Distillation Labware
Glassware and replacement parts designed to carry out distillations in laboratory settings; includes condensers, distillation heads, receivers, etc. Products are available for various scales and for specialty distillations.
Distillation is a process used widely in the laboratory or in wider working environments for separating or purifying liquids or liquid mixtures based on the different boiling points of individual components.
Distillation Applications:
• Separation and purification of miscible liquid mixtures in organic chemistry
• Drying of solid residues and/or solvent removal
• Fractional distillation of liquids from polymers and petroleum products
• Removal of particulates or other solid contaminants
• As part of a water purification system for production of distilled water for laboratory use
• Specialist steam distillation-based applications such as Kjeldahl analysis of nitrogen and proteins in food, beverage, or environmental samples
What Types of Distillation Equipment Are Available?
Conventional distillation apparatus, typically comprising individual, jointed borosilicate glassware components assembled by the user (depending upon the application), using appropriate clamps, stands, and supports. Most conventional distillation assemblies combine a round-bottomed distilling flask to contain and heat the liquid(s) that require purification, fitted with a stoppered or jointed neck to which is attached a downward-sloping, inclined side-arm for connection to a condensing unit to cool the heated vapors back down to their liquid state. Heating mantles are the preferred heat source for improved temperature control. These conventional distillation units are also available supplied complete and ready-assembled for added convenience and ease of use.
Specialized automated distillation equipment, notably units designed for the determination of volatile acidity and alcoholic strength by volume in wines, musts, and alcoholic beverages, and units designed for Kjeldahl nitrogen or protein determinations.
Chemglass Life Sciences Distilling Receiver, 12mL, 14/20, Complete, Approx. 175mm Height x 240mm Width
Distilling Receiver, 12mL, 14/20, Complete, Approx. 175mm Height x 240mm Width. The 135º angle between the center line of the condenser and the receiver tubes allows the distillate to fall directly into the receiver tubes. This receiver can be used with short path style distilling heads. Complete receiver is supplied with distribution adapter, three 12mL receiver tubes, and six CG-110 stainless steel springs.
Chemglass Life Sciences Distilling Head, Short Path, Jacketed, Vigreux Indents, 10/18 Thermometer Joint, 14/20 Lower Inner Joint, Approx. 105mm Width x 105mm Height
Distilling Head, Short Path, Jacketed, Vigreux Indents, 10/18 Thermometer Joint, 14/20 Lower Inner Joint, Approx. 105mm Width x 105mm Height. Similar to CG-1239 but vacuum jacketed to improve efficiency. Available with Vigreux indentations in uptake tube to further increase the performance of the head. NOTE: The 14/20 size accepts a 1” immersion 7/12 or 10/18 thermometer, while the 24/40 and 29/42 sizes accept a 2” immersion, 10/30 thermometer.
Chemglass Life Sciences Vacuum Trap, Removable Arms, Complete
Vacuum Trap, Removable Arms, Complete. Vacuum trap features removable arms to permit the trap to be easily disconnected for cleaning. The arms are made to permit clamping directly to the lattice and accept 5/8in I.D. vacuum hose. Trap and arms have 35/25 spherical joints for added flexibility while providing a leak-free seal. Supplied complete with one each of arm style “A” (180º), one each of arm style “B” (90º) and one each of arm style “C” (straight), and two CG-150-06 #35 stainless steel pinchclamps. The trap body is 2in (50mm) O.D. x 360mm long.
Chemglass Life Sciences J-Kem Temperature Controller, Model 260/T, Type "J" (-0°C to 800°C), Complete
J-Kem Temperature Controller, Model 260/T, Type "J" (-0C to 800C), Complete. The Model 260/T disconnects all output power it the process temperature exceeds the entered temperature by a user-specified amount, or following recovery from a power failure. The outputs remain disconnected until manually reset. Over temperature condition is signalled by an indicator lamp and audible alarm. The Model 260/T has 1800 Watts of power which is sufficient for heating mantles up to 22L. Controller has the ability to display temperature without heating. The Model 260/T is also equipped with a100 hour digital timer to turn heating ON or OFF when time has expired.PLEASE NOTE: THE TYPE T, J AND K CONTROLLERS ARE SUPPLIED COMPLETE WITH: 1/8 DIAMETER X 12 LONG PTFE COATED THERMOCOUPLE, 10FT COILED EXTENSION CORD, AND A 14/20 PTFE THERMOCOUPLE ADAPTER. Specifications:Dimensions: 3.25" H x 7.5" W x 9" DPower: 15 Amps @ 120VAC, 1800 Watts
Chemglass Life Sciences Saddles, Berl, 200cc, Porcelain, Distilling Column, Approx. 250 Pieces/Package
Saddles, Berl, 200cc, Porcelain, Distilling Column, Approx. 250 Pieces/Package. Porcelain berl saddles having an O.D. of 8mm. Ideal for vacuum distillation, absorption and extraction. Saddles provide a highly useable surface area, lower gas flow resistance and excellent internal distribution. Available in packages of 200cc and 1000cc boxes.
Chemglass Life Sciences Coil Condenser Insert, Type "C"
Coil Condenser Insert, Type "C". Insert allows the conversion of a "C" type dry ice condenser for use with either tap water or a chilled circulator. Inlet and outlet are GL-14 threads and supplied complete with caps and detachable hose connections. Also supplied with a PTFE centering ring.
Chemglass Life Sciences Distilling Receiver, 3mL, 14/20 Joint, Graduated, 210mm height x 90mm width
Distilling Receiver, 3mL, 14/20 Joint, Graduated, 210mm height x 90mm width. Cow type receiver has a single standard taper outer joint at the top. The four lower graduated receiver tubes can be accessed via a syringe for product recovery. Tubes are graduated from 0 to 3mL in 0.2mL subdivisions.
Chemglass Life Sciences Distilling Column, 19/22 Joint, 130mm, Vigreux
Distilling Column, 19/22 Joint, 130mm, Vigreux. Vigreux style column with indentations that run the entire length of the column for improved vapor-liquid contact. Column length refers to the effective length, measured from the lowest to highest indent in the column. Column has a top outer and lower inner standard taper joint.
Chemglass Life Sciences Distilling Column, 14/20 Joint, 130mm, Vigreux
Distilling Column, 14/20 Joint, 130mm, Vigreux. Vigreux style column with indentations that run the entire length of the column for improved vapor-liquid contact. Column length refers to the effective length, measured from the lowest to highest indent in the column. Column has a top outer and lower inner standard taper joint.
Chemglass Life Sciences Distillation Head, Micro, Vigruex, 10/18 Thermometer Joint, 14/20 Outer Joint, Approx. 195mm Height x 185mm Width
Distillation Head, Micro, Vigruex, 10/18 Thermometer Joint, 14/20 Outer Joint, Approx. 195mm Height x 185mm Width. Distillation head with condenser sealed to a Vigreux column. Top thermometer joint is a 10/18 for use with a 1” immersion thermometer. Vacuum adapter has an outer joint and accepts a CG-1279-11 distribution adapter.
Chemglass Life Sciences Distilling Column, 24/40 Joint, 250mm, Vacuum Jacketed
Distilling Column, 24/40 Joint, 250mm, Vacuum Jacketed. Hemple style distilling column, vacuum jacketed to improve performance. Indentations on the inner tube support the packing material. All sizes have an I.D. of approximately 10mm.
Chemglass Life Sciences Distilling Receiver, 10mL, Moisture Test, Dean-Stark, 24/40 Joint Size, Approx. 250mm Height x 90mm Width
Distilling Receiver, 10mL, Moisture Test, Dean-Stark, 24/40 Joint Size, Approx. 250mm Height x 90mm Width. Dean-Stark receiver used for determining the water content of various materials. Can be used with ASTM Method D-95 along with similar ASTM methods. The 10mL size has subdivisions of 0.1 from 0 to 2mL, and 0.2 from 2 to 10mL. The 25mL size has subdivisions of 0.1 from 0 to 2mL and 0.2 from 2 to 25mL.
Chemglass Life Sciences Adapter Only, Distribution, 24/40 Joint
Adapter replacement part for the CG1276 series of cow type design distillation receivers. 24/40 Joint. Adapter only.
