General Spectrometer Accessories
Perkin Elmer US LLC MEINHARD Concentric Glass Nebulizer, Type K1
The MEINHARD concentric glass nebulizer reflects exacting standards in design and manufacturing. Its advantages include simplicity of design and operation, reproducible and self-aligning aerosol, and close fabrication control. They provide excellent sensitivity and precision for aqueous solutions and samples with few dissolved solids (less than 1%). It includes Standard Nebulizer Solution Fitting, 0.5 mm PTFE capillary tubing (N0777414), PFA Gas Quick Connect (N8121036), and Nebulizer Clip for MEINHARD Nebulizers (N0777460).
Glass Expansion Contour Flared End PVC Pump Tube 3tag, 72mm spacing, 1.52mm ID, Yellow/Blue (PKT 6)
Contour Flared End PVC Pump Tube 3tag 1.52mm ID Yellow/Blue (PKT 6).Tag Colors: Yellow/BlueID mm: 1.52Wall Thickness mm: 0.86OD mm: 3.24Overall Length: 455mm (72mm spacing between tags)Number of Tubes Per Pack: 6Physical Properties: Thermoplastic, PVC based material with plasticizerMaterial: Made from Tygon R3603/R3607 or equivalent.Special Properties: Inexpensive all-around tubing for general laboratory applicationsChemical Compatibility: Excellent for aqueous solutions of the following acids and concentrations, up to 35% Nitric Acid, up to 37% Hydrochloric Acid, up to 25% Hydrofluoric Acid, up to 30% Hydrogen Peroxide.Limitations: Potential leaching of plasticizersGlass Expansion is ISO 9001:2015 certified by AB Certification, No. AU4501-9001
Glass Expansion Solva Flex Pump Tube 2tag, 140mm spacing, 1.30mm ID, Grey/Grey (PKT 12)
Solva Flex Pump Tube 2tag, 140mm spacing, 1.30mm ID Gray/Gray (PKT 12).Tag Colors: Gray/GrayID mm: 1.30Wall Thickness mm: 0.86OD mm: 3.02Overall Length: 455mm (140mm spacing between tags)Number of Tubes Per Pack: 12Physical Properties: Thermoplastic, PVC based material with plasticizerMaterial: Made from Tygon 4040 or equivalent.Special Properties: Special tubing for hydrocarbons, petroleum products and distillates.Chemical Compatibility: Ideal for gasoline, kerosene, heating oils, cutting liquids and coolants based on glycols.Limitations: Not recommended for strong acids and alkalis, foodstuffs, beverages and medicines. Potential leaching of plasticizersGlass Expansion is ISO 9001:2015 certified by AB Certification, No. AU4501-9001
Glass Expansion Solva Flex Pump Tube 2tag, 140mm spacing, 1.85mm ID, Green/Green (PKT 12)
Solva Flex Pump Tube 2tag, 140mm spacing, 1.85mm ID Green/Green (PKT 12).Tag Colors: Green/GreenID mm: 1.85Wall Thickness mm: 0.86OD mm: 3.57Overall Length: 455mm (140mm spacing between tags)Number of Tubes Per Pack: 12Physical Properties: Thermoplastic, PVC based material with plasticizerMaterial: Made from Tygon 4040 or equivalent.Special Properties: Special tubing for hydrocarbons, petroleum products and distillates.Chemical Compatibility: Ideal for gasoline, kerosene, heating oils, cutting liquids and coolants based on glycols.Limitations: Not recommended for strong acids and alkalis, foodstuffs, beverages and medicines. Potential leaching of plasticizersGlass Expansion is ISO 9001:2015 certified by AB Certification, No. AU4501-9001
Glass Expansion HF Drain Device
HF Drain Device (046-00093-06). Compatible with Shimadzu ICPE 9000/9800 and ICPS 7500/8100 ICP-OES and ICPM-2030 ICP-MS.Glass Expansion is ISO 9001:2015 certified by AB Certification, No. AU4501-9001
Glass Expansion Tracey PFA44 Spray Chamber with Helix CT, 44ml cyclonic, PFA. Includes UFT-16-75 UniFit Connector (1 unit) and 70-803-1439 Helix CT locking screw with seal (1 unit)
Tracey PTFE spray chamber, includes Helix CT locking screw & seal (1 pc) & UniFit with 1.6mm OD x 0.75mm ID x 700mm long tube (1 pc). Made from PTFE for HF resistance, 44mL volume. Compatible with VG PlasmaQuad and Axiom Series ICP-MS.The Tracey PTFE is a HF-resistant cyclonic design with a proprietary Stediflow surface treatment that significantly improves sensitivity & precision, in addition to enhancing washout efficiency compared to other inert spray chamber designs. The interior surface can be refurbished at a nominal cost, average lifespan of treatment is 12 months when well cared for.The main feature of the Helix CT interface is the built-in, ratcheting torque control mechanism that allows for a consistent, zero dead volume & chemically inert seal of the nebulizer.Replacement parts include NC1943061, NC2081825 & V-044, suggested to replace every 6 months.Glass Expansion is ISO 9001:2015 certified by AB Certification, No. AU4501-9001
Glass Expansion Tracey TFE Spray Chamber with Helix CT 50ml cyclonic, PTFE. Includes UFT-16-75 and UFT-2-700 UniFit Connectors (1 each) and 70-803-1439 Helix CT locking screw with seal (1 unit)
Tracey PTFE spray chamber, includes Helix CT locking screw & seal, UniFit 1.6mm OD x 0.75mm ID x 700mm long tube, & UniFit 2.0mm OD x 0.86mm ID x 700mm long tube (1 ea). Made from PTFE, 50mL volume. Compatible with Horiba 24, 38 & 138 Series, Ultima, Activa ICP-OES.The Tracey PTFE is a HF-resistant cyclonic design with a proprietary Stediflow surface treatment that significantly improves sensitivity & precision, in addition to enhancing washout efficiency compared to other inert spray chamber designs. The interior surface can be refurbished at a nominal cost, average lifespan of treatment is 12 months when well cared for.The main feature of the Helix CT interface is the built-in, ratcheting torque control mechanism that allows for a consistent, zero dead volume & chemically inert seal of the nebulizer.Replacement parts include NC1943061, UFT-2-700, NC2081825 & V-044, suggested to replace every 6 months.Glass Expansion is ISO 9001:2015 certified by AB Certification, No. AU4501-9001
Glass Expansion Twister TFE Spray Chamber with Helix CT, 50ml cyclonic, PTFE. Includes UFT-075 UniFit Connector (1 unit) and 70-803-1439 Helix CT locking screw with seal (1 unit)
Twister PTFE spray chamber, includes Helix CT locking screw & seal (1 pc) & UniFit with 1.3mm OD x 0.75mm ID x 700mm long tube (1 pc). Made from PTFE for HF resistance, 50mL volume. Compatible with Agilent 5000 series and PE Avio 200/500 series ICP-OES.The Twister PTFE is a HF-resistant, baffled cyclonic design with a proprietary Stediflow surface treatment that significantly improves sensitivity & precision, in addition to enhancing washout efficiency compared to other inert spray chamber designs. The PTFE Twister is an excellent choice for high matrix samples with HF. The interior surface can be refurbished at a nominal cost.The main feature of the Helix CT interface is the built-in, ratcheting torque control mechanism that allows for a consistent, zero dead volume & chemically inert seal of the nebulizer.Replacement parts include UFT-075, NC2081825 & V-044, suggested to replace every 6 months.Glass Expansion is ISO 9001:2015 certified by AB Certification, No. AU4501-9001
Perkin Elmer US LLC Polyethylene Nebulizer Capillary Tubing, 0.58 I.D. - Qty. 10 ft
This is a 10 foot (3 m) capillary tubing accessory for various nebulizers. Included in: Quick-Change Torch Module with Cyclonic Spray Chamber and Concentric Nebulizer for Optima 8x00 (N0780607), Quick-Change Torch Module with Cyclonic Spray Chamber and Concentric Nebulizer for Optima 2x00/4x00/5x00/7x00 (N0770607), HF Sample Introduction Kit for NexION 300/350 (N8140507), Standard Stainless Steel Nebulizer Complete Assembly for PinAAcle (N3160143), Organics Stainless Steel Nebulizer Complete Assembly for PinAAcle (N3160158), Universal GemTip Plastic Body Nebulizer Complete Assembly for AAnalyst (N0370394), and the GemTip High-Sensitivity Plastic Body Nebulizer Complete Assembly for AAnalyst (N0370393). Note: This capillary tubing is not compatible with the High Sensitivity Nebulizer Assembly for AAnalyst 200/400/700/800 (N3150188).
C Technology Inc SOLO VPE PLATFORM WINDOW
This item has a minimum qty of 5 per supplier requirements.
