Cellular Imaging

Instruments, software products, and accessories used to capture images of cell samples for clinical analysis, cellular research, and other laboratory applications.

1 – 15 of 440 results

Invitrogen™ Countess™ 3 Automated Cell Counter

Experience rapid cell counting with the Countess 3 Automated Cell Counter. Equipped with advanced optics, automated focus and lighting, and AI-based image analysis software, the Countess 3 brightfield cell counter enables automated cell counting and measurement of cell viability.

Promotions are available

Pricing & Availability
Specifications

Shipping Condition	Ambient
Electrical Requirements	12 VDC, 3 A
Dimensions	9 x 9 x 5.5 in. (228.6 x 228.6 x 139.7 mm)
Optics	1 Channel (Brightfield)
For Use With (Application)	Cell Counting and Viability Measurement
Detection Method	Brightfield
For Use With (Equipment)	EVOS Microscopes, Countess Chamber Slides, and Reusable Slide
Voltage	100/240 V
Weight (English)	8 lb.
Certifications/Compliance	RoHS
Camera	5 MP
Magnification	2.5X
Weight (Metric)	3.6 kg
Display	LCD (1280 x 800 pixels)
Product Line	Countess

Agilent BioTek Cytation 1 Cell Imaging Multi-Mode Reader

BioTek Cytation 1 cell imaging multi-mode reader combines fluorescence and high contrast brightfield imaging with conventional multi-mode detection. For Research Use Only. Not for use in diagnostic procedures.

Pricing & Availability
Specifications

Height (Metric)	44.5 cm
Depth (English)	20 in.
Width (English)	16.5 in.
Shaking	Linear, Orbital, Double Orbital
Light Source	Xenon Flash
Width (Metric)	41.9 cm
Reading Options	Endpoint, kinetic, area scanning, plate mode inject/read process and well mode inject/read process
Type	Cell Imaging Multi-Mode Microplate Reader
Depth (Metric)	50.8 cm
Software	Gen5 Microplate Reader and Imager Software
Certifications/Compliance	CE and TUV marked. RoHS compliant.
Temperature Range (Metric)	Incubation to 45°C
O2 Concentration Range	0 to 19%
CO2 Concentration Range	0 to 20%
Height (English)	17.5 in.
Resolution	0.3 μm/pixel at 20X
Plate Type	6-well to 384-well plates

Agilent BioTek Lionheart FX Automated Microscope

Lionheart FX automated microscope is a compact system for a broad range of imaging workflows. For Research Use Only. Not for use in diagnostic procedures.

Pricing & Availability

Thermo Scientific™ Pierce™ 16% Formaldehyde (w/v), Methanol-free

Vials of high-quality, methanol-free formaldehyde, a general IHC fixative and reversible amine-crosslinking agent for protein and nucleic acid samples.

Pricing & Availability
Specifications

Content And Storage	Store in original container protected from direct sunlight in a dry, cool and well-ventilated area.
Type	Formaldehyde
Format	Liquid
Reagent Type	Fixation Reagent
Product Line	Pierce

Invitrogen™ Live Cell Imaging Solution

The Live Cell Imaging Solution from Molecular Probes™ is a physiological medium developed for live cell imaging applications that has universal utility in cell-based research—for live cell imaging, dye loading, and wash steps.

Pricing & Availability

Invitrogen™ EVOS™ M5000 Imaging System

The EVOS M5000 Imaging System is a fully integrated digital inverted benchtop system for four-color fluorescence, transmitted light, and color imaging.

Pricing & Availability

Invitrogen™ EVOS™ XL Core Configured Cell Imager with Mechanical Stage

The EVOS XL Core Imaging System is a digital transmitted-light inverted imaging system for cell and tissue culture applications and routine cell maintenance.

Pricing & Availability

Invitrogen™ FLoid™ Cell Imaging Station

Captures high-quality, three-color fluorescent cell images right at your benchtopx

Pricing & Availability

Agilent BioTek Cytation 7 Cell Imaging Multi-Mode Reader

BioTek Cytation 7 cell imaging multi-mode reader combines automated digital upright and inverted widefield microscopy with conventional multi-mode microplate reading. For Research Use Only. Not for use in diagnostic procedures.

Pricing & Availability
Specifications

Scan Speed	96-wells: 11 s; 384-wells: 22 s
Shaking	Linear, Orbital, Double Orbital
Light Source	Xenon Flash
Wavelength	Luminescence 300 to 700 nm; Absorbance 230 to 999 nm, 1 nm increment
Detection Method	Monochromator- based fluorescence intensity, luminescence and absorbance
Reading Options	End point, kinetic, spectral scanning and well area scanning
Sensitivity	Fluorescein 2.5 pM (0.25 fmol/well, 384-well plate) – top Fluorescein 4 pM (0.4 fmol/well, 384-well plate) – bottom; luminescence 20 amol ATP (flash)
Type	Automated Microscope/Multi-Mode Microplate Reader
No. of Dispensers	2 Syringe Pumps
Dispense Volume	5 to 1000 μL, 1 μL increments
Linearity	<1% from 0 to 3 OD
Voltage	100/240 V
Bandwidth	4 nm (230 to 285 nm), 8 nm (>285 nm)
Frequency	50/60 Hz
Certifications/Compliance	CE and TUV marked. RoHS compliant.
Wavelength Selection	Quad monochromators (top/bottom)
Temperature Range (Metric)	4-Zone incubation to 45°C with Condensation Control (±0.5°C at 37°C)
Resolution	0.0001 OD
Plate Type	Monochromator: 6- to 384-well plates; Imaging: 6- to 1536-well plates

Agilent BioTek Cytation 5 Cell Imaging Only Reader

Cytation 5 combines automated microscopy and conventional microplate detection in a configurable, upgradable platform. For Research Use Only. Not for use in diagnostic procedures.

Pricing & Availability
Specifications

Height (Metric)	44.5 cm
Depth (English)	20.2 in.
Width (English)	16.4 in.
Contrast Methods	Fluorescence, phase contrast, brightfield, high contrast brightfield, color brightfield and phase contrast
Shaking	Linear, Orbital, Double Orbital
Wattage	250 W max.
Objectives	1.25x, 2.5x (2.25x eff), 2.5x (2.75x eff), 4x, 10x, 20x, 40x, 60x
Width (Metric)	41.6 cm
Dynamic Range	Absorbance: 0 to 4 OD; Fluorescence Intensity: 7 decades; Luminesence: >6 decades
Type	Cell Imaging Only Microplate Reader
For Use With (Equipment)	BioStack and Third Party Automation Compatible; BioSpa 8 Automated Incubator Compatible
Depth (Metric)	51.4 cm
Weight (English)	80 lb.
Certifications/Compliance	CE and TUV marked. RoHS compliant.
Camera	Sony CMOS, 16-bit Gray Scale, Standard or WFOV
Temperature Range (Metric)	4-Zone incubation to 65°C with Condensation Control (±0.2°C at 37°C)
CO2 Concentration Range	0 to 20%
Weight (Metric)	36.3 kg
Height (English)	17.5 in.
Plate Type	Monochromator: 6- to 384-well plates; Filters: 6-to 1536 well plates; Imaging: 6-to 1536 well plates

Invitrogen™ EVOS™ M5000 Imaging System

The Invitrogen™ EVOS™ M5000 Cell Imaging System brings simple, automated microscopy within reach. All-in-one design includes high resolution fluorescence imaging, unique color illumination, a full suite of fluorescent filters, and intuitive software.

Pricing & Availability

Invitrogen™ EVOS™ XL Core Configured Cell Imager

The EVOS XL Core Imaging System is a digital transmitted-light inverted imaging system for cell and tissue culture applications and routine cell maintenance.

Pricing & Availability

Agilent BioTek Cytation 5 Multi-Mode Only Reader

Cytation 5 combines automated microscopy and conventional microplate detection in a configurable, upgradable platform. For Research Use Only. Not for use in diagnostic procedures.

Pricing & Availability
Specifications

Height (Metric)	44.5 cm
Depth (English)	20.2 in.
Width (English)	16.4 in.
Shaking	Linear, Orbital, Double Orbital
Wattage	250 W max.
Absorbance Range	230 to 999 nm, 1 nm increments
Light Source	Xenon Flash; 100 mW 680 nm laser (Alpha Detection)
Width (Metric)	41.6 cm
Dynamic Range	Absorbance: 0 to 4 OD; Fluorescence Intensity: 7 decades; Luminesence: >6 decades
Reading Options	End point, kinetic, spectral scanning and well area scanning
Accuracy	Monochromator: ±2 nm; Dispenser: ±1 μL or 2%
Type	Multi-Mode Only Microplate Reader
No. of Dispensers	2 Syringe Pumps
Dispense Volume	5 to 1000 μL, 1 μL increments
For Use With (Equipment)	BioStack and Third Party Automation Compatible; BioSpa 8 Automated Incubator Compatible
Depth (Metric)	51.4 cm
Weight (English)	80 lb.
Software	Gen5 Microplate Reader and Imager Software included; Gen5 Image+ and Image Prime software available for full image analysis; Gen5 Secure for 21 CFR Part 11 compliance (option)
Certifications/Compliance	CE and TUV marked. RoHS compliant.
Temperature Range (Metric)	4-Zone incubation to 65°C with Condensation Control (±0.2°C at 37°C)
CO2 Concentration Range	0 to 20%
Weight (Metric)	36.3 kg
Height (English)	17.5 in.

Corning™ Videodrop

Through the utilization of interferometry in conjunction with microscopy, the Corning™ Microdrop; senses, detects, characterizes, and tracks single nanoparticles in real time.

Pricing & Availability

Invitrogen™ EVOS™ XL Core Imaging System

Digital, transmitted light, inverted imaging system for cell and tissue culture applications and routine cell maintenance.

Pricing & Availability
