Experience rapid cell counting with the Countess 3 Automated Cell Counter. Equipped with advanced optics, automated focus and lighting, and AI-based image analysis software, the Countess 3 brightfield cell counter enables automated cell counting and measurement of cell viability.
Shipping Condition | Ambient |
---|---|
Electrical Requirements | 12 VDC, 3 A |
Dimensions | 9 x 9 x 5.5 in. (228.6 x 228.6 x 139.7 mm) |
Optics | 1 Channel (Brightfield) |
For Use With (Application) | Cell Counting and Viability Measurement |
Detection Method | Brightfield |
For Use With (Equipment) | EVOS Microscopes, Countess Chamber Slides, and Reusable Slide |
Voltage | 100/240 V |
Weight (English) | 8 lb. |
Certifications/Compliance | RoHS |
Camera | 5 MP |
Magnification | 2.5X |
Weight (Metric) | 3.6 kg |
Display | LCD (1280 x 800 pixels) |
Product Line | Countess |
BioTek Cytation 1 cell imaging multi-mode reader combines fluorescence and high contrast brightfield imaging with conventional multi-mode detection. For Research Use Only. Not for use in diagnostic procedures.
Height (Metric) | 44.5 cm |
---|---|
Depth (English) | 20 in. |
Width (English) | 16.5 in. |
Shaking | Linear, Orbital, Double Orbital |
Light Source | Xenon Flash |
Width (Metric) | 41.9 cm |
Reading Options | Endpoint, kinetic, area scanning, plate mode inject/read process and well mode inject/read process |
Type | Cell Imaging Multi-Mode Microplate Reader |
Depth (Metric) | 50.8 cm |
Software | Gen5 Microplate Reader and Imager Software |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Temperature Range (Metric) | Incubation to 45°C |
O2 Concentration Range | 0 to 19% |
CO2 Concentration Range | 0 to 20% |
Height (English) | 17.5 in. |
Resolution | 0.3 μm/pixel at 20X |
Plate Type | 6-well to 384-well plates |
Lionheart FX automated microscope is a compact system for a broad range of imaging workflows. For Research Use Only. Not for use in diagnostic procedures.
Vials of high-quality, methanol-free formaldehyde, a general IHC fixative and reversible amine-crosslinking agent for protein and nucleic acid samples.
Content And Storage | Store in original container protected from direct sunlight in a dry, cool and well-ventilated area. |
---|---|
Type | Formaldehyde |
Format | Liquid |
Reagent Type | Fixation Reagent |
Product Line | Pierce |
The Live Cell Imaging Solution from Molecular Probes™ is a physiological medium developed for live cell imaging applications that has universal utility in cell-based research—for live cell imaging, dye loading, and wash steps.
The EVOS M5000 Imaging System is a fully integrated digital inverted benchtop system for four-color fluorescence, transmitted light, and color imaging.
The EVOS XL Core Imaging System is a digital transmitted-light inverted imaging system for cell and tissue culture applications and routine cell maintenance.
Captures high-quality, three-color fluorescent cell images right at your benchtopx
BioTek Cytation 7 cell imaging multi-mode reader combines automated digital upright and inverted widefield microscopy with conventional multi-mode microplate reading. For Research Use Only. Not for use in diagnostic procedures.
Scan Speed | 96-wells: 11 s; 384-wells: 22 s |
---|---|
Shaking | Linear, Orbital, Double Orbital |
Light Source | Xenon Flash |
Wavelength | Luminescence 300 to 700 nm; Absorbance 230 to 999 nm, 1 nm increment |
Detection Method | Monochromator- based fluorescence intensity, luminescence and absorbance |
Reading Options | End point, kinetic, spectral scanning and well area scanning |
Sensitivity | Fluorescein 2.5 pM (0.25 fmol/well, 384-well plate) – top Fluorescein 4 pM (0.4 fmol/well, 384-well plate) – bottom; luminescence 20 amol ATP (flash) |
Type | Automated Microscope/Multi-Mode Microplate Reader |
No. of Dispensers | 2 Syringe Pumps |
Dispense Volume | 5 to 1000 μL, 1 μL increments |
Linearity | <1% from 0 to 3 OD |
Voltage | 100/240 V |
Bandwidth | 4 nm (230 to 285 nm), 8 nm (>285 nm) |
Frequency | 50/60 Hz |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Wavelength Selection | Quad monochromators (top/bottom) |
Temperature Range (Metric) | 4-Zone incubation to 45°C with Condensation Control (±0.5°C at 37°C) |
Resolution | 0.0001 OD |
Plate Type | Monochromator: 6- to 384-well plates; Imaging: 6- to 1536-well plates |
Cytation 5 combines automated microscopy and conventional microplate detection in a configurable, upgradable platform. For Research Use Only. Not for use in diagnostic procedures.
Height (Metric) | 44.5 cm |
---|---|
Depth (English) | 20.2 in. |
Width (English) | 16.4 in. |
Contrast Methods | Fluorescence, phase contrast, brightfield, high contrast brightfield, color brightfield and phase contrast |
Shaking | Linear, Orbital, Double Orbital |
Wattage | 250 W max. |
Objectives | 1.25x, 2.5x (2.25x eff), 2.5x (2.75x eff), 4x, 10x, 20x, 40x, 60x |
Width (Metric) | 41.6 cm |
Dynamic Range | Absorbance: 0 to 4 OD; Fluorescence Intensity: 7 decades; Luminesence: >6 decades |
Type | Cell Imaging Only Microplate Reader |
For Use With (Equipment) | BioStack and Third Party Automation Compatible; BioSpa 8 Automated Incubator Compatible |
Depth (Metric) | 51.4 cm |
Weight (English) | 80 lb. |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Camera | Sony CMOS, 16-bit Gray Scale, Standard or WFOV |
Temperature Range (Metric) | 4-Zone incubation to 65°C with Condensation Control (±0.2°C at 37°C) |
CO2 Concentration Range | 0 to 20% |
Weight (Metric) | 36.3 kg |
Height (English) | 17.5 in. |
Plate Type | Monochromator: 6- to 384-well plates; Filters: 6-to 1536 well plates; Imaging: 6-to 1536 well plates |
The Invitrogen™ EVOS™ M5000 Cell Imaging System brings simple, automated microscopy within reach. All-in-one design includes high resolution fluorescence imaging, unique color illumination, a full suite of fluorescent filters, and intuitive software.
The EVOS XL Core Imaging System is a digital transmitted-light inverted imaging system for cell and tissue culture applications and routine cell maintenance.
Cytation 5 combines automated microscopy and conventional microplate detection in a configurable, upgradable platform. For Research Use Only. Not for use in diagnostic procedures.
Height (Metric) | 44.5 cm |
---|---|
Depth (English) | 20.2 in. |
Width (English) | 16.4 in. |
Shaking | Linear, Orbital, Double Orbital |
Wattage | 250 W max. |
Absorbance Range | 230 to 999 nm, 1 nm increments |
Light Source | Xenon Flash; 100 mW 680 nm laser (Alpha Detection) |
Width (Metric) | 41.6 cm |
Dynamic Range | Absorbance: 0 to 4 OD; Fluorescence Intensity: 7 decades; Luminesence: >6 decades |
Reading Options | End point, kinetic, spectral scanning and well area scanning |
Accuracy | Monochromator: ±2 nm; Dispenser: ±1 μL or 2% |
Type | Multi-Mode Only Microplate Reader |
No. of Dispensers | 2 Syringe Pumps |
Dispense Volume | 5 to 1000 μL, 1 μL increments |
For Use With (Equipment) | BioStack and Third Party Automation Compatible; BioSpa 8 Automated Incubator Compatible |
Depth (Metric) | 51.4 cm |
Weight (English) | 80 lb. |
Software | Gen5 Microplate Reader and Imager Software included; Gen5 Image+ and Image Prime software available for full image analysis; Gen5 Secure for 21 CFR Part 11 compliance (option) |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Temperature Range (Metric) | 4-Zone incubation to 65°C with Condensation Control (±0.2°C at 37°C) |
CO2 Concentration Range | 0 to 20% |
Weight (Metric) | 36.3 kg |
Height (English) | 17.5 in. |
Through the utilization of interferometry in conjunction with microscopy, the Corning™ Microdrop; senses, detects, characterizes, and tracks single nanoparticles in real time.
Digital, transmitted light, inverted imaging system for cell and tissue culture applications and routine cell maintenance.
