Distillation Labware
Glassware and replacement parts designed to carry out distillations in laboratory settings; includes condensers, distillation heads, receivers, etc. Products are available for various scales and for specialty distillations.
Distillation is a process used widely in the laboratory or in wider working environments for separating or purifying liquids or liquid mixtures based on the different boiling points of individual components.
Distillation Applications:
• Separation and purification of miscible liquid mixtures in organic chemistry
• Drying of solid residues and/or solvent removal
• Fractional distillation of liquids from polymers and petroleum products
• Removal of particulates or other solid contaminants
• As part of a water purification system for production of distilled water for laboratory use
• Specialist steam distillation-based applications such as Kjeldahl analysis of nitrogen and proteins in food, beverage, or environmental samples
What Types of Distillation Equipment Are Available?
Conventional distillation apparatus, typically comprising individual, jointed borosilicate glassware components assembled by the user (depending upon the application), using appropriate clamps, stands, and supports. Most conventional distillation assemblies combine a round-bottomed distilling flask to contain and heat the liquid(s) that require purification, fitted with a stoppered or jointed neck to which is attached a downward-sloping, inclined side-arm for connection to a condensing unit to cool the heated vapors back down to their liquid state. Heating mantles are the preferred heat source for improved temperature control. These conventional distillation units are also available supplied complete and ready-assembled for added convenience and ease of use.
Specialized automated distillation equipment, notably units designed for the determination of volatile acidity and alcoholic strength by volume in wines, musts, and alcoholic beverages, and units designed for Kjeldahl nitrogen or protein determinations.
Chemglass Life Sciences Distilling Receiver, 25mL, Moisture Test, Dean-Stark, 24/40 Joint Size, Approx. 330mm Height x 90mm Width
Distilling Receiver, 25mL, Moisture Test, Dean-Stark, 24/40 Joint Size, Approx. 330mm Height x 90mm Width. Similar to CG-1258 but with the addition of an overflow tube between the uptake tube and the graduated receiver.
Chemglass Life Sciences Distilling Receiver, 10mL, Moisture Test, Barrett, 19/22 Joint Size, 2mm PTFE Stopcock , Approx. 190mm Height x 65mm Width
Distilling Receiver, 10mL, Moisture Test, Barrett, 19/22 Joint Size, 2mm PTFE Stopcock , Approx. 190mm Height x 65mm Width. Barrett style distilling receiver used to determine the water content in petroleum or bituminous material. Receiver is made according to ASTM specifications, with the addition of the top outer standard taper joint and lower stopcock. The 2mL has sub-divisions of 0.02mL; the 5ml has subdivisions of 0.20mL; 10ml has subdivisions of 0.1mL; the 20mL has subdivisions of 0.2 from 0 to 3mL and 0.5 from 3 to 20mL. Available with glass or PTFE stopcocks.
Chemglass Life Sciences Distilling Receiver, 20mL, Moisture Test, Barrett, 29/42 Joint Size, 2mm PTFE Stopcock, Approx. 325mm Height x 95mm Width
Distilling Receiver, 20mL, Moisture Test, Barrett, 29/42 Joint Size, 2mm PTFE Stopcock, Approx. 325mm Height x 95mm Width. Barrett style distilling receiver used to determine the water content in petroleum or bituminous material. Receiver is made according to ASTM specifications, with the addition of the top outer standard taper joint and lower stopcock. The 2mL has sub-divisions of 0.02mL; the 5ml has subdivisions of 0.20mL; 10ml has subdivisions of 0.1mL; the 20mL has subdivisions of 0.2 from 0 to 3mL and 0.5 from 3 to 20mL. Available with glass or PTFE stopcocks.
Chemglass Life Sciences Joint Size: 24/40, Capacity mL: 20, Stopcock Size: 2mm, Approx. Height x Width (mm): 325 x 125
Graduated distilling receiver with a standard taper outer joint on top and a standard taper lower drip joint. Distance between the receiver and the uptake arm: 10 and 20mL are 100mm center to center; the 50, 100 and 250mL are 150mm center to center. Joint Size: 24/40, Capacity mL: 20, Stopcock Size: 2mm, Approx. Height x Width (mm): 325 x 125.
Chemglass Life Sciences Vacuum Trap, 1000mL Capacity, Fits 4300mL Dewar Flask, 340mm OAH x 130mm Width, Complete
Vacuum Trap, 1000mL Capacity, Fits 4300mL Dewar Flask, 340mm OAH x 130mm Width, Complete. Trap is designed for large volume solvent removal by vacuum. The 40/35 standard taper joint connects trap body with stopper. Connections are 1/2in O.D. Trap is designed to fit into standard CG-1593 through CG-1595 Dewar flasks.
Chemglass Life Sciences Vacuum Trap, 1000mL Capacity, Fits 4300mL Dewar Flask, 400mm OAH x 130mm Width, Complete
Vacuum Trap, 1000mL Capacity, Fits 4300mL Dewar Flask, 400mm OAH x 130mm Width, Complete. Similar to CG-4529, but having a 40mm o-ring joint to connect the trap body to the stopper. O-ring joint provides for a vacuum-tight grease-free seal and permits the trap body to be easily disconnected from the stopper for cleaning. Complete trap is supplied with a stopper, trap body and CG-150-09 clamp.
Chemglass Life Sciences Vacuum Trap, 38mm Body OD x 250mm Body Length, 18mm OD Side and Inner Tubes
Vacuum Trap, 38mm Body OD x 250mm Body Length, 18mm OD Side and Inner Tubes. One piece trap used in the removal of undesired vapors in the vacuum system by condensation. Vacuum Trap, 38mm Body OD x 250mm Body Length, 18mm OD Side and Inner Tubes.
Ace Glass, Inc. 0.16" 316 stainless steel packing
0.16 316 stainless steel PRO-PAK distillation packing. An efficient protruded metal dump-packing for distillation columns of 0.75 to 12 diameter. Suitable for both atmospheric and reduced pressures down to 10mm Hg condenser pressure.
Ace Glass, Inc. Trap, bump, drain holes, 100mL, 24/40 top, 24/40 bottom
100mL bump trap for use between a rotary evaporators steam tube and evaporator flask, preventing fluid from being drawn into the condenser. Trap has 24/40 top and bottom joints. Improved design incorporates two drain holes to expedite the return of solvent to the evaporator flask.
Chemglass Life Sciences Condenser, Reflux, 445mm, 29/42 Joint, 300mm Jacket Length
Condenser, Reflux, 445mm, 29/42 Joint, 300mm Jacket Length. Reflux condenser having an internal coil that is water jacketed. Vapors are condensed both on the coil and the inner wall of the jacket. The top end has a standard taper outer joint and the lower end has an inner drip tip joint. Hose connections have an O.D. of 10mm at the middle serration.
Petroleum Analyzer Corporation CRM W/Cert ASTM D86 Diesel 255Ml
CRM Atm Distillation Diesel appr. 170 to 370°C, 255ml
Chemglass Life Sciences Condenser Tube Only, Minum-Ware, 14/10
Condenser Tube Only, Minum-Ware, 14/10. Vertically adjustable condenser tube having an O.D. of 7mm.
Petroleum Analyzer Corporation Pour Point Test Tube complies with requirements of ASTM D5950
Pour Point Test Tube complies with requirements of ASTM D5950 & D97
Hach Company Tube, Drip
Borosilicate glass drip tube with 7 mm outside diameter, 45° bevel tip. Body is 17 mm outside diameter and 145 mm in length with a 20 to 400 screw-thread finish. Use on Hach Distillation Apparatus.
Chemglass Life Sciences Distillation Vessel, 500mL, Receiving, Cylindrical, 105mm OD, ChemRxnHub, Compatable with CG-1947-A100
Distillation Vessel, 500mL, Receiving, Cylindrical, 105mm OD, ChemRxnHub, Compatible with CG-1947-A100. Cylindrical shaped distillation receiving vessel for use with ChemRxnHub benchtop systems for collecting distillate. The top of the vessel has two 0-8 Chem-cap valves with 1/2¿ OD Swagelock side arms that offer a convenient way to connect the receiver to CG-1975 PTFE tubing and compression fittings. Bottom of vessel has 0-14 drain valve with a 1/2¿ OD swagelock sidearm. The body of vessel has approximate volume graduations on the front and back. Vessel body diameter is compatible with CG-1947-A clamps which provide an easy way to support the receiver on the frame or hood lattice.
