible source of breakage. Includes PTFE stopcock plug.
Chemglass Life Sciences 60mL Addition Funnel, Graduated, 19/22 Joint Size, 2mm PTFE Stpk, 230mm OAH
60mL Addition Funnel, Graduated, 19/22 Joint Size, 2mm PTFE Stopcock, 230mm OAH. Cylindrical style addition funnel similar to CG-1710, but with a PTFE stopcock. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 25mL Addition Funnel, 14/20 Joint Size, 2mm Glass Stpk, 200mm OAH
25mL Addition Funnel, 14/20 Joint Size, 2mm Glass Stopcock, 200mm OAH. Cylindrical style addition funnel with a standard taper top outer joint and lower inner joint, both being the same size. With pressure equalizing arm and glass stopcock. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 1000mL Addition Funnel, Graduated, 24/40 Joint Size, 4mm Glass Stpk, 525mm OAH
1000mL Addition Funnel, Graduated, 24/40 Joint Size, 4mm Glass Stopcock, 525mm OAH. Cylindrical style addition funnel graduated with a double scale of numbers, one up from the stopcock and one down from the capacity line. With a standard taper top outer joint and lower inner joint, both being the same size, and pressure equalizing arm. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 125mL Addition Funnel, 24/40 Joint Size, 2mm PTFE Stpk, 325mm OAH
125mL Addition Funnel, 24/40 Joint Size, 2mm PTFE Stopcock, 325mm OAH. Cylindrical style addition funnel with a standard taper top outer joint and lower inner joint, both being the same size. With pressure equalizing arm and PTFE stopcock. For replacement stoppers see CG-3000.
