MSC Barcor Countersink Gage, 90 Degree Angle, .560 in. to .780 in. Capacity, 1 ea.
The Barcor countersink gage is a precision instrument designed for the rapid and direct measurement of the major (top) countersink diameter. This gage features a spring-loaded, conically ground gaging plunger that allows for direct reading of dimensions as called out on technical drawings. Suitable for use on flat, concave, or convex surfaces, it provides fast and repeatable measurements for applications ranging from production machining to quality control inspections.
- Measurement capacity of .560 in. to .780 in.
- Countersink angle of 90°
- Graduations in .002 in. increments
- Accuracy of ±.0005 in.
- Standard peak hold mechanism
- Includes setting ring and foam-lined storage case
MSC Vermont Gage Plug Gage, Class X, Tool Steel, 0.4760 in. Diameter, 2 in. Length, 1 ea.
This Class X plug gage is designed for high-precision calibration of measuring equipment or for direct inspection of parts. Manufactured from cold-stabilized tool steel hardened to 60/65 Rc, this pin gage offers exceptional durability and wear resistance in demanding industrial environments.
- Diameter of 0.4760 in.
- Overall length of 2 in.
- Tolerance of 0.00004 in.
- Roundness within 1/2 of tolerance
- Surface finish of 4 microinch or better
- Includes certificate of accuracy with NIST traceability
MSC Vermont Gage Class X Minus Pin Gage, Tool Steel, 0.6245 in. Dia., 2 in. Length, 1 ea.
This Class X minus pin gage is a precision measurement tool designed for the calibration of equipment or direct part inspection. Manufactured from cold-stabilized tool steel, this gage offers high durability and reliability for metrology applications.
- Diameter of 0.6245 in. with a tolerance of -0.00004 in.
- Length of 2 in.
- Constructed from tool steel with 60/65 Rc hardness.
- Surface finish of 4 microinch or better.
- Roundness within 1/2 of tolerance.
- Includes certificate of accuracy with NIST traceability.
MSC Vermont Gage Class X Pin Gage, 0.2510 in. Diameter, Tool Steel, 2 in. Length, 1 ea.
This Class X Plus plug gage is designed for precision measurements, suitable for both shop floor use and metrology laboratory applications. It serves as a reliable master for the calibration of measuring equipment or for direct part gaging, featuring an included certificate of accuracy with NIST traceability to ensure quality and reliability.
- Tool steel construction with a hardness of 60/65 Rc
- Cold stabilized for dimensional consistency
- Surface finish of 4 microinch or better
- Tolerance of +0.00004 in., -0.0000 in.
- Overall length of 2 in.
- Round within 1/2 of tolerance
- Class X precision accuracy
