pH, ORP, and Titration, Combination Electrodes
World Precision Instrument STX HTS EVOM Electrode for CORNING 96
Semi-permeable HTS (high throughput screening) culture plates have become a standard tool for pharmaceutical and institutional research in epithelial transport. HTS culture plates have well cups which are bonded together into a single assembly and are not removable. This makes the plates ideal for automated applications, but imposes a significant inconvenience when TEER must be measured in the absence of an automated system. WPI’s STX HTS series of EVOM™ electrodes, replacing the STX100 electrodes, provide a cost-effective alternative to automation, allowing HTS well plates to be measured manually using a hand–held electrode.
To learn more about our warranty options, click here.
World Precision Instrument Carbon Fiber Electrode, L 100 um
Electrochemical detection of oxidizable compounds
Carbon fiber microelectrodes have been used in both the detection of oxidizable compounds (Gonon, et al., 1978; Cahill and Wightman, 1995) and extracellular single-unit recording (Armstrong-James and Millar, 1979). WPI™s ultra-sensitive and low-noise carbon fiber (CF) electrodes can be applied, with our Micro-C Potentiostat or similar instruments, in the electrochemical detection of catecholamines (epinephrine, norepinephrine and dopamine), indolamines (serotonin, 5-HT or melatonin), Fe (II) and other oxidizable compounds.
World Precision Instrument Electrode Adapter for DAM50 Bioamplifier
Simplify your input connections to the DAM50 when you are setting up your applications
This optional electrod adapter is designed for use with the DAM50 Bioamplifier. See some of the sample setups possible with this component in the Details below.
World Precision Instrument Carbon Fiber Electrode, Length 50 um
Electrochemical detection of oxidizable compounds
Carbon fiber microelectrodes have been used in both the detection of oxidizable compounds (Gonon, et al., 1978; Cahill and Wightman, 1995) and extracellular single-unit recording (Armstrong-James and Millar, 1979). WPI™s ultra-sensitive and low-noise carbon fiber (CF) electrodes can be applied, with our Micro-C Potentiostat or similar instruments, in the electrochemical detection of catecholamines (epinephrine, norepinephrine and dopamine), indolamines (serotonin, 5-HT or melatonin), Fe (II) and other oxidizable compounds.
World Precision Instrument Electrode Handle 4.0 mm
Electrode holder for popular manipulators
This 4.0 mm electrode holder is designed for use with Narishige and Zeiss manipulators
Hach Company Radiometer Analytical PHC2011-8 Combination Red-Rod pH Electrode for Alkaline Samples (alkaline glass, glass body, BNC)
The Radiometer PHC2011-8 Combination pH Electrode has a glass body, Red-Rod reference system, refillable electrolyte (sat. KCl) and porous pin junction. The PHC2011-8 has a glass membrane specific for alkaline samples. The PHC2011-8 is compatible with Hach Sension+ laboratory pH meters (or any meter with a BNC connection).
Hach Company Radiometer Analytical PHG311-9 Glass pH Electrode for Alkaline Samples (alkaline glass, screw cap)
The Radiometer PHG311 pH Electrode has a glass body and pH membrane specifc for alkaline samples. The PHG311 should be used with Ag/AgCl or calomel reference electrodes for general purpose applications. The PHC311-9 is a screw cap electrode and requires the CL114 cable (part no. A94L114) for compatibilty with Hach Sension+ laboratory pH meters (or any meter with a BNC connection).
Hach Company Radiometer Analytical PHC3005-9 Combination pH Electrode (epoxy body, Ag/AgCl ref., screw cap)
The Radiometer PHC3005-9 Combination pH Electrode has a robust epoxy body, Ag/AgCl reference system, refillable electrolyte (3M KCl + sat. AgCl) and porous pin junction for general purpose applications. The PHC3005-9 is a screw cap electrode and requires the CL114 cable (part no. A94L114) for compatibilty with Hach Sension+ laboratory pH meters (or any meter with a BNC connection).
Hach Company Radiometer Analytical M231Pt Metal Electrode (platinum wire sensor, screw cap)
The Radiometer M231Pt Metal Electrode has a platinum wire sensor and is recommended for general purpose measurements. An external reference electrode is required. The M231Pt is a screw cap electrode and requires the CL114 cable (part no. A94L114) for use with Hach Sension+ laboratory and other BNC-compatible meters/titrators.
Hach Company Sension+ 5056 laboratory ORP electrode for general applications
Sension+ 5056 is a combination platinum ORP electrode with a glass body and non-refillable gel-electrolyte reference. The 5056 has a fixed 1 meter cable and BNC connector dedicated for use with Hach Sension+ Laboratory pH (mV) meters. The 5056 has a ceramic junction is ideal for oxidation-reduction potential (ORP) measurements in general aqueous applications.
Hach Company Sension+ 5014T pH liquid combination electrode, with silver ion barrier
pH liquid electrode (refillable) with 2 ceramic diaphragms and silver ion barrier. Automatic temperature compensation. Glass body. Range 0-14 pH, -10 to 100 ºC. 1 m cable. For Laboratory Meter.This pH electrode is suitable for aqueous media in general and for samples containing sulphurs, reducing sugars or other substances which react with silver ions.Reference electrode stability due to sleeved cartridge and Ag+ ion barrier design.
Hach Company Intellical™ MTC101 Field Low Maintenance Gel Filled ORP/RedOx Electrode, 15 m Cable
Intellical™ MTC101 is a digital combination oxidation reduction potential (ORP/RedOx) electrode with built-in temperature sensor. MTC101 has low maintenance needs thanks to a non-refillable gel-filled single open reference junction. This Rugged MTC101 version is built with a stainless steel body ensuring sufficient weight to the probe for an easy outside handling, the Metal Platinum sensing part is protected by a shroud, and the connection is ensured by strong and visible yellow coloured cable onto which you can clip depth markers (optional accessories), making the MTC101 rugged models specially designed for field use. MTC101 Rugged is available with a 5, 10, 15, or 30 meters cable. The MTC101 Rugged is ideal for measuring ORP/RedOx absolute mV values in all types of external environment such as river, surface and ground waters, ponds, lakes, sea, wastewater plant, source water, drinking water reservoir for water quality, environmental and treatment process purposes.
Hach Company Intellical™ PHC101 Laboratory Low Maintenance Gel Filled pH Electrode, 1 m Cable
Intellical™ PHC101 is a digital combination pH electrode with built-in temperature sensor. PHC101 has low maintenance needs thanks to a non-refillable gel-filled single open reference junction. The laboratory version of this pH electrode is shockproff with its epoxy plastic body protecting down to the glass bulb sensing element. The Electrode is available with a 3 or 1 m cable. The PHC101 electrode is ideal for measuring pH in wastewater, drinking water and general aqueous applications. The PHC101 is not suitable for use with organic solvents or samples with pH less than 2.
Hach Company Intellical™ MTC101 Laboratory Low Maintenance Gel Filled ORP/RedOx Electrode, 3 m Cable
Intellical™ MTC101 is a digital, combination oxidation reduction potential (ORP/Redox) electrode with a non-refillable, gel-electrolyte reference and built-in temperature sensor. MTC101 has low maintenance needs thanks to a non-refillable gel-filled single open reference junction. The laboratory version of this metallic electrode is shockproff with its epoxy plastic body protecting down to the platinum sensing element. The Electrode is available with a 3 or 1 m cable. The MTC101 electrode is ideal for measuring ORP/RedOx absolute mV values in wastewater, drinking water and aqueous media applications. The MTC101 is not suitable for use with organic solvents.
Hach Company 3/4 Inch Combination pH/ORP Sensor, Convertible Style, Ryton Body Material, Flat Glass General Purpose pH Electrode, Temperature Compensation - PT1000 ohm RTD, 15 ft cable
Ryton, Convertible Body Style, 4.5m Analog Cable, General Purpose Flat Glass pH Electrode, Pt 1000 Temperature Compensation
