Tubing Connectors and Fittings
Chemglass Life Sciences Graded Seal, Quartz to Borosilicate, 4mm ID X 6mm OD
Graded Seal, Quartz to Borosilicate, 4mm ID X 6mm OD. Graded seals have 3 inches of quartz sealed to 4 inches of borosilicate.
Chemglass Life Sciences Valve, Chem-Vac, Glass Portion Only, 180°, 0-4mm Bore, 13mm OD Barrel, 9mm X 1.5W Sidearm
Valve, Chem-Vac, Glass Portion Only, 180¿, 0-4mm Bore, 13mm OD Barrel, 9mm X 1.5W Sidearm. CHEM-VAC valve glass portion only. Valve has two sidearms sealed to the barrel at a 180¿ angle to one another and on the same plane. Heavy duty rounded coarse thread and precision formed tapered seat. Dimensions as listed.
Chemglass Life Sciences Valve, Chem-Vac, Glass Portion Only, 90°, 0-8mm Bore, 19mm OD Barrel, 12.7mm X 1.6W Sidearm
Valve, Chem-Vac, Glass Portion Only, 90¿, 0-8mm Bore, 19mm OD Barrel, 12.7mm X 1.6W Sidearm. CHEM-VAC valve glass portion only. Valve has two sidearms sealed to the barrel at a 90¿ angle to one another. Heavy duty rounded coarse thread and precision formed tapered seat. Dimensions as listed. PLEASE NOTE: THE 0-20mm BORE SIZE IS OUR PREVIOUS STYLE CG-500 SERIES VALVE WITH COARSE THREAD.
Chemglass Life Sciences Adapter, Flow Control, 90°, 2mm Stpk, 29/42 Inner Joint
Adapter, Flow Control, 90¿, 2mm Stpk, 29/42 Inner Joint. Used to regulate the flow of gases or liquids into reaction systems. Stopcock has a bore of 2mm and is supplied complete with a CG-423 retaining clip. Hose connection has an O.D. of 8mm at the middle serration.
Chemglass Life Sciences Adapter, Distillation, 14/20 Joint Size, Side Inner Joint At 75°
Adapter, Distillation, 14/20 Joint Size, Side Inner Joint At 75¿, with standard taper outer joint at the top, and inner joints on the bottom and sidearm, all being the same size. Inner joints are at a 75¿ angle to one another.
Chemglass Life Sciences Adapter, Connecting, 24/40 Joint Size, Side Outer Joint At 105°
Adapter, Connecting, 24/40 Joint Size, Side Outer Joint At 105¿, with standard taper joints at top and side, with inner joint at bottom. Sidearm is at a 105¿ angle from the lower tube.
Chemglass Life Sciences Inner Luer Joint, on 7.0mm OD x 4.0mm ID Capillary
Inner Luer Joint, on 7.0mm OD x 4.0mm ID Capillary. Inner joint manufactured to the same specifications found on medical and research syringes. Complies with Federal Specification CG-S-921b and USAST Standard Z70.1. Available tooled on three tubing sizes with the inner diameter being 1mm through the tip of the joint on all three sizes.
Chemglass Life Sciences Adapter, Bushing, 24/40 Lower Inner, 10/30 Top Outer
Adapter, Bushing, 24/40 Lower Inner, 10/30 Top Outer. Bushing style adapter having a lower standard taper inner joint and outer joint ground in the bore of the adapter. Adapters having a 10/18 or 10/30 outer member in the bore are used to insert thermometers into apparatus.
Chemglass Life Sciences Adapter, Distillation, 24/40 Joint Size, Side Inner Joint At 75°
Adapter, Distillation, 24/40 Joint Size, Side Inner Joint At 75¿, with standard taper outer joint at the top, and inner joints on the bottom and sidearm, all being the same size. Inner joints are at a 75¿ angle to one another.
Chemglass Life Sciences Adapter, Claisen, 45/50 Joint Size, 240mm H x 180mm W
Adapter, Claisen, 45/50 Joint Size, 240mm H x 180mm W. With outer standard taper joints on both top arms and lower inner joint. All three joints are the same size.
Chemglass Life Sciences Adapter, Bushing, 45/50 Lower Inner, 24/40 Top Outer
Adapter, Bushing, 45/50 Lower Inner, 24/40 Top Outer. Bushing style adapter having a lower standard taper inner joint and outer joint ground in the bore of the adapter. Adapters having a 10/18 or 10/30 outer member in the bore are used to insert thermometers into apparatus.
Chemglass Life Sciences Adapter, Distillation, 75°, 14/20 Inner Joints, 10/18 Thermometer Joint For 25mm Immersion
Adapter, Distillation, 75¿, 14/20 Inner Joints, 10/18 Thermometer Joint For 25mm Immersion. Adapter has a standard taper outer joint at the top of the main tube for use with jointed thermometers. The 10/18 size is used with 10/18, 25mm immersion thermometers. With inner joints on the bottom and sidearm at a 75¿ angle to one another.
Chemglass Life Sciences Adapter, Flow Control, 90°, 2mm Stpk, 14/20 Inner Joint
Adapter, Flow Control, 90¿, 2mm Stpk, 14/20 Inner Joint. Used to regulate the flow of gases or liquids into reaction systems. Stopcock has a bore of 2mm and is supplied complete with a CG-423 retaining clip. Hose connection has an O.D. of 8mm at the middle serration.
Chemglass Life Sciences 34/45 Outer Joint, 16in OAL, on 38mm OD x 2mm W tubing
34/45 Outer Joint, 16in OAL, on 38mm OD x 2mm W tubing. Standard taper inner and outer lengths tooled on longer lengths or different sizes than normally available under part numbers CG-100 through CG-105. These joints offer the glassblower the opportunity to construct apparatus made of heavier tubing or without unnecessary seals.
