Addition Funnels
Ace Glass, Inc. Funnel, addition, graduated, PTFE stopcock, 10mL, 14/20
Funnel, addition, graduated, PTFE stopcock, 10mL, 14/20
Chemglass Life Sciences 60mL Addition Funnel, Graduated, 24/40 Joint Size, 2mm PTFE Stpk, 265mm OAH
60mL Addition Funnel, Graduated, 24/40 Joint Size, 2mm PTFE Stopcock, 265mm OAH. Cylindrical style addition funnel similar to CG-1710, but with a PTFE stopcock. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences Funnel, Solvent Addition, Stem 22mm OD X 75mm Long
Funnel, Solvent Addition, Stem 22mm OD X 75mm Long. Design of funnel permits addition of solvents to flash chromatography columns without disturbing the silica-gel / packing layer. Lower end of the funnel is closed and the stem has a series of small holes through which the solvent drains. Top of the funnel is 75mm (3in) in diameter with the stem size as listed.
Microsolv Technology Corporation Mobile Phase Filter, 10um, Last Drop™, PTFE, 1/16" Connector. 1 EA.
These Last Drop, PEEK and Polypropylene Mobile Phase Filters are manufactured with a 10um PTFE Filter Element and will provide very high filter capacity and throughput while using a maximum amount of solvent. The unique design allows for this flat filter to "vacuum" up to the "last drop of liquid" in the reservoir bottle. The all PEEK, 1/16" Tubing Connector uses the fitting and an ETFE ferrule to hold non-flanged low pressure tubing in to the Filter without leaking. The 10um pore size Element will filter undissolved particles from your solvents that are 10um or larger preventing them from damaging your HPLC pumps, columns or instrument. Install these filters directly in your mobile phase bottles.
Chemglass Life Sciences Chemglass 60 mL Addition Funnel, Graduated, 14/20 Joint, 2 mm Glass Stopcock, 225 mm OAH
The Chemglass 60 mL graduated addition funnel is a cylindrical glass funnel designed for controlled, pressure-equalized addition of reagents in laboratory workflows. It provides accurate dosing with a double graduation scale and includes a pressure-equalizing arm and a 2 mm glass stopcock. Funnels with 14/20 joints are supplied complete with a stopper.
- Capacity: 60 mL
- Joint size: 14/20 (top outer and lower inner)
- Stopcock type: 2 mm glass stopcock
- Overall length (OAH): 225 mm
- Graduated with a double scale of numbers
- Pressure equalizing arm
- Supplied complete with a stopper for 14/20 joints
Chemglass Life Sciences 25mL Addition Funnel, 14/20 Joint Size, 2mm Glass Stpk, 200mm OAH
25mL Addition Funnel, 14/20 Joint Size, 2mm Glass Stopcock, 200mm OAH. Cylindrical style addition funnel with a standard taper top outer joint and lower inner joint, both being the same size. With pressure equalizing arm and glass stopcock. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Ace Glass, Inc. 500mL graduated cylindrical funnel, 24/40 top, 24/40 bottom
500mL graduated cylindrical funnel with 24/40 joints at top and bottom. Features include drip stem, and double scale graduations calibrated from stopcock. Drip stem does not extend beyond the joint, thereby eliminating a possible source of breakage. Includes PTFE stopcock plug.
Chemglass Life Sciences 125mL Addition Funnel, Graduated, 24/40 Joint Size, 2mm Glass Stpk, 325mm OAH
125mL Addition Funnel, Graduated, 24/40 Joint Size, 2mm Glass Stopcock, 325mm OAH. Cylindrical style addition funnel graduated with a double scale of numbers, one up from the stopcock and one down from the capacity line. With a standard taper top outer joint and lower inner joint, both being the same size, and pressure equalizing arm. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Ace Glass, Inc. Addition funnel, 35L, #25 Ace-Thred bottom, body only
35L addition/separatory funnel body for use where large volumes are needed. The cylindrical shape necks down to a #25 Ace-Thred.
Ace Glass, Inc. 3000mL Addition funnel with Ace-Thred™ connections for a leak-proof seal.
3000mL Addition funnel with Ace-Thred™ connections for a leak-proof seal.
Chemglass Life Sciences 25mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm Glass Stpk, 200mm OAH
25mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm Glass Stopcock, 200mm OAH. Cylindrical style addition funnel graduated with a double scale of numbers, one up from the stopcock and one down from the capacity line. With a standard taper top outer joint and lower inner joint, both being the same size, and pressure equalizing arm. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 2000mL Addition Funnel, 24/40 Joint Size, 6mm Stpk, 530mm OAH
2000mL Addition Funnel, 24/40 Joint Size, 6mm Stopcock, 530mm OAH. Cylindrical shape addition funnel with PTFE stopcocks. For replacement stoppers see CG-3000.
Chemglass Life Sciences 60mL Addition Funnel, Cooling Jacket, 24/40 Joint Size, 2mm Stpk
60mL Addition Funnel, Cooling Jacket, 24/40 Joint Size, 2mm Stopcock. Jacket permits the cooling of the contents of the funnel by means of dry ice. Drain outlet is 8mm O.D. With a standard taper top outer joint and lower inner joint, both being the same size, and pressure equalizing arm.
Chemglass Life Sciences 50mL Addition Funnel, Graduated, 14/20 Joint Size, 0-2mm PTFE Valve, 240mm OAH
50mL Addition Funnel, Graduated, 14/20 Joint Size, 0-2mm PTFE Valve, 240mm OAH. Cylindrical style graduated addition funnel has a threaded, grease-free extended tip valve. Design of all PTFE plug permits semi-needle valve action. With a standard taper top outer joint and lower inner joint, both being the same size, and pressure equalizing arm. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
