Clamps
Adjustable devices designed to securely hold two objects together or to hold an object in place; used with standard-taper and ball-and-socket joints, glass and tubing assemblies, and with ring stands. Available as plastic joint clips, stainless steel pinch clamps, and taper clips.
A laboratory clamp is an essential piece of equipment used to support and secure labware and other laboratory apparatus such as flasks, reaction vessels, tubing, thermometers, probes, columns, funnels, and overhead stirrers.
Some laboratory clamps consist of a shaft and boss head, secured with hand-tightened thumbscrews, knurled nuts, or wingnuts onto a supporting rod, stand or scaffold. They may also include two- or three-pronged, adjustable closing jaws designed for gripping objects safely and securely.
Laboratory clamps are constructed of metals such as stainless steel, nickel-plated zinc, plated brass or diecast aluminum alloy for enhanced chemical, heat, and corrosion resistance. However, some components such as the adjusting screws may be made of plastic, and the prongs may also be lined or covered with cork, plastic, glass-fiber, or rubber for enhanced grip with minimal damage or breakage.
Laboratory Clamp Styles and Designs
• Universal, general-purpose clamps that are fully adjustable for accommodating and securing a wide range of items of different sizes such as columns and thermometers
• Retort clamps for securing round-bottom flasks and similar glassware
• Fork clamps for securing and supporting cone-and-socket ground glassware joints
• Three-prong extension clamps, sometimes available with spring-loaded jaws, for holding irregularly shaped or outsized objects
• Specialized clamps for securing burettes and condensers or reaction vessels
• Chain clamps, which incorporate a circular, adjustable chain loop to hold cylinders and beakers
Chemglass Life Sciences Clamp, Keck, Blue, Standard Taper, Fits Joint Sizes 19/22 & 19/38
Clamp, Keck, Blue, Standard Taper, Fits Joint Sizes 19/22 & 19/38. Made of Delrin, the clamp is non-corrosive and will not scratch glass. Can be used to 140 C. Color coded for easy identification. SOLD IN PACKAGES OF 10.
Ace Glass, Inc. 17-22mm diameter stainless steel hose clamp
17-22mm diameter stainless steel hose clamp. Adjustable, with hex head finger nut.
Chemglass Life Sciences Clamp, Column, Large, 121mm to 140mm Clamping Range
Clamp, Column, Large, 121mm to 140mm Clamping Range. Ideal for Chromatography columns and large cylindrical glassware, the column clamp is constructed of stainless steel. Large, flat thumb screw on the worm drive permits tightening and removing.
Chemglass Life Sciences Clamp, Pinch, Stainless Steel, #75
Clamp, Pinch, Stainless Steel, #75. Made entirely of stainless steel. Part numbers CG-150-01 and CG-150-03 are supplied WITHOUT a screw type locking device. All other sizes have the screw type locking device.Note: The size #102 Stainless Steel pinch clamp is available on a special order basis.
Chemglass Life Sciences Clamp, Keck, Blue, Spherical Joint, Fits Joint Sizes 18/7 & 18/9
Clamp, Keck, Blue, Spherical Taper, Fits Joint Sizes 18/7 & 18/9. Made of Delrin, these clamps are non-corrosive and will not scratch glass. Can be used to 140 C. Color coded for easy identification. SOLD IN PACKAGES OF 10.
Chemglass Life Sciences Clamp, Keck, Red, Standard Taper, Fits Joint Sizes 29/26 & 29/42
Clamp, Keck, Red, Standard Taper, Fits Joint Sizes 29/26 & 29/42. Made of Delrin, the clamp is non-corrosive and will not scratch glass. Can be used to 140 C. Color coded for easy identification. SOLD IN PACKAGES OF 10.
Chemglass Life Sciences Clamp, Keck, Brown, Standard Taper, Fits Joint Size 45/50
Clamp, Keck, Brown, Standard Taper, Fits Joint Size 45/50. Made of Delrin, the clamp is non-corrosive and will not scratch glass. Can be used to 140 C. Color coded for easy identification. SOLD IN PACKAGES OF 10.
Chemglass Life Sciences Clamp, Three-Prong Extension, Large, Single Adjust, 9.76in OAL
Clamp, Three-Prong Extension, Large, Single Adjust, 10 1/2in OAL. Nickel-plated zinc alloy clamp has high tensile strength and corrosion resistance. Fully enclosed stainless steel springs provide smooth operation. Three-prong clamps are available in single and dual adjustment. The small clamp has a 1¿ (25mm) maximum grip size with a 1/4¿ (6mm) O.D. extension arm. The medium clamp has a 1 1/2¿ (38mm) maximum grip size with a 1/2¿ (13mm) O.D. extension arm. The large clamp has a 2 1/2¿ (64mm) maximum grip size with a 5/8¿ (16mm) O.D. extension arm. Complete with removable vinyl and fiberglass covers for easy cleaning.
Grainger 5/16" Wide, Interlocked Worm Gear Hose Clamp, 10/pk
Interlocked worm gear hose clamp helps secure many types of hoses, including pneumatic and exhaust hoses. This general-purpose hose clamp is interlocked to prevent shearing, while clamps used for exhaust have no holes, preventing marring of the hose and fumes escaping. Gear clamp resists rust and corrosion and are useful in humid or damp conditions.10/pk
Ace Glass, Inc. Open ring support, PVC coated aluminum, 4in OD, 3-1/4in ID, 12in arm
4" PVC coated open ring support has 12" extension arm for supporting glassware, such as separatory funnels and powder funnels, from the bottom. The long extension arm allows for easier connection to labframes or stands.
Chemglass Life Sciences Clamp, Pinch, Stainless Steel, #12
Clamp, Pinch, Stainless Steel, #12. Made entirely of stainless steel. Part numbers CG-150-01 and CG-150-03 are supplied WITHOUT a screw type locking device. All other sizes have the screw type locking device.Note: The size #102 Stainless Steel pinch clamp is available on a special order basis.
Ace Glass, Inc. Joint clips, 19/22, Keck; type, POM acetal resin, not for positive pressure use, blue, pk/10
19/22 blue Keck type joint clips made from POM acetal resin. Clips will not scratch the glass, and are resistant to concentrated alkalies and dilute acids. Useful temp range: -40 to 140 C. Not for pressure applications. Pk/10.
