Tubing Connectors and Fittings
New Jersey Fluid Systems LLC MALE CONNECTOR
316 Stainless Steel Swagelok Tube Fitting Male Connector. 3/8 in. OD x 1/4 in. Male NPT
New Jersey Fluid Systems LLC QUICK CONNECT
316 Stainless Steel Swagelok QC4 in. series Quick Connect Shut-OFF Stem; 1/4 in. OD Tube Fitting end; Viton o-ring; 3,000psi @100F
Hanna Pharmaceutical Supply Co., Inc. LUER LOCK ADAPTOR 100/PCK
LUER LOCK ADAPTOR 100/pCK
Please note: This item is nonrefundable, non-returnable and non-cancelable once order is placed.
Chemglass Life Sciences Chemglass Distilling Column, Vacuum-Jacketed, 45/50 Outer to 65/40 O-Ring Ball Joint
This vacuum-jacketed distilling column is designed for use in distillation assemblies and reactor distillation cart systems. It provides a secure transition from a 45/50 outer joint (top) to a 65/40 O-ring ball joint (bottom), and is intended for use with compatible distillation kits and process reactor setups.
- Vacuum jacketed construction for improved thermal control and reduced heat loss.
- 45/50 outer joint (top) to 65/40 O-ring ball joint (bottom) for secure, standardized connections.
- Designed for installation in distillation assemblies and distillation cart systems.
- Compatible with standard reactor distillation kit configurations and cart-mounted distillation systems.
Chemglass Life Sciences Chemglass High Flow Manifold System for Process Reactor - 50 L (400 mm flange), M30 circulator end fitting (CG-1969-M-08)
High Flow Manifold System provides a secure, high-volume connection between a temperature-controlled circulator and a process reactor. Supplied complete, it facilitates efficient heat transfer and safe fluid handling for 50 L reactors with 400 mm flanges.
- Includes inlet and outlet manifold block.
- Supplied with 3 ft and 4 ft triple insulated flexible hoses.
- Hoses use a 3/4 in male NPT connection to the manifold block and a beaded pipe fitting for the reactor.
- Includes two 3/4 in male NPT plugs and a tube of thread sealant.
- Designed for high-flow connection to 50 L reactors with 400 mm flanges.
- Circulator end fitting is an M30 male connection.
- Hose temperature range -60 to 200 °C.
- Clamp attaches to a support frame for installation; reactor coupling sold separately.
Chemglass Life Sciences Chemglass Air Operated Lower Drain Valve for 10-50 L Reactors (CG-1968-V-01)
Air-operated flush bottom drain valve designed for 10 L-50 L reactors with a 2 in beaded pipe connection. The valve is held closed by spring tension and opens when air pressure is applied. Supplied as a complete kit with an air control panel, two regulators, a mounting bracket, tubing, and fittings. Suitable for solvent extractions and controlled drain operations; not recommended for slurries or viscous materials.
- Constant spring tension prevents leakage during low-temperature reactions.
- Air-operated for rapid, controlled opening and closing.
- Secondary regulator provides 4 psi safety backup.
- Wetted parts of PTFE with 316L stainless steel shaft for corrosion resistance.
- Includes air control panel, two regulators, mounting bracket, tubing, and fittings.
- Control panel can be mounted outside a hood and positioned using a universal clamp.
Chemglass Life Sciences Chemglass Chem-Spin Rotary Scraper Tool, Individual - Fits 100 mL Round Bottom Flasks (CG-1981-C100)
The Chem-Spin rotary scraper is a motor-driven scraping tool designed to remove dried solids from the interior walls of 100 mL round bottom flasks quickly and with minimal effort. Constructed from stainless steel and PTFE, the tool is laser-etched for clear identification and designed to work with standard laboratory joints.
- Removes dried solids from flask walls with minimal manual effort.
- Constructed of stainless steel and PTFE for chemical resistance.
- Designed to fit 100 mL round bottom flasks.
- Compatible with 24/40 or larger standard taper joints.
- Laser-etched size and identification for easy inventory control.
IDEX Health & Science Upchurch BARBED TO FEMALE LUER ADAPTER
NC3592517 BARBED TO FEMALE LUER ADAPTER
Accuflow Systems 1"/1.5" TC x 1/8" ID Polypropylene Bio Barb Adapter
1"/1.5" TC x 1/8" ID Polypropylene Bio Barb Adapter with true-bore ID are designed for use in GMP Manufacturing and laboratories. These Bio Barb adapters can be autoclavable as well as gama irradiated. Constructed of USP Class VI Polypropylene. Designed for Sanitary Tri clamp applications. Max working pressure, 150psi @ 70? F, Pack of 10
Accuflow Systems 1"/1.5" TC x 3/8" ID Polypropylene Bio Barb Adapte
1"/1.5" TC x 3/8" ID Polypropylene Bio Barb Adapter with true-bore ID are designed for use in GMP Manufacturing and laboratories. These Bio Barb adapters can be autoclavable as well as gama irradiated. Constructed of USP Class VI Polypropylene. Designed for Sanitary Tri clamp applications. Max working pressure, 150psi @ 70? F, Pack of 10
